3M™ No Polish SC Connector SM and MM

250/900 µm

Instructions

November 2010

78-8140-0034-1-E

Contents

1.0 KitContents............................................................................................................................................................................... 3

2.0 3M™NoPolishSCConnectorSMandMM250/900µm........................................................................................................ 3

3.0 3M™NoPolishConnector(NPC)Re-termination...............................................................................................................7

4.0 LossTesting............................................................................................................................................................................... 8

Safety Precautions

Protective Eyewear

c CAUTION

Safetyglassesshouldbewornwhenhandlingchemicalsandcleavingtheopticalber.

Chemical Precautions

c WARNING

Storage,useanddisposalofisopropylalcoholshouldbeperyourcompanyhealth,safetyandenvironmentalinstructions.Referto

MaterialSafetyDataSheetforhealthhazards,safehandling,properuseandcontrolmeasures.

c CAUTION

Productcontainsphenylmethylsilicone(63148-58-3),hydrophobicsilica(68611-44-9)andmaycauseminimaleyeirritation.Avoid

contactwitheyesandwashhandsbeforeeatingorsmoking.Uponeyecontact,immediatelyusheyeswithwaterwhileholdingeyelids

openandcontinueushingfortenminutes.Contactaphysician.Uponskincontact,washwithsoapandwater.ProductInformation:

MaterialSafetyDataSheetor3MCompany,St.PaulMN,55144-1000,(651)733-1110Operator55

Bare Fiber Handling

c CAUTION

Cleavedglassbersaresharpandcanpiercetheskin.Usetweezerswhenhandlingshardsanddisposeofthemproperlyperyourcom-

panyhealthandsafetyinstructions.

Fiber/Cable Handling

c CAUTION

Opticalbercanbedamagedbyexcessivetensile,compressiveandbendingforces.Consultthemanufactures'specicationsforproper

handlinginstructions.

Laser Safety

c CAUTION

Taketheproperprecautionswhenworkingwithopticalberbecauseinvisiblelaserlightmaybepresent.Theprincipallaserhazardwhen

workingwithberopticsisinjurytotheeye.Neverlookdirectlyintotheberorconnectorusingthenakedeyeoramicroscope.

1.0 Kit Contents

1.1 Thediagramsbelowshowthepartsofthe3M™No

PolishConnector(singlemodepictured)andthe3M

™

NoPolishConnectorAssemblyTool8865-AT.Please

reviewthesedrawingstounderstandtheinstructionsin

thefollowingpages.

™

No Polish SC Connector

Fiber

Ferrule

Splice

Element

Buffer

Clamp

Boot

Spring

< 50 mm ( )2”

Length

Shell

Collar

Backbone

3M™ No Polish Connector Assembly Tool 8865-AT

SC coupling

Element actuator button

Drag finger

Release lever

Actuation Tool

Assembly Base

Guide Funnel

Fiber Clamp

Fiber Covers

Fiber Holder

2.0 3M™ No Polish SC Connector SM

and MM 250/900 µm

2.1 Removethedustcapsfromthefrontandrearofthe

connector.Opentheactuatorbuttonontheassemblytool.

Inserttheconnectorwiththewhiteactuationcapfacing

upintothecoupling,pushingforwarduntilitclicks.

2.2 Cleantheberholderwithalint-freeclothsoaked

withalcohol.Moveguidefunnelforwardonber

holderuntilitstops;openbercoversandber

clamp.
