Analog LCD Monitor

AL502 User’s Manual

English

FCC compliance statement ......................................................................... 1

DOC compliance notice .............................................................................. 1

Introduction ................................................................................................. 2

Features ...................................................................................................... 2

Unpacking ................................................................................................... 3

Screen position adjustment.......................................................................... 4

Connecting the power cord ......................................................................... 4

Safety precaution ........................................................................................ 5

Cleaning your monitor ................................................................................. 5

Preset modes .............................................................................................. 6

Power saving .............................................................................................. 7

DDC ........................................................................................................... 7

Installation ................................................................................................... 8

User controls............................................................................................... 9

Front panel controls ................................................................................. 9

Basic section of a OSD screen ............................................................. 10

Standard OSD operation ....................................................................... 11

OSD function description ...................................................................... 11

Troubleshooting ......................................................................................... 13

Specification .............................................................................................. 14

TABLE OF CONTENTS

English

AL502

English

FCC Compliance Statement

This equipment has been tested and found to comply with the limits for a Class B digital

device, pursuant to Part 15 of the FCC Rules. These limits are designed to provide resonable

protection against radio frequency interference in a residential installation. This equipment

generates, uses, and can radiate radio frequency energy. If not installed and used in

accordance with the instructions, it may cause interference to radio communications.

However, there is no guarantee that intereference will not occur in a particular installation.

If this equipment does cause interference to radio or television reception (this can be

determined by turning this equipment off and on), the user is encouraged to try to correct

the interference by one or more of the following measures:

·Reorient or relocate the receiving antenna.

·Increase the separation between this equipment and the receiver.

·Connect this equipment to an outlet on a circuit different from which the

receiver is connected to.

·Consult the dealer or an experienced radio/TV technician for help.

Caution:

To comply with the limits for an FCC Class B computing device, always use the shielded

signal cord and shielded DC power cord supplied with this unit.

Caution to the user:

The Federal Communications Commission warns the user that changes or modifications

to the unit not expressly approved by the party responsible for compliance could void the

user’s authority to operate the equipment.

Notice of Compliance Canadian

Interference-causing Equipment Regulations

DOC Compliance Notice:

This digital apparatus does not exceed the Class B limits for radio noise emissions from

digital apparatus set out in the Radio Interference Regulations of the Canadian Department

of Communications.

DOC Avis de Conformation

Le présent appareil numérique n’emet pas de bruits radioélectriques dépassant les limites

applicable aux appareils numériques de la class B prescrites dan le Réglement sur le

brouillage radioélectriques édicté par le ministére des Communications du Canada.
