(40.2x26.4x1.4 inches)
Mechanical Characteristics
Type of cell
Dimensions
Weight
Front Glass
Frame
Encapsulation
Relative Humidity
Resistance
Snow load
parameters
Poly-crystalline 156 x 156 mm
1020x670x35mm
9.5Kg (20.6 lbs)
Low-Iron Tempered Glass
Aluminum Alloy
Glass/EVA/Cells/EVA/TPT
0 to 100%
2400Pa
227g steel ball fall down from
1m height and 60m/s wind
Electrical Characteristics
Characteristics 100W
Open-Circuit Voltage(Voc) 22.0V
Optimum Circuit Voltage(Vmp) 17.48V
Short-Circuit Current(Isc) 6.21A
Optimum Circuit Current(Imp) 5.72A
Maximum Power at STC(Pmax) 100W
Module Efficiency 14.35%
Operating Temperature -40 to +85℃℃
Maximum System Voltage 1000V DC
Power tolerance ±3%
STC: Irradiance 1000W/, Module temperature 25 ,㎡℃
AM=1.5
HY100-12P
100W
www.ACOPower.com
Power Your Green Life!
Size
Application Scope
Courtyard lighting.
Small household lighting system.
Street lighting.
Portable solar power.
All small power electrical devices & small PV
Temperature Coefficients
Nominal Operating Cell 45±5℃℃
Temperature(NOCT)
Temperature Coefficient of Pmax -0.45%/℃
Temperature Coefficient of Voc -0.35%/℃
Temperature Coefficient of Isc +0.05%/℃
Maximum SeriesFuse/current rating 10A
Unit:mm
(5 inches)
USA Sales: 4120 Valley Blvd, Ste B, Walnut, CA 91789, USA
Tel:+1-626-575 8822/7722 Fax: 626-800 2255
Email: sales@acopower.com
