Sida 1/14

ELS15 BT

Professional Powered Two-Way

Loudspeaker

Rev. 1/15

©American Audio® - www.AmericanAudio.us - ELS15 BT - Instruction Manual Page 2

ELS15 BT Contents

ELS15 BT Unpacking

ELS15 BT Introduction

Every ELS15 BT has been thoroughly tested and has been shipped in perfect operating condition.

Carefully check the shipping carton for damage that may have occurred during shipping. If the car-

ton appears to be damaged carefully inspect your units for any damage and be sure all accessories

necessary to operate the system have arrived intact. In the event damage has been found or parts are

missing, please contact our toll free customer support number for further instructions. Please do not

return the speaker to your dealer without rst contacting customer support.

Introduction: Congratulations and thank you for purchasing the American Audio

® ELS15 BT profes-

sional sound reinforcement loudspeaker. This loudspeaker is a representation of American Audio’s

continuing commitment to produce the best and highest quality audio products possible at an aord-

able price. The ELS15 BT is a lightweight 15-inch active speaker. Its extremely high eciency design,

low power consumption, and plenty of output power is ideal for small and mid-size events. The ELS15

BT is multifunctional. Users can also utilize the Microphone Inputs and built-in MP3 player with Wire-

less Audio or USB and Memory Card inputs. The speaker includes a poll mount slot and rubber feet

on the bottom of the unit for portable applications and also includes rigging points on the top, bottom,

and rear of the unit for permanent and ight installations. Please read and understand this manual

completely before attempting to operate your new speaker system. This booklet contains important

information concerning the proper and safe operation of your new speaker.

Customer Support: American Audio

® provides a toll free customer support line, to provide set up help

and answer any question should you encounter problems during your initial set up or operation. You

may also visit us on the web at www.americandj.com for any comments or suggestions. Service Hours

are Monday through Friday 8:00 a.m. to 4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2610

E-mail: support@americandj.com

Caution! There are no user serviceable parts inside this speaker. Do not attempt any repairs, without

being instructed to do so by an authorized American Audio technician. Doing so will void your manufac-

tures warranty. In the unlikely event your speaker may require service, please contact American Audio

®.

CUSTOMER SUPPORT..........................................................................................................................2

UNPACKING.............................................................................................................................2

HANDLING PRECAUTIONS...................................................................................................................3

FEATURES...........................................................................................................................................5

PRODUCT REGISTRATION....................................................................................................................5

REAR PANEL CONTROLS.....................................................................................................................6

RIGGING AND MOUNTING.................................................................................................................11

AVAILABLE ACCESSORIES.................................................................................................................12

WARRANTY.......................................................................................................................................13

SPECIFICATIONS.................................................................................................................................14

Produktspecifikationer

Varumärke:	Adj
Kategori:	högtalare
Modell:	ELS15 BT
Vikt:	17000 g
Bredd:	372 mm
Djup:	469 mm
Höjd:	700 mm
LED-indikatorer:	Clipping, Power
Volymkontroll:	Rotations-
Rekommenderad användning:	DJ
Impedans:	4 Ω
USB-anslutning:	Ja
Ljudutgångskanaler:	2.0 kanaler
Högtalarplacering:	Floor, Flyable, Stand-mountable
Bashögtalare:	Ja
Känslighet:	94 dB
Förstärkare:	Inbyggd
Ingångskänslighet:	500 mV
Diskantjustering:	Ja
Ljudtrycksnivå (max):	114 dB
Förstärkarklass:	A/B
Högtalarposition:	Framsida
Produktens färg:	Svart
Inbyggd kortläsare:	Ja
Uteffekt (RMS):	- W
AC-inspänning:	115 - 230 V
Frekvensområde:	50 - 20 hz
Anslutningsteknologi:	Kabel & Trådlös
Strömkälla av typen:	AC, Battery
Strömingång:	Ja
XLR-ingång:	Ja
RCA-ljudingångar:	1
Woofer diameter:	381 mm
Växelström Frekvens:	50 - 60 hz
På / av-knapp:	Ja
Woofer diameter (imperial):	15 "
Bluetooth:	Ja
Uttag för mikrofon/linje in:	Ja
Högtalartyp:	2-vägs
Basnivåkontroll:	Ja
Linje in:	Ja
Övergångsfrekvens:	2100 hz
