User Manual

Technical Specifications

Power Input ................................................................ AC 120V~60Hz, 10 A max.

Channel Output ..................................................................................... 10 A max.

DMX OUTPUT................................................................ 3-pin XLR female socket

DMX INPUT........................................................................ 3-pin XLR male socket

Fuse Type.............................................................................. F10A 250V 5x20mm

Dimensions ............................................7.17L x 3.62W x 2.56H (182x92x65mm)

Weight ............................................................................................2.5lbs. (1.1 Kg)

Features

Thank you for purchasing the Uni pak-II hybrid dimmer/switch pack.

This product includes the following features:

Every effort has been made to design dependable and reliable products. New

products are constantly being designed to meet the needs of the entertainment

lighting industry. Your comments regarding our products and services are welcome.

Please send us an e-mail to info@elationlighting.com and let us know how we

can improve to better serve you.

It’s both a privilege and a pleasure serving you.

1 channel hybrid pack with dual Edison output sockets.

Pack is user assignable between Dimmer & Switch modes.

10 Amp Maximum output.

On board control fader allows for dim intensity adjustment, from 0-100%.

External control fader allows for dim intensity adjustment, from 0-100%.

4 digit segment display shows current activity and function state.

3-pin standard DMX IN/OUT ports.

Installation / Mounting

The Uni pak-II was designed to be mounted on a truss rig or ceiling. It is

recommended that you use a suitable mounting clamp and safety cable when

mounting to any structure. There are two holes on the Uni pak-II. These are in

place for a mounting clamp or to fasten to a wall or ceiling. For cooling purposes,

it is necessary to mount the pack so that air is free to circulate around the dimmer.

There should be at least 12 inches of clearance between the pack and anything

surrounding it.

Connections

The Uni pak-II is supplied with a single 10 Amp Edison plug attached to a 16 gauge

line cord. This cord should be connected to a service capable of suppling

at least 10 amps and be protected by a properly sized circuit breaker. Lamp loads

should be plugged into to the dual 10 Amp Edison sockets which are supplied on

the face of the pack. 3 pin XLR’s are supplied for the input and output of the data

link. Connect out of the console or previous fixture in line and into the input of

the Uni pak-II. Connect out of the Uni pak-II and into the input of next pack or

fixture in line. It is recommended that the last pack or fixture in line include a DMX

terminator into the output. A DMX terminator consists of a 120 ohm, 1/4 watt

resistor soldered across pins 2 & 3 of a 3 pin XLR connector.

Installation, Mounting and Connections
