Sida 1/26

User Manual

DSD-5028 Series

28" Industrial Stretched Signage

Display Monitor

DSD-5028 User Manual ii

Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right to

make improvements in the products described in this manual at any time without

notice. No part of this manual may be reproduced, copied, translated or transmitted

in any form or by any means without the prior written permission of Advantech Co.,

Ltd. Information provided in this manual is intended to be accurate and reliable. How-

ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-

ments of the rights of third parties, which may result from its use.

Acknowledgements

Intel

and Pentium

are trademarks of Intel

Corporation.

Microsoft

Windows

and MS-DOS

are registered trademarks of Microsoft

Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants to you, the original purchaser, that each of its products will be

free from defects in materials and workmanship for two years from the date of pur-

chase.

This warranty does not apply to any products which have been repaired or altered by

persons other than repair personnel authorized by Advantech, or which have been

subject to misuse, abuse, accident or improper installation. Advantech assumes no

liability under the terms of this warranty as a consequence of such events.

Because of Advantech’s high quality-control standards and rigorous testing, most of

our customers never need to use our repair service. If an Advantech product is defec-

tive, it will be repaired or replaced at no charge during the warranty period. For out-

of-warranty repairs, you will be billed according to the cost of replacement materials,

service time and freight. Please consult your dealer for more details.

If you think you have a defective product, follow these steps:

1. Collect all the information about the problem encountered. (For example, CPU

speed, Advantech products used, other hardware and software used, etc.) Note

anything abnormal and list any onscreen messages you get when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any helpful information readily available.

3. If your product is diagnosed as defective, obtain an RMA (return merchandize

authorization) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully-completed Repair and Replacement

Order Card and a photocopy proof of purchase date (such as your sales receipt)

in a shippable container. A product returned without proof of the purchase date

is not eligible for warranty service.

5. Write the RMA number visibly on the outside of the package and ship it prepaid

to your dealer.

Part Number: 2006502800 Edition 1

Printed in Taiwan August 2014

Produktspecifikationer

Varumärke:	Advantech
Kategori:	bildskärm
Modell:	DSD-5028
Vikt:	3000 g
Bredd:	736.6 mm
Djup:	44.4 mm
Höjd:	167.3 mm
Förpackningens bredd:	870 mm
Skärm diagonal:	28 "
Upplösning:	1920 x 358 pixlar
Ljusstyrka:	700 cd/m²
Antal färger:	16,78 miljoner färger
DVI-port:	Ja
Datorsystem:	Nej
VGA (D-Sub) ingångsportar:	1
Produktdesign:	Interaktiv plattskärm
Produktens färg:	Svart
Betraktningsvinkel (horisontell):	178 °
Skärmtyp:	LCD
VESA-fäste:	Ja
Låddjup:	265 mm
Vikt inkl. förpackning:	6700 g
Strömförbrukning (vanlig):	40 W
Temperatur vid drift:	0 - 45 ° C
Temperaturintervall (förvaring):	-10 - 60 ° C
Intervall för relativ operativ luftfuktighet:	0 - 80 %
Fuktighet (förvaring):	0 - 80 %
RS-232-gränssnitt:	Ja
USB-port:	Nej
Strömförbrukning i vänteläge:	3 W
Kontrastförhållande (medel):	3000:1
Ändamål:	Universal
Svarstid (medel):	6.5 ms
Synfältsvinkel (vertikal):	178 °
Antal DVI-D anslutningar:	1
Gränsssnitt för panelmontering:	200 x 100 mm
Ljudingång (vänster och höger):	1
Bildpunktavstånd:	- mm
Funktionell livslängd:	50000 h
