Advantech DSD-5038 Bruksanvisning

Advantech bildskärm DSD-5038

Läs gratis den bruksanvisning för Advantech DSD-5038 (26 sidor) i kategorin bildskärm. Guiden har ansetts hjälpsam av 2 personer och har ett genomsnittsbetyg på 4.7 stjärnor baserat på 1.5 recensioner. Har du en fråga om Advantech DSD-5038 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/26

User Manual

DSD-5038 Series

38" Industrial Stretched Signage

Display Monitor

DSD-5038 User Manual ii

The documentation and the software included with this product are copyrighted 2014

by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right

to improve the products described in this manual at any time without notice. No part

of this manual may be reproduced, copied, translated or transmitted in any form or by

any means without prior written permission from Advantech Co., Ltd. The information

provided in this manual is intended to be accurate and reliable. However, Advantech

Co., Ltd. assumes no responsibility for its use, nor for any infringements of the rights

of third parties that may result from its use.

Acknowledgements

Intel

and Pentium

are trademarks of Intel

Corporation.

Microsoft

Windows

and MS-DOS

are registered trademarks of Microsoft

Corp.

All other product names or trademarks are properties of their respective owners.

Product Warranty (2 years)

Advantech warrants the original purchaser that each of its products will be free from

defects in materials and workmanship for two years from the date of purchase.

This warranty does not apply to any products that have been repaired or altered by

persons other than repair personnel authorized by Advantech, or products that have

been subject to misuse, abuse, accident or improper installation. Advantech

assumes no liability under the terms of this warranty as a consequence of such

events.

Because of Advantech’s high quality-control standards and rigorous testing, most

customers never need to use our repair service. If an Advantech product is defective,

it will be repaired or replaced at no charge during the warranty period. For out-of-war-

ranty repairs, customers are billed according to the cost of replacement materials,

service time, and freight. Please consult your dealer for more details.

If you believe that your product is defective, please follow the steps listed below:

1. Collect all information about the problem encountered (for example, CPU

speed, Advantech products used, other hardware and software used, etc.). Note

anything abnormal and list all onscreen messages displayed when the problem

occurs.

2. Call your dealer and describe the problem. Please have your manual, product,

and any relevant information to hand.

3. If your product is diagnosed as defective, obtain an return merchandize authori-

zation (RMA) number from your dealer. This allows us to process your return

more quickly.

4. Carefully pack the defective product, a fully completed Repair and Replacement

Order Card and proof of the purchase date (such as a photocopy of your sales

receipt) in a shippable container. Products returned without a proof of purchase

date are not eligible for warranty service.

5. Write the RMA number clearly on the outside of the package and ship the prod-

uct prepaid to your dealer.

Part Number: 2006503800 Edition 1

Printed in Taiwan August 2014

Produktspecifikationer

Varumärke:	Advantech
Kategori:	bildskärm
Modell:	DSD-5038
Vikt:	6400 g
Bredd:	980.9 mm
Djup:	44.4 mm
Höjd:	303.2 mm
Förpackningens bredd:	1152 mm
Skärm diagonal:	38 "
Upplösning:	1920 x 538 pixlar
Pekskärm:	Nej
Ljusstyrka:	800 cd/m²
Antal färger:	16,78 miljoner färger
DVI-port:	Ja
Certifiering:	FCC, CE
VGA (D-Sub) ingångsportar:	1
Produktdesign:	Platt skärm för digital skyltning
Produktens färg:	Svart
Betraktningsvinkel (horisontell):	176 °
Skärmtyp:	LED
VESA-fäste:	Ja
Låddjup:	180 mm
Vikt inkl. förpackning:	10400 g
Windows-operativsystem som stöds:	Ja
Strömförbrukning (vanlig):	76 W
Temperatur vid drift:	0 - 50 ° C
Temperaturintervall (förvaring):	-10 - 60 ° C
Hållbarhetscertifiering:	RoHS
AC-inspänning:	100 - 240 V
Kabel inkluderad:	DVI, HDMI-DVI
Nätverksansluten (Ethernet):	Nej
USB-port:	Nej
Strömförbrukning i vänteläge:	3 W
Kontrastförhållande (medel):	4000:1
Harmonized System (HS)-kod:	85285210
Svarstid (medel):	9.5 ms
Synfältsvinkel (vertikal):	176 °
Antal DVI-D anslutningar:	1
Gränsssnitt för panelmontering:	200 x 100 mm
Skärmgränssnitt (OSD):	Ja
Bildpunktavstånd:	- mm
Funktionell livslängd:	50000 h
