SQFlash

2.5” SSD 640

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.4 Page 1 of 24 Jun. 20, 2019

2.5” SSD 640

Datasheet

(SQF-S25x-xxx-SBx)

SQFlash

2.5” SSD 640

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.4 Page 2 of 24 Jun. 20, 2019

CONTENTS

1. Overview ............................................................................................ 4

2. Features ............................................................................................. 5

3. Specification Table ............................................................................ 6

4. General Description .......................................................................... 8

5. Pin Assignment and Description ................................................... 11

5.1

2.5” SATA-SSD Interface Pin Assignments (Signal Segment) ....................................... 11

5.2

2.5” SATA-SSD Interface Pin Assignments (Power Segment) ....................................... 11

6. Identify Device Data ........................................................................ 12

7. ATA Command Set .......................................................................... 15

8. System Power Consumption ......................................................... 21

8.1

Supply Voltage .............................................................................................................. 21

8.2

Power Consumption ...................................................................................................... 21

9. Physical Dimension ........................................................................ 22

Appendix: Part Number Table ........................................................... 23

SQFlash

2.5” SSD 640

Specifications subject to change without notice, contact your sales representatives for the most update information.

REV 1.4 Page 3 of 24 Jun. 20, 2019

Revision History

Rev.

Date

History

0.1

2017/2/18

1. Preliminary

0.2

2017/2/26

1. Update performance

0.3

2017/5/17

1. Update performance, endurance, and power consumption

0.4

2017/11/13

1. Update power consumption and PN

0.5

2017/12/22

1. Add 3D NAND configuration solution

0.6

2018/1/22

1. Modify information for 3D NAND (BiCS3)

0.7

2018/3/3

1. Add 3D NAND information

0.8

2018/3/28

1. Update MLC/UMLC TBW information

0.9

2018/6/11

1. Update 3D NAND information

1.0

2018/6/18

1. Add 64GB MLC 4CH information

1.1

2018/10/30

1. Revise PN information

1.2

2018/12/28

1. Update OP temp description

1.3

2019/1/21

1. Update Performance data

1.4

2019/6/20

1. Update product list

Advantech reserves the right to make changes without further notice to any products or data herein to improve reliability, function, or

design. Information furnished by Advantech is believed to be accurate and reliable. However, Advantech does not assure any liability

arising out of the application or use of this information, nor the application or use of any product or circuit described herein, neither

does it convey any license under its patent rights nor the rights of others.

Produktspecifikationer

Varumärke:	Advantech
Kategori:	Solid State-enheter (ssd)
Modell:	SQF-S25U2-16G-SBE
Bredd:	69.85 mm
Djup:	100.1 mm
Höjd:	7 mm
Gränssnitt:	Serial ATA III
Läshastighet:	355.83 MB/s
Skrivhastighet:	165.92 MB/s
Dataöverföringshastighet:	6 Gbit/s
bruksanvisning:	Ja
Skyddsfunktioner:	Shock resistant, Vibration proof
Temperatur vid drift:	-40 - 85 ° C
Solid-state drive kapacitet:	16 GB
Stötar vid drift:	1500 G
ECC:	Ja
SSD-diskens formfaktor:	2.5"
Slumpvis läsning (4 kB):	36957 IOPS
Random skrivning (4KB):	40056 IOPS
Vibrationer vid drift:	20 G
