Sida 1/60
User Manual
UNO-238 電腦
Intel® Whiskey Lake processor
IoT Edge Computer, with 2x LAN,
2x COM, 4x USB, 1x DP, 1x HDMI,
1x GPIO, 1x Audio, 2x M.2
申請商: 研華股份有限公
地址:台北市內湖區瑞光路 26 巷20 弄 1 號
電話:02-27927818
UNO-238 User Manual ii
Copyright
The documentation and the software included with this product are copyrighted 2021
by Advantech Co., Ltd. All rights are reserved. Advantech Co., Ltd. reserves the right
to make improvements in the products described in this manual at any time without
notice. No part of this manual may be reproduced, copied, translated or transmitted
in any form or by any means without the prior written permission of Advantech Co.,
Ltd. Information provided in this manual is intended to be accurate and reliable. How-
ever, Advantech Co., Ltd. assumes no responsibility for its use, nor for any infringe-
ments of the rights of third parties, which may result from its use.
Acknowledgments
IBM, PC/AT, PS/2 and VGA are trademarks of International Business Machines Cor-
poration.
Intel Core™ and Atom™ are trademarks of Intel Corporation
Microsoft Windows and MS-DOS are registered trademarks of Microsoft Corp.
All other product names or trademarks are properties of their respective owners.
Support
For more information on this and other Advantech products, please visit our websites
at: http://www.advantech.com
For technical support and service, please visit our support website at:
http://support.advantech.com/
This manual applies to the below model which is abbreviated as UNO-238 products
in this article
*Model name UNO-238
*Part number:
UNO-238-83N1AE
UNO23883N2001-T, UNO23883N2002-T, UNO23883N2101-T,
UNO23883N2102-T, UNO23883N2103-T, UNO23883N2104-T,
UNO23883N2201-T, UNO23883N2202-T, UNO23883N2203-T,
UNO23883N2204-T, UNO23883N2301-T, UNO23883N2302-T,
UNO23883N2303-T, UNO23883N2304-T, UNO23883N2401-T,
UNO23883N2402-T, UNO23883N2403-T, UNO23883N2404-T,
UNO23883N2501-T, UNO23883N2502-T, UNO23883N2503-T,
UNO23883N2504-T, UNO23883N2601-T, UNO23883N2602-T,
UNO23883N2603-T, UNO23883N2604-T
Part Number. 2003023800 Edition 1
Printed in China March 2021
iii UNO-238 User Manual
UNO-238-85N1AE
UNO23885N2001-T, UNO23885N2002-T, UNO23885N2101-T,
UNO23885N2102-T, UNO23885N2103-T, UNO23885N2104-T,
UNO23885N2201-T, UNO23885N2202-T, UNO23885N2203-T,
UNO23885N2204-T, UNO23885N2301-T, UNO23885N2302-T,
UNO23885N2303-T, UNO23885N2304-T, UNO23885N2401-T,
UNO23885N2402-T, UNO23885N2403-T, UNO23885N2404-T,
UNO23885N2501-T, UNO23885N2502-T, UNO23885N2503-T,
UNO23885N2504-T, UNO23885N2601-T, UNO23885N2602-T,
UNO23885N2603-T, UNO23885N2604-T
UNO-238-87N1AE
UNO23887N2001-T, UNO23887N2002-T, UNO23887N2101-T,
UNO23887N2102-T, UNO23887N2103-T, UNO23887N2104-T,
UNO23887N2201-T, UNO23887N2202-T, UNO23887N2203-T,
UNO23887N2204-T, UNO23887N2301-T, UNO23887N2302-T,
UNO23887N2303-T, UNO23887N2304-T, UNO23887N2401-T,
UNO23887N2402-T, UNO23887N2403-T, UNO23887N2404-T,
UNO23887N2501-T, UNO23887N2502-T, UNO23887N2503-T,
UNO23887N2504-T, UNO23887N2601-T, UNO23887N2602-T,
UNO23887N2603-T, UNO23887N2604-T
UNO-238 User Manual iv
限用物質含有情況標示聲明書
Declaration of the Presence Condition of the Restricted Substances Marking
設備名稱:電腦 型號 (型式)UNO-238 ( 系列型號請參見手冊載明型號)
Equipment name Type designation (Type)
單元 Unit
限用物質及其化學符號
Restricted substances and its chemical symbols
Lead
(Pb)
Mercury
(Hg)
Cadmium
(Cd)
六價鉻
Hexavalent
chromium
(Cr
+6
)
多溴聯苯
Polybrominat
ed biphenyls
(PBB)
多溴二苯醚
Polybrominated
diphenyl ethers
(PBDE)
電路板
內外殼
( 外殼、內部
框架 )
其它固定組件
( 螺絲、夾
具、卡榫 )
配件 ( 排線、
傳輸線、網路
)
電源供應器
備考 1.“ 超出 0.1 wt %” 超出 0.01 wt %” 係指限用物質之百分比含量超出百分比含
量基準值。
Note 1. “Exceeding 0.1 wt %” and “exceeding 0.01 wt %” indicate that the percentage
content of the restricted substance exceeds the reference percentage value of presence
condition.
備考 2.“ 係指該項限用物質之百分比含量未超出百分比含量基準值。
Note 2. ”indicates that the percentage content of the restricted substance does not
exceed the percentage of reference value of presence.
備考 3.“ 係指該項限用物質為排除項目。
Not
e 3. The ” indicates that the restricted substance corresponds to the exemption.
v UNO-238 User Manual
Product Warranty (2 years)
Advantech warrants the original purchaser that all of its products will be free from
defects in materials and workmanship for two years from the date of purchase.
This warranty does not apply to any products that have been repaired or altered by
persons other than repair personnel authorized by Advantech, or products that have
been subject to misuse, abuse, accident, or improper installation. Advantech
assumes no liability under the terms of this warranty as a consequence of such
events.
Because of Advantech's high quality-control standards and rigorous testing, most
customers never need to use our repair service. If an Advantech product is defective,
it will be repaired or replaced at no charge during the warranty period. For out-of-war-
ranty repairs, customers are billed according to the cost of replacement materials,
service time, and freight. Please consult your dealer for more details.
If you suspect that your product is defective product, follow the steps outlined below.
1. Collect all the information about the problem encountered (for example, CPU
speed, Advantech products used, other hardware and software used, etc.). Note
anything abnormal and list any onscreen messages displayed when the prob-
lem occurs.
2. Call your dealer and describe the problem. Please have your manual, product,
and any helpful information readily available.
3. If your product is diagnosed as defective, obtain a return merchandize authori-
zation (RMA) number from your dealer. This allows us to process your return
more quickly.
4. Carefully pack the defective product, a completed Repair and Replacement
Order Card, and a proof of purchase date (such as a photocopy of your sales
receipt) into a shippable container. Products returned without a proof of pur-
chase date are not eligible for warranty service.
5. Write the RMA number clearly on the outside of the packaging, and ship the
package prepaid to your dealer.
Declaration of Conformity
CE
This product has passed the CE test for environmental specifications when shielded
cables are used for external wiring. We recommend the use of shielded cables. This
type of cable is available from Advantech. Please contact your local supplier for
ordering information.
FCC Class A
This equipment has been tested and found to comply with the limits for a Class A dig-
ital device, pursuant to part 15 of the FCC Rules. These limits are designed to pro-
vide reasonable protection against harmful interference when the equipment is oper-
ated in a commercial environment. This equipment generates, uses, and can radiate
radio frequency energy and, if not installed and used in accordance with the instruc-
tion manual, may cause harmful interference to radio communications. Operation of
this equipment in a residential area is likely to cause harmful interference. In such
cases, users are required to correct the interference at their own expense.
警告使用者:這是甲類資訊產品,在居住的環境中使用時, 可能會造成射頻干擾,在
這種情況下,使用者會被要求採取某些適當對策。
UNO-238 User Manual vi
Technical Support and Assistance
1. Visit the Advantech web site at support.advantech.com/ where you can find the
latest information about the product.
2. Contact your distributor, sales representative, or Advantech's customer service
center for technical support if you need additional assistance. Please have the
following information ready before you call:
Product name and serial number
Description of your peripheral attachments
Description of your software (operating system, version, application software,
etc.)
A complete description of the problem
The exact wording of any error messages
Safety Precaution - Static Electricity
Follow these simple precautions to protect yourself from harm and the products from
damage.
To avoid electrical shock, always disconnect the power from your PC chassis
before you work on it. Don't touch any components on the CPU card or other
cards while the PC is on.
Disconnect power before making any configuration changes. The sudden rush
of power as you connect a jumper or install a card may damage sensitive elec-
tronic components.
Safety Instructions
1. Read these safety instructions carefully.
2. Retain this user manual for future reference.
3. Disconnect this equipment from any AC outlet before cleaning. Use a damp
cloth for cleaning. Do not use liquid or spray detergents.
4. For plug-gable equipment, the power outlet socket should be located near the
equipment and easily accessible.
5. Protect the equipment from humidity.
6. Place the equipment on a reliable surface during installation. Dropping or letting
the equipment fall may cause damage.
7. The openings on the enclosure are for air convection. Protect the equipment
from overheating. Do not cover the openings.
8. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet.
9. Position the power cord away from high-traffic areas. Do not place anything over
the power cord.
10. All cautions and warnings on the equipment should be noted.
11. If the equipment is not used for a long time, disconnect it from the power source
to avoid damage from transient overvoltage.
12. Never pour liquid into an opening. This may cause fire or electrical shock.
13. Never open the equipment. For safety reasons, the equipment should be
opened only by qualified service personnel.
14. If one of the following occurs, have the equipment checked by service person-
nel:
The power cord or plug is damaged.
vii UNO-238 User Manual
Liquid has penetrated into the equipment.
The equipment has been exposed to moisture.
The equipment does not work well, or you cannot get it to work according to the
user's manual.
The equipment has been dropped and damaged.
The equipment has obvious signs of breakage.
15. DO NOT LEAVE THIS EQUIPMENT IN AN ENVIRONMENT WHERE THE
STORAGE TEMPERATURE MAY GO BELOW -20° C (-4° F) OR ABOVE 60° C
(140° F). THIS COULD DAMAGE THE EQUIPMENT. THE EQUIPMENT
SHOULD BE IN A CONTROLLED ENVIRONMENT
16. CAUTION: DANGER OF EXPLOSION IF BATTERY IS INCORRECTLY
REPLACED. REPLACE ONLY WITH THE SAME OR EQUIVALENT TYPE
RECOMMENDED BY THE MANUFACTURER, DISCARD USED BATTERIES
ACCORDING TO THE MANUFACTURER'S INSTRUCTIONS.
17. In accordance with IEC 704-1:1982 specifications, the sound pressure level at
the operator's position does not exceed 70 dB (A).
18. This product is intended to be supplied by an UL certified power supply or dc
source with ES1 output, rated 12 Vdc, 4.5A minimum and Tma 60 degree. If
you need further assistance, please contact Advantech for further information.
19. Ensure that the voltage of the power source is correct before connecting the
equipment to a power outlet. The power outlet socket should have a grounded
connection.
20. For use in pollution free environments and indoor use.
21. This equipment is not suitable for use in locations where children are likely to be
present.
22. If the equipment is used in a manner not specified by the Advantech, the protec-
tion provided by the equipment may be impaired.
23. The equipment contains no user-serviceable parts. Do not open, Return to man-
ufacturer for servicing.
24. Do not block air ventilation holes.
25. This is open type equipment and should be installed in a suitable enclosure.
DISCLAIMER: This set of instructions is given according to IEC 704-1. Advantech
disclaims all responsibility for the accuracy of any statements contained herein.
Consignes de sécurité
1. Lire attentivement les instructions de sécurité.
2. Conserver ce manuel pour utilisation ultérieure,
3. Débranchez cet équipement de toute prise secteur avant de le nettoyer. Utilisez
seulement un chiffon humide. N'utilisez pas de détergent liquide ou pulvérisé
pour le nettoyage.
4. Gardez cet équipement à l'abri de l'humidité.
5. Placez cet équipement sur une surface fiable pendant l'installation. Le faire ou
bien le laisser tomber peut causer des dégâts.
6. Les ouvertures sur l'enceinte servent à la convection de l'air. Protégez l'équipe-
ment contre la surchauffe. NE COUVREZ PAS LES OUVERTURES.
7. Assurez-vous que la tension de la source d'alimentation est correcte avant de
connecter l'équipement à l'alimentation.
8. Placez le câble d'alimentation de manière à ce que personne ne puisse marcher
dessus. Ne placez rien sur le câble d'alimentation.
9. Toutes les mises en garde et tous les avertissements sur l'équipement doivent
être notés.
UNO-238 User Manual viii
10. Si l'équipement n'est pas utilisé pendant une longue période, débranchez-le de
la source d'alimentation pour éviter tout endommagement dû à une surtension
transitoire.
11. Ne jamais verser de liquide dans une ouverture. Cela pourrait provoquer un
incendie ou un choc électrique.
12. N'ouvrez jamais l'équipement. Pour des raisons de sécurité, l'équipement doit
être ouvert uniquement par du personnel qualifié.
13. Si l'une des situations suivantes se présente, faites vérifier l'équipement par le
personnel de service:
Un liquide a pénétré dans l'équipement.
L'équipement a été exposé à l'humidité.
L'équipement ne fonctionne pas bien, ou vous ne pouvez pas le faire fonction-
ner selon le manuel de l'utilisateur.
L'équipement est tombé et endommagé.
L'équipement présente des signes évidents de rupture.
14. NE LAISSEZ PAS CET ÉQUIPEMENT DANS UN ENVIRONNEMENT OU LA
TEMPÉRATURE DE STOCKAGE PEUT ÊTRE INFÉRIEURE À -20 ° C (-4 ° F)
OU BIEN SUPÉRIEURE À 60 ° C (140 ° F). CECI POURRAIT ENDOMMAGER
L'EQUIPEMENT. L'ÉQUIPEMENT DEVRAIT ÊTRE DANS UN ENVIRONNE-
MENT CONTRÔLÉ.
15. Ce produit est destiné à être alimenté par une source d'alimentation certifiée UL
ou par une source cc convenant à une utilisation à une température minimale
de 60 degrés Celsius, dont la sortie est conforme à la norme ES1 et dont la
puissance nominale est de 12 Vdc, 4.5 A, en cas de besoin. contactez Advant-
ech pour plus d'informations.
16. Pour une utilisation dans des environnements non polluant et à l'intérieur.
17. C'est appareil ne doit pas être utilisé dans des endroits où se trouvent des
enfants.
18. Si l'équipement est utilisé d'une manière non spécifiée par le fabricant, la pro-
tection fournie par l'équipement peut être altéré
19. L'équipement ne contient aucune pce réparable par l'utilisateur. Ne pas ouvrir,
retourner au fabricant pour réparation.
20. Ne bloquez pas les ou es de ventilation.
21. Il s'agit d'un équipement de type ouvert et doit être installé dans un boîtier
approprié
ATTENTION: Danger d'explosion si la batterie est mal remplace. Remplacer unique-
ment par le meme type ou equivalent recommandé par le fabricant. Jeter les piles
usagées selon les instructions du fabricant.
ix UNO-238 User Manual
安全指示
1. 請仔細閱讀此安全操作說明。
2. 請妥善保存此用戶手冊供日後參考。
3. 用濕抹布清洗設備前,請確認拔除電源線。請勿使用液體或去污噴霧劑清洗設
備。
4. 對於使用電源線的設備,設備周圍必須有容易接觸到的電源插座。
5. 請勿在潮濕環境中使用設備。
6. 請在安裝前確保設備放置在可靠的平面上,意外摔落可能會導致設備損壞。
7. 設備機殼的開孔適用於空氣對,從而防止設備過熱。請勿覆蓋開孔。
8. 當您連接設備到電源插座前,請確認電源插座的電壓符合要求。
9. 請將電源線佈置在人們不易絆倒的位置,請勿在電源線上覆蓋任何雜物。
10. 請注意設備上所有的警告標示。
11. 如果長時間不使用設備,請拔除與電源插座的連結,避免設備被超標的電壓波動
損壞。
12. 請勿讓任何液體流入通風口,以免引起火灾或短路。
13. 請勿自行打開設備。為了確保您的安全,請透過經認證的工程師來打開設備。
14. 如遇下列情況,請由專業人員來維修:
電源線或者插頭損壞;
設備內部有液體流入;
設備曾暴露在過於潮濕的環境中使用;
設備無法正常工作,或您無法通過用戶手冊來使其正常工作;
設備跌落或者損壞;
設備有明顯的外觀破損。
15. 請不要把設備放置在超出我們建議的溫度範圍的環境,即不要低於 -20 ℃ (-4
℉)或高於 60 ℃ (140 ℉),否則可能會損壞設備。
16. 注意:若電池更換不正確,將有爆炸危險。因此,只可以使用製造商推薦的同一
種或者同等型號的電池進行替換。請按照製造商的指示處理舊電池
17. 根據 IEC 704‐1:1982 規定,操作員所在位置音量不可高於 70 分貝。
18. 限制區域:請勿將設備安裝於限制區域使用。
19. 免責聲明:請安全訓示符合 IEC 704‐1 要求。研華公司對其內容之準確性不承
擔任何法律責任。
20. 消费者若使用电源适配器供电,则应购买配套使用获得 CCC 认证并满足标准要
求的电源适配器。
UNO-238 User Manual x
xi UNO-238 User Manual
Contents
Chapter 1 Overview...............................................1
1.1 Introduction ............................................................................................... 2
1.2 Safety Precautions.................................................................................... 2
1.3 Accessories............................................................................................... 3
1.4 Hardware Specifications ........................................................................... 3
1.4.1 General ......................................................................................... 3
1.4.2 System Hardware ......................................................................... 3
1.4.3 I/O Interfaces ................................................................................ 4
1.4.4 Environment.................................................................................. 4
1.4.5 Certification................................................................................... 4
1.5 Mechanical Specifications......................................................................... 4
1.5.1 Dimensions ................................................................................... 4
Figure 1.1 UNO-238 Dimensions................................................. 4
Chapter 2 Hardware Functionality.......................5
2.1 Introduction ............................................................................................... 6
Figure 2.1 Key components locations of UNO-238 (Top Side).... 6
Figure 2.2 Key components locations of UNO-238 (Bottom Side)
6
Table 2.1: Key components, Connectors on Board..................... 7
2.2 External I/O Connectors............................................................................ 7
Figure 2.3 Front I/O of UNO-238 ................................................ 7
Figure 2.4 Right I/O of UNO-238 ................................................ 8
Figure 2.5 Rear I/O of UNO-238.................................................. 8
2.2.1 Power Connector .......................................................................... 8
2.2.2 LAN: Ethernet Connector.............................................................. 8
2.2.3 USB Connector............................................................................. 8
2.2.4 DisplayPort Connector.................................................................. 8
2.2.5 HDMI Connector ........................................................................... 9
2.2.6 COM Connector............................................................................ 9
Table 2.2: COM Connector Pin Assignments.............................. 9
2.2.7 GPIO Connector ........................................................................... 9
Table 2.3: GPIO Connector Pin Assignments ............................. 9
2.2.8 Audio Connector ......................................................................... 10
Table 2.4: Audio Connector Pin Assignments........................... 10
2.3 Internal I/O Connector and Switch .......................................................... 10
Figure 2.6 Key components locations of UNO-238 (Top Side).. 10
Figure 2.7 Key components locations of UNO-238 (Bottom Side)
11
Table 2.5: Key components, Connectors on Board................... 11
2.3.1 M.2 Connector ............................................................................ 11
2.3.2 Nano SIM Slot............................................................................. 12
2.4 Others ..................................................................................................... 12
Figure 2.8 LED Indicator, Power Button, and Antenna Hole ..... 12
2.4.1 LED Indicators ............................................................................ 12
2.4.2 Power button............................................................................... 12
2.4.3 Antenna Hole .............................................................................. 12
Chapter 3 Initial Setup ........................................13
3.1 Chassis Grounding.................................................................................. 14
Figure 3.1 Chassis Grounding Connection................................ 14
UNO-238 User Manual xii
3.2 Connecting Power................................................................................... 14
3.3 M.2 Storage Installation (optional) .......................................................... 14
3.4 M.2 LTE/5G Module Installation (Optional)............................................. 16
3.5 M.2 WiFi Module Installation (Optional) .................................................. 19
3.6 SIM Card Installation............................................................................... 21
3.7 DDR and CPU Thermal grease Installation ............................................ 22
3.8 Din-Rail Installation Mounting ................................................................. 26
3.8.1 Din-Rail Installation..................................................................... 26
3.8.2 Wall Mount.................................................................................. 26
3.8.3 Stand Mount ............................................................................... 27
3.9 BIOS Setting ........................................................................................... 27
Appendix A System Settings/Pin Assignments.. 29
A.1 LAN: Ethernet Connector (CN11) ........................................................... 30
A.2 USB 3.2 Connector (CN22,CN23) .......................................................... 30
A.3 HDMI + DP Connector (CN15)................................................................ 31
A.4 M.2 Connector ........................................................................................ 32
A.4.1 M.2 B Key 2280/3042/3052 (CN17)............................................ 32
A.4.2 M.2 E Key 2230 (CN16).............................................................. 34
A.5 TPM 2.0 BIOS Setting............................................................................. 37
A.6 CPU Turbo mode BIOS Setting .............................................................. 38
A.7 Serial Port 1 Configuration...................................................................... 40
A.8 Serial Port 2 Configuration...................................................................... 41
A.9 GPIO Configuration................................................................................. 43
A.10 CANBus Configuration............................................................................ 44
Chapter 1
1 Overview
This chapter provides an overview
of the UNO-238 specifications.
Sections include:
Introduction
Safety precautions
Accessories
Hardware Specifications
Dimensions
3 UNO-238 User Manual
Chapter 1 Overview
1.3 Accessories
Please refer to below packing list:
UNO-238
1 x 60W power adapter (Advantech P/N: 96PSA-A60W12W7-3)
1 x Thermal grease for CPU (Advantech P/N: 2170000093-01)
1 x Earth-ground cable (Advantech P/N: 1703011001-11)
1 x Bracket for 3042/3052 LTE module (Advantech P/N: 1960098471N000)
2 x Screws for attaching 3042/3052 bracket (Advantech P/N: 1930001782)
1 x Thermal pad for NVMe/SATA storage (Advantech P/N: 1990036489N010)
1 x Thermal pad for 2nd DDR (Advantech P/N: 1990026184N010)
Quick Start Guide
Simplified Chinese manual
China RoHs sheet
Warranty card
If any of the above items are missing or damaged, contact your distributor or sales
representative immediately.
1.4 Hardware Specifications
1.4.1 General
1.4.2 System Hardware
Dimensions (W x D x H) 150 x107 x 60 mm (5.9" x 4.2" x 2.3")
Weight (Net) 1.8 kg (3.9lbs)
Mounting Stand, DIN rail (optional)
Power Requirement 12VDC
Power Consumption 31W (typical), 54W (Max)
BIOS AMI UEFI 128Mbit
Watchdog Timer Programmable 255 levels timer interval, from 1 to 255 sec
Hardware Security TPM2.0
Processor
Intel® i7-8665UE quad core, 1.7 GHz (up to 4.4 GHz)
Intel® i5-8365UE quad core, 1.6 GHz (up to 4.1 GHz)
Intel® i3-8145UE dual core, 2.2 GHz (up to 3.9 GHz)
Memory 2 socket DDR4 2400 (up to 32 GB max.)
Graphics Engine Intel® UHD Graphics 620
Ethernet 10/100/1000 Mbps (LAN1: Intel® i219; LAN2: Intel®i210-IT)
LED Indicators Power and HDD status
Storage
32GB of eMMC 5.1 (Onboard)
1 x M.2 B Key 2280 (SATA or NVMe PCIex2), shared with expan-
sion
Expansion
1 x M.2 B Key 3042/3052 (For LTE/5G module, supports USB 2.0
only), shared with storage 1 x M.2 E Key 2230 (for WiFi module,
supports PCIe and USB 2.0).
UNO-238 User Manual 4
1.4.3 I/O Interfaces
1.4.4 Environment
1.4.5 Certification
1.5 Mechanical Specifications
1.5.1 Dimensions
Figure 1.1 UNO-238 Dimensions
Serial Ports 2 x RS-232/422/485
LAN Ports
2 x 10/100/1000 Mbps IEEE 802.3u 1000BASE-T Fast Ethernet
(RJ-45)
USB Ports 4 x USB 3.2
Displays
1 x DP 1.2 (up to 4096 x 2160 @60 Hz)
1 x HDMI 1.4 (up to 4096 x 2160 @30/24 Hz)
Power Connector 1 x Lockable DC jack
Audio 1 x Line out
Others 1 x GPIO (8 bit) (CAN bus 2.0 is available upon request)
Operating Temperature*
-20 ~ 60 °C (-4 ~ 140 °F) with 0.7m/s airflow and extended tem-
perature peripherals
Storage Temperature - 40 ~ 85°C (-40 ~ 185°F)
Relative Humidity 10 ~ 95% RH @ 40 °C/104 °F, non-condensing
Shock Protection Operating, IEC 60068-2-27, 50G, half sine, 11ms
Vibration Protection Operating, IEC 60068-2-64, 3Grms, random,5 ~ 500Hz, 1hr/axis
Certification CE/FCC, CB/UL, CCC, BSMI
150.00
162.00
R2.00
R2.70
88.10
81.60
94.60
60.00
107.00
Chapter 2
2 Hardware Functionality
This chapter explains how to setup
the UNO-238's hardware functions,
including connecting peripherals
and indicators.
Sections include:
Introduction
External I/O Connector
Internal I/O Connector
LED Indicators
Reset Buttons
Antenna Hole
UNO-238 User Manual 6
2.1 Introduction
The following figure shows the locations of key components, internal and the external
connectors on motherboard of UNO-238.
Figure 2.1 Key components locations of UNO-238 (Top Side)
Figure 2.2 Key components locations of UNO-238 (Bottom Side)
SW1
CN2
CN1
CN35
CN30
CN10
CN8
CN29
J2
CN37
CN11
CN9
CN15
CN22
CN23
CN5
CN19
CN16
CN20
7 UNO-238 User Manual
Chapter 2 Hardware Functionality
2.2 External I/O Connectors
Figure 2.3 Front I/O of UNO-238
Table 2.1: Key components, Connectors on Board
Category Label Function
External
CN37 DC input Connector (Adapter)
CN11 RJ45 Connector (2 port)
CN9 COM port Connector (RS232/RS422/RS485)
CN15 HDMI and DP++ Connector
CN22 USB3.2 Connector (2 ports)
CN23 USB3.2 Connector (2 ports)
Internal
CN29 Audio Line out Connector (Convert to external I/O by cable)
CN8 Power Button Connector (Convert to external I/O by cable)
CN10
RS232/RS422/RS485 COM port Connector (Convert to
external I/O by cable)
CN30 GPIO 8bit Connector (Convert to external I/O by cable)
CN35 CANBus Connector (Convert to external I/O by cable)
CN20 Nano SIM slot Connector
CN16 M.2 Key E Connector for Wi-Fi
CN19 M.2 Key B Connector for Storage or LTE
DP1.2USB3.2
Power button
DC input
Rubber stopper HDMI 1.4
RS-232/422/485
RJ45 LAN
Chassis grounding
UNO-238 User Manual 8
Figure 2.4 Right I/O of UNO-238
Figure 2.5 Rear I/O of UNO-238
2.2.1 Power Connector
UNO-238 comes with a Lockable DC jack that carries 12 VDC external power input,
and features reversed wiring protection. Therefore, it will not cause any damage to
the system by reversed wiring of ground and power lines.
2.2.2 LAN: Ethernet Connector
UNO-238 is equipped with two Gigabit LAN controllers. (LAN1: Inte i219; LAN2:
Intel® i210-IT) that complies with IEEE 802.3u 10/100/1000 Base-T is used as the
controller chip.
2.2.3 USB Connector
UNO-238 features 4 USB ports that comply with USB 3.2 specifications. The USB
connectors support plug-and-play and hot-swapping functionality for external devices
without turning off the computer. It can also be enabled/disabled in the BIOS menu as
well.
2.2.4 DisplayPort Connector
The UNO-238 provides 1 x DP 1.2 connector for a high resolution interface up to
4096 x 2160 @ 60Hz, It also supports DP++ that is compatible with passive adapters.
Reserved antenna socket
Line-out GPIO
Reserved DIN-rail mount kit holes
Reserved antenna socket
