AK15 plus

installation guide

mark &

merch

AK15 plus

Installation Guide

Contents Page

1. Introduction 3

2. Checklist 4

3. SHC-Option 4

4. Check and inspect the Guitar 5

5. Prepare the Instrument 5

6. Woodwork 6

7. Pickup Installation 6

8. Saddle Height Adjustment 7

9. Endpin Mounting 7

10. Test Run 8

11. Battery Holder Installation 8

12. Soundhole Control and Final Assembly 9

13. Operation 9

14. Troubleshooting 10

15. Technical Specications 11

16. Terms of Warranty 12

1. Introduction

Thank you for choosing the AK15 plus pickup system.

Be assured, we have done a lot to achieve this level of performance. We

hope that it may change the way you look at things a bit.

The AK15 plus is a two source system, Piezo crystal plus electret con-

denser microphone integrated in the endpin pickup. The two levels are

pre-adjustable independently at the preamp and controlled with the

soundhole control (volume plus added microphone).

It has been a developing goal to come up with an easy to use, versatile

pickup system that captures the true sound of the instrument with a

maximum of dynamic range – even if it exceeds the dynamic range of

the instrument. The AK15 plus provides high volumes and impressive

punch combined with low noise components for best possible signal to

noise ratio. It can be used with all instruments (steel and classic) which

allow under saddle pickup installation with string spacings from 10 to

12.5 mm.

The installation is similar to all under-saddle pickup systems. The instru-

ment does not suer mechanical stress in use or during installation. There

is no soldering necessary.

Read on and have fun using your !AK15 plus

Claim

AER mark & merch and AER cannot be held responsible for any damages to your

pickup or instrument that may result from improper installation.

AER recommends installation by qualied personnel only. Your national distribu-

tor will be able to recommend someone.
