E26 door Luminaires In
Ceiling Mount - FM
120VAC 60Hz/
Page 1 of 1 R0 8061546
Model #: NOAC13MBDG
Limited Factory Warranty
AFX Inc. hereby warrants that this xture is free from defects in materials and workmanship when installed and used under normal operating conditions for a period of 5 years
from date of purchase. This warranty covers all component parts and extends only to replacement of defective xture or components; it does not cover failure due to improper
installation, misuse, mishandling or damage incurred in transit.
View shown for reference
only. Individual models may
vary.
Safety Precautions
Read all safety precautions and installation instructions carefully before installing or servicing this xture. Failure to comply with these instructions could result in potentially fatal
electric shock and/or property damage.
It is recommended that a qualied electrician perform all wiring. This xture must be wired in accordance with all national and local electrical codes.
Do not handle any energized xture or attempt to energize any xture with wet hands or while standing on a wet or damp surface or in water.
This xture is designed for use in a 120 , 60Hz circuit. VAC 50/
Make sure that the power source conforms to the requirements of the xture. (See labels on the xture housing).
To reduce the risk of electrical shock, and to assure proper operation, this xture must be adequately grounded. To accomplish proper grounding, there must be a separate ground
wire (green) contact between this xture and the ground connection of your main power supply panel.
This xture is intend neral indoor lighting in dry or damp locations. ed to be used for ge
Assembly Instructions
Step 1 Preparing for installation–
A. at fuse or circuit breaker box before installing or servicing any Disconnect electrical power
part of this xture.
B. Carefully remove the xture from the carton, remove components from hardware kit.
C. Remove mounting bracket (1) from the xture (5) by removing two side screws (6).
D. Install mounting bracket (1) to the junction box (not included) using two screws (2) to secure it.
For additional support, use pencil to mark at the slots for screws (4). Take the mounting
bracket (1) down and drill a small hole in the ceiling at each of the marked locations to see if
there is a wall stud. Where there is a wall stud, use a wood screw (4) to mount the bracket.
Where there is no stud to screw into, drill a larger hole for a drywall anchor (3). Reinstall the
mounting bracket with four screws to secure it.
Wiring All wiring must take place inside junction box (not included) –
Caution: Make sure power is o at fuse or circuit breaker box. Check power wires for damage
or scrapes. Use wire suitable for at least 90°C (194°F). Most dwellings built before 1985 Note:
have supply wire rated to 60°C. Consult a qualied electrician to ensure correct branch circuit
conductor before installing.
Step 2 Wiring xture –
A. Make all wire connections to appropriate wire. Secure with wire nuts (provided).
B. Connect the green wire from the xture to the supply power source ground wire.
C. Connect the white wire from the xture to the white (N) wire from supply power source.
D. Connect the black wire from the xture to the black (L) wire from supply power sourc e.
E. Pull on each wire lead to make sure connections are secure. Make certain Do not mix wires.
no bare wires are exposed outside of wire connectors. Tuck all connections neatly into the
junction box.
Step 3 Mounting –
A. Install xture by aligning both side holes over the mounting bracket then using two (5) (1)
screws (6 to secure it. )
Step 4 Lamping (not include–d)
A. Install A19 (E26) base type lamp under 60W max rating into socket and twist clockwise
rotation until securely snug. Repeat until all three lamps are installed.
Step 5 Restore power at fuse or circuit breaker box –
