HVWCTRL IP Controller

HVWCTRL - iPad & PC Software

Installation Manual

Video Wall SETUP

Contents

Chapter 1: APP GUIDE FOR THE HVWCIP-SERIES DEVICES.............................................2

1.1 ABOUT THIS DOCUMENT 2 ...............................................................................................................

1.2 GENERAL INSTRUCTIONS 2 .............................................................................................................

Chapter 2: OVERVIEW..........................................................................................................................3

Chapter 3: BEFORE INSTALLATION...............................................................................................4

Chapter 4: NETWORK BANDWIDTH CALCULATOR................................................................5

Chapter 5: VIDEO WALL SETUP......................................................................................................7

Chapter 6: CREATE AND CONFIGURE VIDEOWALL..............................................................8

Chapter 7: IPAD APP SETUP...........................................................................................................15

Chapter 8: ADVANCE SETTING TABS.........................................................................................18

Chapter 9: SIMPLE API COMMANDS...........................................................................................20

TABLE OF CONTENTS

APP GUIDE FOR THE HVWCIP-SERIES DEVICES

1.1 ABOUT THIS DOCUMENT

This document explains how to congure the HVWCIP-Series devices to work with an iPad App and

control PC software.

Software version: V7.0.0

Firmware version: V1.5/V5.10 (5.11)

The rmware and software versions listed in this document have been tested within the

recommended settings the units can support and are fully supported by AG Neovo.

It is recommended that users read this entire document before attempting both setup and

rmware updates and fully understand all the steps and procedures outlined in this document.

WARNING – Please make sure when using this guide for an exsiting setup all of the following

items are available:

- HVWCIP-T and HVWCIP-R with 12V 1A power supplies

- HVWCTRL IP Controller

- CAT5/6 cables

- Wireless Gigabit Router with 802.11/a/b/g/n 2.4 GHz; 5 GHz

- Network switch

- RS-232 to bare wire for phoneix RS-232 out

- 3.5mm headphones jack to bare wire (external audio)

- 6 x Ethernet (RJ45 Patch Cable 6 to 3m (10ft) or within the setup CAT5/6 cable runs)

- Wireless Gigabit Router with 802.11/a/b/g/n 2.4 GHz; 5 GHz

1.2 GENERAL INSTRUCTIONS

1. Before begining the setup guide or rmware upgrade ensure that the HVWCIP-Series unit are

2. PC Requirements-Windows

XP/ Windows Vista

/ Windows

7 (Windows

8/ Windows

10 are

available)

3. Ensure Laptop or desktop is plugged in to AC power during the update process. It is not

recommended to use battery power during the setup/upgrade. Do not unplug power from the unit

at any time during the rmware update process as this could lead to malfunctions.
