Installation Manual
To installers:
•After installation is completed, be sure to hand the
accessories to the customer.
NOTE:
•The illustrations and images used in this manual may
differ from the actual ones.
HTML manual
https://www.aip-info.net/file/manual/j/JV-1MD/JV-
1MD_INS/JV-1MD_INS_EN/content/
Table of contents
Package contents ............................................. 2
Precautions ....................................................... 2
Part names and functions ............................... 3
Wiri ng................................................................ 5
Precautions for wiring .......................................... 5
Wiring diagram and specifications ....................... 6
Before installation ............................................ 7
Precautions for installation ................................... 7
Door station mounting positions and image view
area 8.....................................................................
Mounting ........................................................... 8
JV-1MD ................................................................ 8
JV- DV................................................................ 10
JV-DVF .............................................................. 11
After installation ............................................. 11
Check after installation .......................................11
Installer settings ................................................. 12
Privacy notice ................................................. 12
Issue date: Dec. 2023 FK2966 1223 (H1.00) DL GZ 65292 Ⓐ
JVS-1V (A set including JV-1MD, JV-DV and power supply)
JVS-1F (A set including JV-1MD, JV-DVF and power supply)
JV-1MD (Hands free color video intercom master monitor station)
