Airflo AFV30 Bruksanvisning
Airflo
dammsugare
AFV30
Läs gratis den bruksanvisning för Airflo AFV30 (8 sidor) i kategorin dammsugare. Guiden har ansetts hjälpsam av 20 personer och har ett genomsnittsbetyg på 4.5 stjärnor baserat på 10.5 recensioner. Har du en fråga om Airflo AFV30 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/8
Wet & Dry Vacuum Cleaner
AFV30
INSTRUCTION MANUAL
Model
Power (W)
Voltage (V)
Rate(HZ)
AFV30
1200
220-240
50/60
Product Details
Filter assembly and disassembly
Parts
Hold the handle to
lift up the machine
Hanging wire function
You can hang the wire
for storage
Rod assembly storage
function
here for storage to
save space
Handle
Blowing function
Clips
Dust shaking function
Turn off the power,
press the dust removing
button at the bottom,
then release it quickly.
The button will go back
to its original position.
Operate it repeatedly
to shake off dust.
To connect the hose, move
the locker to the left
side and insert the hose
connector into the
suction mouth. Then,
release the locker to
make it tightly locked.
Conversely, to separate it.
Move the locker to the right side,
insert the hose connector into the
blowing mouth, then release the
locker to make it tightly locked. Move
the blowing control bar to the left for
blowing function on and to the right
for blowing function off.
Pull out the clips to open,
conversely, to lock it.
Take out the dust removing board
Twist the knob counterclockwi
se,
then take out the dust removing
board
Replace the HEPA filter
Twist the HEPA
clockwise to take it off
Install the HEPA and Dust removing board
Twist the HEPA counterclockwise to
lock, then pull out the dust
removing board. Tighten the knob.
Pull out the filter
Troubleshooting
If you still can not solve the problem, take it to a service center, not repair by yourself.
Problem
Reasons
Solutions
Vacuum
is not
working
1. The plug is not inserted tightly and
correctly.
2. The socket is switched off.
1. Insert the plug into the socket
tightly
2. Ensure that the socket is
switched on
Suction
is weak
1. The hose or tube is blocked
2. The filter is blocked
3. The machine is not fastened tightly
4. The air-out filter is blocked
5. The adjust window in the hose is
open
1. Clean up all the obstructions
in the hose or tube or filter
2. Clean or replace the filter
3. Make sure that the adjust
window is closed
1. The filters are blocked
2. The hose, rod or accessories are
blocked
1. Clean and maintain the filter
2. Get rid of all obstructions
ON / OFF switch
"O" for power turn off
" " for power turn on
Hose
Pull out the machine head
Pull out the clips to pull out
the machine head
Abnormally
loud noise
Put the rod assembly
Cleaning and Maintenance
1. Turn off the switch
“o” for OFF
“-”for ON
2.
3. Take off the hose and floor
brush
4.Pull out the head as
shown in the picture
6.Clean the tank and dry
with a soft cloth
5.Pull out the filter, wash and
dry it for next use
Protective Device
Special instructions for the protective device
When the tank is full of water, this Protective Device will
rise up. Suction power will stop but an abnormal noise may
indicate that the motor is running at a high speed. If this
happens, cut off the power immediately and pour out the
water from the tank.
When vacuum cleaner overturns or shakes excessively, the
Protective Device may not work correctly. What you should do
is to switch off the machine and turn it upright before
continuing to use the vacuum.
When the tank is full of water, the Protective Device will rise up, suction power will cut off. Pour out all
the water from the tank before resuming operation.
Raising of
water level
Operation
To avoid damages or injuries, do
not move vacuum when the clips
are unlocked.
Use wire and plug correctly
Pull out the plug when not in use
This is to avoid possible
electric shock or fire, etc.
Avoid incorrect operation
Do not put metal into the connector
of this machine (To avoid electric shock)
Do not pull the plug by the wire
Do not pull or move the machine by
pulling the hose
Please use the handle to move or
pull it
Keep the vacuum at a safe distance from fire/heat source or sunlight
To prolong your vacuum's life
Do not collect the following
as it may
cause vacuum's breakdown:
Construction rubbish / powder
Ash or any flammable material
Glass/tins/needles/toothpicks
Ropes/stockings or the like
Do not use the hose or the rod to collect dust
directly to avoid wear
Always use the floor brush or crevice nozzle etc. to
pick up dirt / water
Do not block the air-outlet
If the suction mouth is blocked, unblock it first
before using the vacuum
Use the hose carefully to avoid
damage
To avoid the motor overheating,
do not use it continuously for more
than half an hour. Also, it's time to
service the vacuum when:
The tank is full of dust / dirt
The suction mouth is blocked
The hose, rod or nozzle is blocked
Please check whether the cloth or HEPA filter is
installed before operating
Pull out the plug and put
the wire in order
IMPORTANT REMINDERS
