DR 403 USB Receiver for DAB, DAB +, DMB

User Manual

1 Introduction

1.1 About This Document

1.1.1. Foreword

Thank you for buying Albrecht DR 403. The manual will introduce Albrecht DR 403

installation and operations. It contains the software framework, the relevant

information, and quickly guides system's basic function.

The present software description is issued for the preliminary working title KOGAN,

produced by DabMate. The description is valid for the Albrecht DR 403

accordingly, until the software issue will be modified to show Albrecht DR 403

instead of Kogan.

1.1.2. Topics

Following is a general introduction to the chapters.

Chapter 1: Introduction - Provide chapters outline and the content of the software

provided on Albrecht DR 403.

Chapter 2: Getting started - Guiding how to install, uninstall and utilize DR 403.

Chapter 3: Albrecht DR 403 basics - Basic operations for listening to DAB/Internet

Radio and relevant system information.

Chapter 4: DAB guide - Introduce DAB functions and operational steps on KOGAN.

Chapter 5: Internet Radio guide - Introduce Internet Radio functions and

operational steps on KOGAN.

Chapter 6: More functions - Introduce other advanced functions, including “Screen

Mode”, “Favorites”, “My Multimedia Files”, and “Recall Last Program”

Functions.

1.1.3. Reference

N/A.

1.2. Preface

Albrecht DR 403, a multimedia digital platform which follows the DAB specification of

Eureka-147, supports digital broadcasting DAB and DMB with AAC + audio codec as

well as Internet Radio services to enrich your digital multimedia entertainment

experience. AAC + coded audio services, which are transmitted as MPEG 4 video (for

example the radio station BigFM2See with AAC + audio + video slide show can also be

received. For DAB + a later software update will be possible.

1.2.1. Accessories

The package provides the following accessories:

1. USB Digital Receiver (DR 403)

2. Installation CD (user manual is included)

3. External magnetic telescopic antenna for Band III and L Band

4. User’s quick guide

5. USB cable

1.2.2. Functions

This section provides a summary of KOGAN. The operation of follow-up steps will

be introduced in the following chapters.

1. Supports playback for audio, video, and slide show programs.

2. Supports the following bands of frequencies which can be easily adjusted on

screen and no need to re-install.

 Eureka147 Band III

 Eureka 147 China Band III

 Eureka 147 Korea Band III

 Eureka 147 L Band

 Eureka 147 Canada L Band

3. Contains over 5,000 Internet Radio stations.

4. Supports full channel scan/single channel scan in DAB Mode.

5. Supports my favorite station management.

6. Simultaneously records an audio or video program in DAB mode.

7. Easily adjusts the screen size, compact mode or full-screen playing.

8. On screen volume control.

9. Previous/Next tuning buttons to quickly switch stations.

10. Easily switches languages on screen, no need to re-install.

11. Automatically or manually checks the most up-to-update version and free

download.

1.2.3. Supported Bands for Each Country

Country Band

Australia Band III

Canada Canada L Band

China China Band III + L Band

China-Beijing China Band III

China-Shanhai L Band

Denmark Band III

France Band III + L Band

German Band III + L Band

Korea Korea Band III

New Zealand Band III

Singapore Band III

Taiwan Band III

UK Band III

1.3. System Requirement

Before installing KOGAN software, please make sure your computer fits the system

requirements of the software and hardware.

1.3.1. Hardware Requirements

 CPU : Intel Pentium IV 750MHz or above

Intel Celeron 750MHz or above

AMD Sempron K8 or above

 Memory : 256MB or above

 H.D.D. : 32MB free disk space

 USB : USB 1.1 or above

1.3.2. Software Requirements

 OS: Windows® XP SP 2 ( recommended ), Windows Vista
