Sida 1/54

www.alfatronelectronics.com

ALFATRON ELECTRONICS GmbH GERMANY

ALF HD- -12 / 20X -TC, ALF- -SD- 12 / 20X TC PTZ Tracking

Camera

User Manual

ALF HD- - -12 20X - -TC and ALF 12 20X- -SD- TC

Preface

This manual describes the functions, installation and operation principles and methods of the product in detail. Before installing

and using product, this please read it carefully.

1. Safety precautions

• During transportation, storage, installation, it is and use, necessary to prevent heavy pressure, severe

vibration, and immersion to avoid damage to the product.

• The product made shell is of organic material. Ensure product does not encounter corrosive liquid, gas, or

solid substances.

• Do rained it limit not let the product get wet or on. Do not use beyond the of temperature and humidity.

• When cleaning the lens, please use a soft dry cloth to wipe. When there is a lot of dust, please use a neutral

cleaner and wipe gently.

• Do not use a strong or corrosive detergent to avoid scratching the lens and affecting the image.

• This product has no parts that users can repair by themselves, and the damage caused by users ‘self-

disassembly does not fall within the scope of warranty.

2. Electrical safety

• The installation and use of products must strictly comply with the national and local electrical safety standards.

• Do specifications not use power adapters beyond the of the power supply, equipment otherwise the

components will will burn out and not work properly.

• In the process of using the product, we should keep enough distance -from the high power equipment, and do

a good job of lightning protection, surge protection and other protective measures when necessary.

• When the product is not in use, please disconnect the power switch and disconnect the

power adapter from the power socket.

• The product uses a DC 12V power supply, and the polarity of the power plug is as shown in

the picture.

ALF HD- - -12 20X - -TC and ALF 12 20X- -SD- TC

3. Installation Safety

• Do not rotate the the otherwise destroy cylinder of product by hand, it will the

rotating shaft of the structure.

• Installation placement and of equipment should be horizontal and stable, and

the product be picture be should not tilted, otherwise the may skewed.

• Installation ensures that there are no obstacles in the rotating range of the

platform to prevent damage to the rotating shaft of the structure.

• Do not turn on the power until all installation work is completed.

4. Magnetic Interference

• The electromagnetic field at a specific frequency may affect the local image. The

product is Class A product. Radio interference may occur in the home environment,

and users need to take appropriate measures.

If it is needed to extend the power line of the camera, extend it from terminal

1 (220V/110V) rather than terminal 2 (DC12V), otherwise it will prevent the ,

device from functioning!
