Sida 1/20

QUICKSTART GUIDE

ENGLISH ( 2 – 4 )

MANUAL DE INICIO RÁPIDO

ESPAÑOL ( 5 – 7 )

GUIDE D’UTILISATION RAPIDE

FRANÇAIS ( 8 – 10 )

GUIDA RAPIDA

ITALIANO ( 11 – 13 )

SCHNELLSTART-ANLEITUNG

DEUTSCH ( 14 – 16 )

SNELSTARTGIDS

NEDERLANDS ( 17 – 19 )

2 T K

volume

p itch x y z

oc ta ve

acco m p storetap

ph ra se latch

ana l o g m o d e l i ng s y n t h

pu sh

BOX CONTENTS

y ZEPHYR mixer

y Power adapter

y Quickstart Guide

y Safety Instructions & Warranty Information booklet

CONNECTION DIAGRAM

Power

House Speakers*

Monitors*

Keyboard*

Drum Machine*

Microphones*

Headphones* External effects rack,

compressor, etc.*

Notes:

y Microphones, monitors, amplifier, speakers, cables, etc. are not included.

y To reduce electrical hum at high gain settings, keep the mixer's power supply away from your guitar

cable and the mixer's channel inputs.

y To use an external effects rack unit, compressor, etc., use a Y-cable (1/4" stereo to two 1/4" mono) to

connect the AUX SEND "2 FX" output to the left and right inputs your external device. Connect the

outputs of your external device to the left and right AUX RETURN INPUTS.

* not included

FEATURES

1. POWER IN – Use the included power

adapter to connect the mixer to a

power outlet. While the power is

switched off, plug the power supply

into the mixer first, then plug the power

supply into a power outlet.

2. POWER SWITCH – Turns the mixer

on and off. Turn on the mixer after all

input devices have been connected

and before you turn on amplifiers.

Turn off amplifiers before you turn off

the mixer.

3. MIC INPUT – Connect a microphone

to these inputs with an XLR cable.

4. LINE INPUT * – Connect line-level

devices to these inputs with 1/4"

cables.

5. GAIN – Adjusts the channel audio

level (pre-fader and pre-EQ gain).

Adjust this so that the PEAK LED just

barely lights up during the loudest

parts of the song.

6. HI EQ (TREBLE) – Adjusts the high

(treble) frequencies of the channel.

7. MID EQ – Adjusts the mid-range

frequencies of the channel.

8. LO EQ (BASS) – Adjusts the low

(bass) frequencies of the channel.

9. AUX SEND 1 MON – Adjusts the

channel audio (pre-EQ) level that is

sent to the AUX SEND output labeled

"1 MON." You can use this to create a

custom monitor mix for yourself or

your musicians.

10. AUX SEND 2 FX – Adjusts the

channel audio (post-EQ) level that is sent to the

mixer's internal effects processor. Turn this up for the

channels that you want internal effects applied to.

You can use this to apply external effects to individual

channels.

11. CHANNEL PAN – Adjusts the (mono) channel's

position in the stereo field.

12. BALANCE (CH 3/4 & 5/6) – Adjusts the balance

between Channels 3 and 4 and Channels 5 and 6.

13. PEAK LED – The LED will flash if the signal is

clipping. If this happens, decrease the setting of the

GAIN knob or CHANNEL VOLUME knob.

14. CHANNEL VOLUME – Adjusts the audio level on the

channel.

15. AUX RETURN INPUTS ** – You can connect the

outputs of an external device to these inputs with 1/4"

mono cables. This is usually used for outboard

effects devices but can also be used like an extra input channel for synthesizers, drum machines, etc.

If your source is mono, plug it into the left jack and it will be heard on both the left and right sides.

16. AUX SEND OUTPUTS ** – You can use a 1/4" TRS cable to connect the AUX 1 MON output to the

input of an external amplifier or active monitor to create a custom monitor mix for onstage musicians.

You can adjust this level with the AUX RETURN LEVEL knob labeled "TO AUX 1 MON." To use an

external effects rack unit, compressor, etc. with the mixer, you can use a Y-cable to connect the AUX 2

FX output to the input of your external device, then connect the outputs of the device to the AUX

RETURN INPUTS of the mixer.

* When using LINE INPUTS 3/4, 5/6 and the

AUX RETURNS:

• If only the left channel is used, the signal

will be heard in both left and right

channels and the balance will not be

adjustable.

• If only the right channel is used, the signal

will be heard in the right channel only.

** To use an external effects rack unit,

compressor, etc., use a Y-cable (1/4" stereo

to two 1/4" mono) to connect the AUX SEND

"2 FX" output to the left and right inputs your

external device. Connect the outputs of your

external device to the left and right AUX

RETURN INPUTS.

2 T K

27 28

11 12 12

4 4 15

19 19 20 20
