Sida 1/12

Power over the Ethernet

PoE Managed Midspan Solution for

Standard Network Infrastructure

Installation Guide

Models Include:

NetWay8M NetWay16M

- Eight (8) Port PoE Midspan Injector - Sixteen (16) Port PoE Midspan Injector

DOC#: NETM

Rev. 052110 More than just power.™

- 2 - NetWay8M/ NetWay16M

Overview:

Altronix NetWay8M/NetWay16M Managed Midspans provide power and pass data for PoE compliant cameras/edge devic-

es. Cameras/edge devices may be located up to 100m (328 ft.) from the NetWay unit. A NetWayXT repeater module can be

utilized to extend the distance an additional 100m (328 ft.) for a total range of up to 200m (656 ft.). A maximum range of

600m (1968 ft.) is possible using multiple repeaters, based on camera/device port requirement. NetWay Managed Midspans

are capable of supporting non-PoE compliant fixed and PTZ IP cameras utilizing NetWay1512 or NetWay3012 adapters.

NetWayM Specifications:

NetWay8M:

•Eight(8)portsofcameras/edgedevicesoverethernet(CAT5)

cable up to a distance of 100m (328 ft.) per port.

•115VAC60Hz,3amp(NetWay8M).

NetWay16M:

•Sixteen(16)portsofcameras/edgedevicesoverethernet(CAT5)

cable up to a distance of 100m (328 ft.) per port.

•115VAC60Hz,4.9amp(NetWay16M).

Common Specifications:

Agency Listings:

•UL/CULListedforInformationTechnologyEquipment

 (UL60950-1).

• ULListedforAccessControlSystems(UL294).

• CEapproved.

Power:

•UnitsuppliesPoEoutputvoltage(55V),andupto30Wmax.

full power per port. Total power: NetWay8M - 150W,

NetWay16M - 300W.

•IEEE802.3afandIEEE802.3atcompliant(PoEPlus).

•Alloutputcircuitsarepowerlimited.

•Shortcircuitprotection.

Functions:

•ProgrammblePoEshutdownforeachport.Utilizedto

reset cameras/edge devices

(see Technical Specifications pg. 5).

• PoEmanualshutdown(ForUL60950-1applications

only) . (see Technical Specifications pg. 5)

•Autodetectionandprotectionoflegacy

non-PoE cameras/edge devices.

Features:

•LANorlaptopconnectionenablesprogrammingof

PoE shutdown and port monitoring.

•Userinterface(Fig. 5, pg. 7).

•Illuminatedmasterpowerdisconnectcircuitbreaker

with manual reset (switch).

•IndividualportstatusLEDs.

•IEC320-3-wiregroundedlinecord(detachable).

•Unitcanberackorshelfmounted.

•1UrackmountchassisforuseinstandardEIA19”rack.

Accessories:

NetWay1512:

•15Wadapterfornon-PoEcompliantIPcameras.

 (ForUL60950-1applicationsonly).

NetWay3012:

•25Wadapterfornon-PoEcompliantIP

fixed or PTZ cameras.

(ForUL60950-1applicationsonly).

NetWayXT:

•PoErepeatermoduleextendsrange100m(328ft.)

 (ForUL60950-1applicationsonly).

Installation Instructions:

WiringmethodsshallbeinaccordancewiththeNationalElectricalCode(ANSI/NFPA70),localcodes,andtheauthoritieshaving

jurisdiction.

NetWayM is not intended to be connected to outside plant leads. These products are for indoor use only and must be

installed within the protected premises.

1. NetWayM .Attachmountingbracketsto unitforrackorwallmountinstallation(Figs. 8 or 9, pg. 10)

Affix rubber pads to for shelf installation NetWayM (Fig. 10, pg. 10).

2. Securetheunitinarackorplaceunitonashelfasdesired.

Note:Thefollowingfactorsshouldbetakenintoconsiderationwheninstallingtheserackmountunits:

 a.Theunitistobeinstalledinaspacewherethemaximumambienttemperaturedoesnotexceed104ºF(40ºC).

 b.Takecaretoinsurethereissufficientairflowaroundtheunitandthatobstructionsdonotimpedeit.

 c.Whenmountingunitsinrack,takecaretoavoidunevenloadingwhichcancauseahazardouscondition.

3. Setilluminatedmasterpowerdisconnectcircuitbreakertothe(OFF)position(Fig. 1g, pg. 3).

4. PlugthegroundedAClinecord(included)intotheIEC320connectoroftheNetWayMunit

(Fig. 1h, pg. 3).Plugunitintoareliableearthgroundedsocket.Whenusingmultipleunitsthesumoftheindividual

 nameplateratingsshouldnotexceedthesupplycircuitrating.DonotConnectToAReceptacleControlledByA

 Switch.

5. Connectstructuredcablesfromportmarked[IN]onNetWayMtothecorrespondinginputsofanethernetswitchor

video server .(Fig. 1b, pg. 3, Fig. 4, pg. 5)

Note:AllcablingandwiremustbeULListedand/orRecognizedwiresuitablefortheirapplication.

6. Connectstructuredcablesfromportmarked[OUT]onNetWayMtoPoEcompliantcamera/edge

devices . (Fig. 1a, pg. 3, Fig. 4, pg. 5)

Note: ForUL294applications,theproductsaretobetestedaspartofacompleteAccessControlSystemandin

 accordancewithULListedAccessControlDevices.

NetWay8M/ NetWay16M - 3 -

Fig. 1

1a OUT1-8(NetWay8M),OUT1-16(NetWay16M):StructuredcabletoPoEcompliantcameras/edgedevices.

1b IN1-8(NetWay8M),IN1-16(NetWay16M):Structuredcabletoethernetswitchorvideoserver.

1c LED(s)1-8(NetWay8M),1-16(NetWay16M):PortstatusLEDs.

1d Reset:Restoresunittofactorysettings.

1e +---,PoEShutdown:Lowvoltagetriggerinput(see Technical Specifications pg. 5).

1f Ethernet:LANorlaptopconnectionenablesNetWayMprogrammingandstatusmonitoring.

AC POWER

NetWay8M & Net y16M - Rear PanelWa

NetWay8M - Front Panel

NetWay16M - Front Panel

+ PoE --

SHUTDOWN

+ PoE --

SHUTDOWN

1a 1b 1c 1d 1e 1f

1g 1h

Note: AllinterconnecteddevicesmustbeULListed.

7. UponcompletionofwiringsetilluminatedmasterpowerdisconnectcircuitbreakertotheRESET(ON)

position .(Fig. 1g, pg. 3)

8. PortstatusLEDsontheNetWayMwillinitializewhenPoEdevicesareconnectedasfollows:

 - LEDwillilluminatewhendevicesareIEEE802.3afcompliant.

 - LEDwillblinkonceandilluminatewhendevicesareIEEE802.3atcompliant(PoEPlus).

9. To utilize the PoE shutdown feature it is necessary to do the following:

a. Connect a device that will provide a low voltage trigger input (see Technical Specifications pg. 5) to terminals

  marked[+---,PoEShutdown]ontheNetWayM(Fig. 1e, pg. 2). When voltage is applied, the PoE shutdown

  enabledPoEport(s)willdroptozerovolts.Removingthelowvoltagetriggerinputatthe[+---,PoEshutdown]

terminals will allow the PoE port(s) to operate normally and supply power to PoE compliant devices. Power will

  resetinapproximately4seconds.AlthoughthereisnooutputvoltagetopowerPoEdevicesduringshutdown,data

signals may still be present on the data pair lines of the structured cable.

b. Individual ports must be programmed utilizing the user interface .(see User Interface and Programming, pgs. 6-9)

Port Status and LED Flash Codes:

Port Status Flash Codes Description

AllPortsOff SequentialLEDPortScan No devices connected

PortOff OFF LEDOFF

PortOn ON LEDON

Class4detectionPort Blinks2times Enables power to PoE devices.

Non-compliantDevice 2Hz Will prevent port from turning on.

PortOverloadFault 5Hz Will prevent port from turning on.

4PortOverloadGrouped 5Hz 4LEDs

Will prevent ports from turning on.

8PortOverloadGrouped 5Hz LED’s1-8PowerSupplyOverloadforports1-8.

LED’s9-16PowerSupplyOverloadforports9-16.
