Sida 1/8

User Instructions

Flash Panel 16 Introduction

11/10

Unpacking: Thank you for purchasing the Flash Panel 16 by Ameri-

can DJ . Every Flash Panel 16 has been thoroughly tested and has ®

been shipped in perfect operating condition. Carefully check the ship-

ping carton for damage that may have occurred during shipping. If the

carton appears to be damaged, carefully inspect your xture for any

damage and be sure all accessories necessary to operate the unit has

arrived intact. In the case damage has been found or parts are miss-

ing, please contact our toll free customer support number for further

instructions. Do not return this unit to your dealer without rst contact-

ing customer support.

Introduction: The Flash Panel 16 is part of American DJ’s continu-

ing pursuit for creating high quality affordable intelligent LED fixtures.

The Flash Panel 16 is a DMX intelligent LED Panel. This LED panel can

be controlled via DMX or via the optional CF card controller (Model:

FP CFC). Dynamic effects can be played on it, which makes it a great

system for DJ’s and night clubs. This unit can be used as a stand alone

or linked together.

Customer Support: American DJ provides a toll free customer sup-®

port line, to provide set up help and to answer any question should you

encounter problems during your set up or initial operation. You may

also visit us on the web at www.americandj.com for any comments or

suggestions. Service Hours are Monday through Friday 9:00 a.m. to

4:30 p.m. Pacic Standard Time.

Voice: (800) 322-6337

Fax: (323) 582-2941

E-mail: support@americandj.com

To purchase parts online visit http://parts.americandj.com

Warning! To prevent or reduce the risk of electrical shock or re, do

not expose this unit to rain or moisture.

Caution! There are no user serviceable parts inside this unit. Do not

attempt any repairs yourself, doing so will void your manufactures war-

ranty. In the unlikely event your unit may require service please contact

American DJ .®

PLEASE recycle the shipping carton when ever possible.

FLASH PANEL 16
