EXTENDER BODY SPRAYS

Installation

Instructions

1660.130

1660.140

1660.1301660.140

LUXURY SHOWER

Thank you for selecting American-Standard...the

benchmark of fine quality for over 100 years.

To ensure that your installation proceeds smoothly--

please read these instructions carefully before you begin.

Certified to comply with ANSI A112.18.1

ROUGHING-IN DIMENSIONS

Recommended Tools

Flat Blade Screwdriver

ALL CONNECTIONS 1/2" NPT

2-1/4" DIA.

(57mm) Hole Saw

75mm

(3")

54mm D.

(2-1/8")

35mm

(1-3/8")

57mm D.

(2-1/4")

HOLE SIZE

12mm

(1/2")

26mm

(1")

15°

FINISHED WALL

1/2" NPT

74mm D.

(2-15/16")

1660.140 Multifunction

Square Body Spray

1660.130 Multifunction

Round Body Spray

Teflon Tape

Electric Drill

(63.6-70.6mm)

2-1/2" - 2-3/4"

(75.6-82.6mm)

2-15/16" - 3-1/4"

M968617 Rev.1.4 (10/17)
