Sida 1/115

IO-HOO-0784/7

(10.2020)

Kitchen extractor hood / okap nadkuchenny /

kuchyňského odsavače / kuchynského odsávača

/ Hotă de bucătărie / tűzhely feletti páraelszívó

/ кухненски аспиратор / Korpus nape / Hotte

aspirante

OMP6552BG / OMP9552BG /

OMP6555BG / OMP6554BG /

OMP9554BG / SIO 655 BG

OPERATING INSTRUCTIONS EN

INSTRUKCJA OBSŁUGI PL

NÁVOD K OBSLUZE CS

NÁVOD NA OBSLUHU SK

INSTRUCŢIUNE DE DESERVIRE RO

HASZNÁLATI UTASÍTÁS HU

ИНСТРУКЦИЯ ЗА ОБСЛУЖВАНЕ BG

UPUTSTVO ZA UPOTREBU SR

NOTICE D’UTILISATION FR

- 3 -

NOTES ON SAFETY 7

UNPACKING 10

DISPOSAL OF OLD APPLIANCE 10

OPERATION 11

COOKER HOOD CONTROLS 11

OFF-TIMER 11

GESTURE CONTROL 12

OTHER IMPORTANT INFORMATION CONCERNING THE OPERATION OF THE HOOD 13

CLEANING AND MAINTENANCE 14

MAINTENANCE 14

GREASE FILTER 14

ACTIVATED CHARCOAL FILTER 14

LIGHT 14

WARRANTY AND AFTER SALES SERVICE 15

WARRANTY 15

EN- Table of contents

CS- Obsah

PL- Spis treści

WSKAZÓWKI DOTYCZĄCE BEZPIECZEŃSTWA 17

ROZPAKOWANIE 21

USUWANIE ZUŻYTYCH URZĄ DZEŃ 21

OBSŁUGA 22

STEROWANIE OKAPEM 22

TIMER (OPÓŹNIONE WYŁĄCZENIE OKAPU) 22

STEROWANIE GESTAMI 23

INNE WAŻNE INFORMACJE DOTYCZĄCE OBSŁUGI OKAPU 24

CZYSZCZENIE I KONSERWACJA 25

KONSERWACJA 25

FILTR PRZECIWTŁUSZCZOWY 25

FILTR WĘGLOWY 25

OŚWIETLENIE 25

GWARANCJA, OBSŁUGA POSPRZEDAŻOWA 26

GWARANCJA 26

BEZPEČNOSTNÍ POKYNY 28

VYBALENÍ 31

LIKVIDACE OPOTŘEBOVANÝCH ZAŘÍZENÍ 31

OBSLUHA 32

OVLÁDÁNÍ ODSAVAČE 32

TIMER (OPOŽDĚNÉ VYPNUTÍ ODSAVAČE) 32

OVLÁDÁNÍ GESTY 33

JINÉ DŮLEŽITÉ INFORMACE O OBSLUZE ODSAVAČE 34

ČIŠTĚNÍ A ÚDRŽBA 35

ÚDRŽBA 35

PROTITUKOVÝ FILTR 35

UHLÍKOVÝ FILTR 35

OSVĚTLENÍ 35

ZÁRUKA, POPRODEJNÍ SERVIS 36

ZÁRUKA 36

- 5 -

BG - Съдържание

ПРЕПОРЪКИ ОТНОСНО БЕЗОПАСНОСТТА 71

РАЗОПАКОВАНЕ 75

ОБЕЗВРЕЖДАНЕ НА ИЗНОСЕНИ УРЕДИ 75

ОБСЛУЖВАНЕ 76

УПРАВЛЕНИЕ НА АБСОРБАТОРА 76

ТАЙМЕР (ИЗКЛЮЧВАНЕ НА АБСОРБАТОРА СЪС ЗАКЪСНЕНИЕ) 77

УПРАВЛЕНИЕ С ЖЕСТОВЕ 77

ДРУГИ ВАЖНИ ИНФОРМАЦИИ ЗА ОБСЛУЖВАНЕТО НА АБСОРБАТОРА 79

ПОЧИСТВАНЕ И ПОДДРЪЖКА 80

ПОДДРЪЖКА 80

ФИЛТЪР ЗА МАЗНИНИ 80

ВЪГЛЕН ФИЛТЪР 80

ОСВЕТЛЕНИЕ 80

ГАРАНЦИЯ, СЛЕД ПРОДАЖБЕНО ОБСЛУЖВАНЕ 81

ГАРАНЦИЯ 81

SR- Sadržaj

BEZBEDNOSNE NAPOMENE 83

UKLANJANJE PAKOVANJA 86

ODLAGANJE ISTROŠENIH UREĐAJA 86

UPOTREBA 87

UPRAVLJANJE NAPOM 87

TAJMER (ODGOĐENO ISKLJUČENJE NAPE) 87

UPRAVLJANJE POKRETIMA 88

OSTALE VAŽNE INFORMACIJE O UPOTREBI NAPE 89

ČIŠĆENJE I ODRŽAVANJE 90

ODRŽAVANJE 90

FILTER ZA MASNOĆU 90

UGLJENI FILTER 90

OSVETLJENJE 90

GARANCIJA, USLUGE POSLE PRODAJE 91

GARANCIJA 91

FR- Table des matières

INDICATIONS CONCERNANT LA SÉCURITÉ D'UTILISATION 93

DÉBALLAGE 97

ÉLIMINATION DES APPAREILS USAGÉS 97

UTILISATION 98

COMMANDE DE LA HOTTE 98

MINUTERIE (ARRÊT DIFFÉRÉ DE LA HOTTE) 99

COMMANDE PAR LES GESTES 99

AUTRES INFORMATIONS IMPORTANTES RELATIVES À L’UTILISATION DE LA HOTTE 101

NETTOYAGE ET ENTRETIEN 102

ENTRETIEN 102

FILTRE À GRAISSE 102

FILTRE À CHARBON 102

ÉCLAIRAGE 102

GARANTIE, SERVICE APRÈS-VENTE 103

GARANTIE 103

- 6 -

Dear customer,

From now on, your daily housework will be easier

than ever before. Your appliance is excepon-

ally easy to use and extremely ecient. Aer reading

these Operang Instrucons, operang the appliance

will be easy.

Before being packaged and leaving the manufacturer,

the appliance was thoroughly checked with regard to

safety and funconality.

Before using the appliance, please carefully read

these Operang Instrucons. By following these

instrucons carefully you will be able to avoid any

problems in using the appliance. It is important to

keep these Operang Instrucons and store them in a

safe place so that they can be consulted at any me.

Follow these instrucons carefully in order to avoid

possible accidents.

Sincerely,

- 7 -

NOTES ON SAFETY

• Before using the appliance, please carefully read

this manual!

• The appliance is designed for household use only.

• The manufacturer reserves the right to introduce

changes, which do not aect operation of the ap-

pliance.

• The manufacturer shall not be liable for any dam-

age or re caused by the appliance resulting from

failure to follow instructions in this manual.

• Cooker hood is designed to remove cooking

odours. Do not use cooker hood for other pur-

poses.

• Connect the cooker hood operating in extraction

mode to a suitable ventilation duct (do NOT con-

nect the cooker to smoke or ue gas ducts, which

are in use). It requires installation of the air ex-

traction duct to the outside. The length of the

duct (usually a pipe of Ø 120 or 150 mm) should

not be longer than 4-5 m. An air extraction duct

is also required for telescopic and furniture hoods

in absorption mode.

• Cooker hood operating in air recirculation mode

requires the installation of an activated charcoal

lter. In this case, installing an extractor duct is

not required, however it is recommended to in-

stall an air guide vane (Mainly in chimney cooker

hoods).

• The cooker hood features independent lighting

and exhaust fan that can be operated at one of

several speeds.

• Depending on the type, the hood is designed to

be permanently attached to a vertical wall over

a gas or electric stove (chimney and universal

hoods); on the ceiling over a gas or electric stove

(island hoods); on the vertical built in furniture

over a gas or electric stove (telescopic and built-

in hoods). Before installing, make sure that the

- 8 -

wall/ceiling structure is strong enough to suspend

the hood. Some hoods are very heavy.

• For details of the installation distance above an

electric hob please refer to product technical

sheet If the installation instructions of the gas

cooker specify a greater distance, this must be

taken into account (Fig. 1).

• Do not leave an open ame under the hood.

When the pots are removed from the burner, set

the minimum ame. Always make sure that the

ame does not extend outside the pot, because it

causes unwanted loss of energy and a dangerous

concentration of heat.

• When cooking on fat, supervise the pans con-

stantly, because overheated fat can ignite.

• Unplug the appliance before any cleaning, replac-

ing the lter or repair work.

• Cooker hood grease lter should be cleaned at

least once a month, because the lter saturated

with fat is ammable.

• Ensure adequate ventilation (air ow) if other

equipment such as liquid fuel stoves or heaters

are operated in the room in addition the cooker

hood. When the cooker hood is simultaneously

operated with burning appliances requiring ade-

quate fresh air from the room to work properly,

their safe operation is possible if under pressure

around these appliances is a maximum of 0.004

mbar (this does not apply when the cooker hood

is used as an odour lter)

• Do not lean on the hood.

• The hood should be cleaned regularly both inside

and out (AT LEAST ONCE A MONTH, following the

indications concerning maintenance provided in

this manual)..Failure to adhere to the rules con-

cerning cleaning the hood and replacing lters

results in a re risk.

• If the power cord is damaged it should be re-

placed by a specialised service centre.

• Ensure that it is possible to disconnect the ap-

- 10 -

UNPACKING

During transportation, protective

packaging was used to protect the

appliance against any damage. Af-

ter unpacking, please dispose of all

elements of packaging in a way that

will not cause damage to the environ-

ment.

All materials used for packaging the

appliance are environmentally friendly; they are

100% recyclable and are marked with the appropri-

ate symbol.

Important! Packaging materials (bags, polyethyl-

ene, polystyrene, etc.) should be kept away from

children during unpacking.

DISPOSAL OF OLD APPLIANCE

In accordance with European Directive

2012/19/EU and local legislation re-

garding used electrical and electronic

goods, this appliance is marked with

the symbol of the crossed-out waste

container. This marking indicates that

the appliance must not be disposed of

together with other household waste

after it has been used.

The user is obliged to hand it over to waste collec-

tion centre collecting used electrical and electron-

ic goods. The collectors, including local collection

points, shops and local authority departments pro-

vide recycling schemes.

Proper handling of used electrical and electronic

goods helps avoid environmental and health haz-

ards resulting from the presence of dangerous com-

ponents and the inappropriate storage and process-

ing of such goods.

- 12 -

Gesture control

Touch to turn gesture control on/o.

You can use gestures to control the fan speed and lighting. When

gesture control is active, you can also control the appliance using the

touch sensors.

Gesture control works correctly when you move your open hand about

3 to 10 cm from the surface of the control panel.

Note: When controlling the fan speed, the hand motion must cover

both motion sensors (Figure 4, item 2, or the hand must be stationary

within the light control sensor (Figure 4, item 1).

If activating a certain function (such as fan speed 3) requires multiple

hand gestures, reposition your hand for another gesture away from the

control panel to avoid triggering the motion sensors). Hand movements

must not be too fast. Preferably, a single gesture should take about 1

second.

To turn on the fan or

increase fan speed, move

your hand from left to

right several times. With

hand movement, current

fan speed sensor will light

up.

To turn o the fan or

reduce fan speed, move

your hand from right to

left several times until

sensor 1 lights up. Move

your hand one more time

and the fan will turn o

(gesture control will still

be active)

To turn the lighting on or

o, position your hand

near the centre of the

control panel (under the

sensor labelled 1) for

about 2 seconds. The

symbol will light up.

- 13 -

Other important information concerning the operation of

the hood

Operation in air circulation / odour lter mode. In this mode, the ltered

air returns to the room through the outlets. Install activated charcoal

lter in this setting. It is recommended to install the air guide (available

depending on the model, mainly in chimney cooker hoods).

Air extraction operation: When cooker hood operates in extraction mode,

air is discharged outside through an extraction duct. Remove activated

charcoal lter in this setting. The cooker hood is connected to the air

outlet opening using a rigid or exible extraction duct with a diameter of

150 or 120 mm, and the appropriate clamps, which must be purchased

at a hardware store. The appliance should be installed by a qualied

installer.

Fan speed: Lowest and medium fan speed is used in normal conditions

and less intense odours, while the highest speed is used only when cook-

ing odours are very intense, such as during frying or grilling.

Note (applies to universal hoods only): Due to the design of universal

hoods you need to manually change the mode of operation. See Figure

8 for instructions on how to change the mode.

Note (only applies to telescopic and in-built kitchen hoods): Furniture

and telescopic cooker hoods operating in air recirculation mode require

installation of the exhaust duct. The other end of the duct should be di-

rected to the room as it will discharge ltered air.

Note: Hanging kitchen hoods operate only in air circulation / odour ab-

sorber mode

- 14 -

CLEANING AND

MAINTENANCE

Maintenance

Regular maintenance and cleaning of the appliance will ensure trou-

ble-free operation of the cooker hood and extend its life. Especially make

sure that the grease lter and activated charcoal lter are replaced ac-

cording to manufacturer's recommendations.

• Do not use a soaked cloth, sponge, or water jet.

• Do not use solvents or alcohol, as they may tarnish lacquered sur-

faces.

• Do not use caustic substances, especially for cleaning stainless steel.

• Do not use a rough or abrasive cloth.

• It is recommend to use a damp cloth and a neutral detergent.

Note: After several washes in the dishwasher, the colour of the alumini-

um lter may change. The change of colour does not indicate improprie-

ties or the necessity to change it.

Grease lter

For normal hood operation, grease lter should be cleaned every month

in the dishwasher or by hand using a mild detergent or liquid soap.

Dismantling of grease lter is shown on Figure 5.

Acrylic lter is used in some models. This lter should be replaced at

least once every two months or more frequently if the appliance is used

intensively.

Activated charcoal lter

Charcoal lter is used only when the cooker hood is not connected to

the ventilation duct. Activated charcoal lter can absorb odours until

saturated. Charcoal lter is not suitable for washing or regeneration and

should be replaced at least once every two months or more frequently if

the appliance is used intensively.

Dismantling of charcoal lter is shown on Figure 6.

Light

Use incandescent / halogen / LED modules of the same specication as

those factory-installed in the appliance. See Figure 7 for details how to

replace lights. If there is no such gure in this manual, please contact

authorised service to replace the lighting module.

- 15 -

WARRANTY AND AFTER

SALES SERVICE

Warranty

Warranty service as stated on the warranty card. The manufacturer shall

not be held liable for any damage caused by improper use of the product.

Service

• The manufacturer recommends that all repairs and adjustments be

carried out by the Factory Service Technician or the Manufacturer’s

Authorized Service Point. For safety reasons, repairs should be re-

ferred to professionals.

• Repairs carried out by unqualied persons may seriously endanger

the appliance user.

• The minimum warranty period for the appliance oered by the man-

ufacturer, importer or authorized representative is given in the war-

ranty card.

• The warranty shall be void if you make any independent adaptations

or alterations, tamper with seals or other appliance safety devices

or its parts or interfere with the appliance contrary to operating in-

structions.

In the event of appliance malfunction, request assistance or repair.

If your appliance needs repair, please contact the service centre. Please

see warranty card for address and contact details of our service centre.

Before contacting us, please have ready the appliance serial number,

which can be found on the identication sticker: For your convenience,

please write it down below:

Manufacturer’s Declaration

The manufacturer hereby declares that this product meets the re-

quirements of the following European directives:

• Low Voltage Directive 2014/35/EC

• Electromagnetic Compatibility (EMC) Directive 2014/30/EC

• ErP Directive 2009/125/EC

• Directive RoHS 2011/65/EC

and has thus been marked with the symbol and been issued with

a declaration of compliance made available to market regulators.

- 16 -

Szanowny

Kliencie

Od dziś codzienne obowiązki staną się prostsze niż

kiedykolwiek. Urządzenie to połączenie wy-

jątkowej łatwości obsługi i doskonałej efektywności.

Po przeczytaniu instrukcji, obsługa nie będzie proble-

mem.

Sprzęt, który opuścił fabrykę był dokładnie sprawdzo-

ny przed zapakowaniem pod względem bezpieczeń-

stwa i funkcjonalności na stanowiskach kontrolnych.

Prosimy Państwa o uważną lekturę instrukcji obsłu-

gi przed uruchomieniem urządzenia. Przestrzeganie

zawartych w niej wskazówek uchroni Państwa przed

niewłaściwym użytkowaniem. Instrukcję należy zacho-

wać i przechowywać tak, aby mieć ją zawsze pod ręką.

Należy dokładnie przestrzegać instrukcji obsługi

w celu uniknięcia nieszczęśliwych wypadków.

Z poważaniem

- 17 -

WSKAZÓWKI DOTYCZĄCE

BEZPIECZEŃSTWA

• Okap należy używać dopiero po przeczytaniu tej

instrukcji

• Urządzenie przeznaczone jest wyłącznie do użyt-

ku domowego.

• Producent zastrzega sobie możliwość dokonywa-

nia zmian niewpływających na działanie urządze-

nia.

• Producent nie ponosi żadnej odpowiedzialności

za ewentualne szkody lub pożary spowodowane

przez urządzenie wynikające z nieprzestrzegania

zaleceń podanych w niniejszej instrukcji.

• Okap nadkuchenny służy do usuwania oparów

kuchennych. Nie należy go używać do innych ce-

lów.

• Okap pracujący w trybie wyciągu należy podłą-

czyć do odpowiedniego kanału wentylacyjnego

(nie podłączać do kanałów kominowych, dymo-

wych lub spalinowych, będących w eksploatacji).

Okap wymaga zainstalowania przewodu odpro-

wadzającego powietrze na zewnątrz. Długość

przewodu (najczęściej rura Ø 120 mm lub 150

mm) nie powinna być dłuższa niż 4-5 m. Przewód

odprowadzający powietrze jest również wymaga-

ny przy okapach teleskopowych i meblowych w

trybie pochłaniacza.

• Okap pracujący w trybie pochłaniacza wymaga

zainstalowania ltra z węglem aktywnym. W tym

przypadku nie wymaga się instalowania przewo-

du odprowadzającego powietrze na zewnątrz, za-

leca się natomiast montaż kierownicy wydmuchu

powietrza (występuje głównie w okapach komi-

nowych).

• Okap posiada niezależne oświetlenie oraz wenty-

Produktspecifikationer

Varumärke:	Amica
Kategori:	Fläktkåpa
Modell:	SIO 655 BG
Färg på produkten:	Black, Blue, Red
Vikt:	970 g
Bredd:	205 mm
Djup:	135 mm
Höjd:	155 mm
Skärm diagonal:	7 "
Upplösning:	- Pixels
Ljudformat som stöds:	MP3
Videoformat som stöds:	MPEG4
USB uttag:	Ja
Typ av anslutningskontakt:	3,5 mm
Typ av strömkälla:	Batterij/Accu
Integrerad minneskortläsare:	Ja
Kompatibla minneskort:	MMC, SD
Hörlursutgångar:	1
Bildformat som stöds:	BMP, JPG
Displayteknik:	LCD
Typ av tuner:	Digitaal
Digitalt signalformat:	TNT
On Screen Display (OSD):	Ja
Fjärrstyrd:	Ja
Föräldratillsyn:	Ja
Fjärrkontroll ingår:	Ja
