Sida 1/27

PASSIVE MINIBOX SPEAKERS

DIFFUSORI MINIBOX PASSIVI

ENCEINTES MINIBOX PASSIVES

PASSIVE MINIBOX-LAUTSPRECHER

DIFUSORES MINIBOX PASIVOS

BBM 3BP/WP | BBM 5BP/WP | BBM 8BP/WP

EN USER MANUAL | SECTION 1

IT MANUALE D’USO | SEZIONE 1

FR NOTICE D’EMPLOI | SECTION 1

DE BEDIENUNGSANLEITUNG | KAPITEL 1

ES MANUAL DE USO | SECCIÓN 1

ENGLISH

BBM BP/WP Series | User manual

User manual | BBM BP/WP Series

1 | INTRODUCTION

Thank you for choosing a A.N.T - Advanced Native Technologies - product!

In BBM BP/WP speaker series we have put our passion and our

technological background gained over the years, to offer products that

meet your needs, maintaining the quality over time.

Specically designed for an immediate and user-friendly application, meeting

the needs of those looking for a compact constant impedance or voltage

(70-100V) audio system, providing excellent performance and the best value

for money possible in its category.

Characterized by an elegant look and compact dimensions, these speakers

are able to amplify indoors and outdoors - thanks to IP55 protection - small

and medium-sized environments. All models are available in two colors,

black (BBM BP) and white (BBM WP).

Are also available, specically engineered for BBM speakers wall or ceiling

installation, the bracket kits BBM WBU and BBM 358Y in black or white, as

well as the SA-30/50/80 black kits specic tripod mounting.

Please, dedicate some minutes to read this instruction manual in order to

quickly achieve the best performances from this product.

For safety precautions, warranty and disposal, please refer to attached

Section 2.

For further information about all A.N.T products catalog, please visit our

website: www.ant-intomusic.com.

TABLE OF CONTENTS

1 | Introduction 3

2 | Installation 4

3 | Description 5

3.1 | Inputs & controls 5

4 | Connections 6

4.1 | Constant voltage 6

4.2 | Constant impedance 7

5 | Troubleshooting 8

6 | Technical specications 9

7 | Optional accessories 10

8 | Notes 11

The warnings in this manual must be observed together with the

“USER MANUAL - SECTION 2”.

PACKAGE CONTENT

• 1x Passive minibox speaker

• 1x User manual - Section 1

• 1x User manual - Section 2

ENGLISH

BBM BP/WP Series | User manual

User manual | BBM BP/WP Series

3 | DESCRIPTION

3.1 | INPUTS & CONTROLS

1 HEADED INPUT CABLE

Connect the signal from amplier outputs to these two wires.

To ensure correct sound reproduction, the speakers must be connected

in phase. Match the positive and negative polarities of the amplier with

the positive (White +) and negative (Black -) polarity of the speaker input.

2 CABLE GLAND

The cable gland guarantees IP55 protection of electrical connections

inside the speaker.

3 SEALED POWER SELECTOR

IP55 Selector with seven positions for constant impedance (8Ω) or

constant voltage (10W, 20W, 40W or 80W on 70V or 100V) connections.

Use a flat-blade screwdriver to select the desired mode.

NOTE:

All the BBM BP/WP series speakers guarantee IP55 protection, in particular:

• Total protection against item introduction.

• Protection against liquids entry in any form like drops, vapors, sprays

and weak jets of water in any direction.

• Dust and liquids intrusion must not damage the equipment.

2 | INSTALLATION

Each speaker is equipped with:

A | Sealed power selector.

B | Headed input cable.

C | Non-slip rubber feet.

WARNING:

For installation please contact qualied personnel.

In order to avoid any danger, place and fasten the speaker in a stable and secure way.

Install the speaker as explained in this instruction manual.

WARNING:

For safe use of the accessory, check functionality and integrity before installation

and periodically.
