Congratulations on your purchase of the Antec One Hundred.

Antec’s One Hundred is the gaming case that delivers high-end features at a price that won’t break the bank. Eight

expansion slots provide exceptional expandability, and can accommodate multiple video cards. A sleek painted black

interior with clean, perforated front bezel houses your components in style, while the four top USB ports with audio

in/out and handy storage tray bring convenience and accessibility to the package. Finally, the bottom PSU mount, two

included TwoCool™ fans and washable fan filter keep your system cool and quiet.

The One Hundred does not come with a power supply unit (PSU). Make sure you choose a power supply that is

compatible with your computer components and has a long enough power harness to reach your motherboard and

peripheral devices. We recommend our High Current Gamer, High Current Pro or TruePower New power supplies for

the latest ATX specification compliance, broad compatibility, and power savings capability.

At Antec, we continually refine and improve our products to ensure the highest quality. It’s possible that your new case

will differ slightly from the descriptions in this manual. This isn’t a problem; it’s simply an improvement. As of the date

of publication, all features, descriptions, and illustrations in this manual are correct.

Disclaimer

This manual is intended only as a guide for Antec’s computer enclosures. For more comprehensive

instructions on installing the motherboard and peripherals, please refer to the user’s manuals that come with

those components.

ABLE OF

ONTENTS

SECTION 1: INTRODUCTION

1.1 Case Specifications ....................................................................................................................4

1.2 Diagram ......................................................................................................................................4

1.3 Included Screws ........................................................................................................................5

HARDWARE INSTALLATION GUIDE

2.1 Setting Up ...................................................................................................................................7

2.2 Power Supply Installation ........................................................................................................7

2.3 Motherboard Installation .........................................................................................................8

2.4 Internal 3.5” Device Installation ............................................................................................8

2.5 External 5.25” Device Installation .........................................................................................9

2.6 Internal 2.5” Device Installation ............................................................................................9

2.7 Cable Management ...................................................................................................................10

CONNECTING THE FRONT I/O PORTS

3.1 USB 2.0 .......................................................................................................................................12

3.2 AC’97 / HD Audio Ports ........................................................................................................12

3.3 Power Switch / Hard Disk Drive LED Connectors ..........................................................13

3.4 Rewiring Motherboard Header Connections .......................................................................13

COOLING SYSTEM

4.1 Included Fans ............................................................................................................................14

4.2 Optional Fans ............................................................................................................................15
