BP550 PLUS

POWER SUPPLY

USER’S MANUAL

BP550 PLUS

The BP550 PLUS is the perfect power supply for the entry-level user, providing stable power, quiet

cooling, and advanced cable management for improved airow and ease- -use. This entry-level of

soluon gives you everything you need in a power supply. No twinkly lights or gliery paint jobs –a

120 mm fan for eecve and quiet cooling, triple +12V rails for amazingly stable power, heavy-duty

protecon circuitry and Acve Power Factor Correcon (PFC) that saves money on corporate power

bills. And it comes with all the assurance of Antec’s AQ3 Antec Quality 3-year limited warranty. All the

features, none of the waste: for builders that are strictly business, the BP550 PLUS is strictly power.

STANDARDS AND FEATURES

The connectors and power specicaons of the BP550 PLUS PSU are all compable with ATX12V v2.3

specicaons. This power supply also features Acve Power Factor Correcon (PFC), which improves

the power factor value of the power supply by altering the input current wave shape, helping to power

transmission across the grid.

SYSTEM PROTECTION

A variety of industrial-grade safety circuitry will help protect your computer: Over Current Protecon

(OCP), Over Voltage Protecon (OVP) & Short Circuit Protecon (SCP). Somemes the PSU will “latch”

into a protected state. You will need to power off the PSU and clear the fault before it will funcon

again. There are no user-replaceable fuses in your BP550 PLUS.

POWER OUTPUT

To see the output capacity and regulaon for each dierent voltage, see table 1.

TABLE 1

Output Voltage

Load Max.

Regulation

Ripple & Noise

+12V

₁

22A

± 5%

< 200 mV

+12V

₂

22A

± 5%

< 200 mV

+12V3

25A

± 5%

< 200 mV

+3.3V

28A

± 5%

< 100 mV

+5V

26A

± 5%

< 100 mV

-12V

0.5A

± 10%

< 200 mV

+5Vsb

2.5A

± 5%

< 100 mV

MODULAR CABLE JACKS

There are four 6-pin black jacks and one 6-pin red jacks on the back of your BP550 PLUS PSU. These

jacks are for the oponal cables that come with your power supply.

Cauon: Please connect only cables provided with this BP550 PLUS. Other cables may not be

compable!

Produktspecifikationer

Varumärke:	Antec
Kategori:	Dator strömförsörjning
Modell:	BP550 Plus
Vikt:	2000 g
Certifiering:	UL, CE, TÜV, CB, FCC, CCC, C-TICK
Medeltid mellan fel (MTBF):	100000 h
Effektivitet:	85 %
Produktens färg:	Silver
Effekt skyddsfunktioner:	Kortslutning
Produktstorlek (BxDxH):	150 x 155 x 86 mm
AC-inspänning:	100 - 240 V
ATX strömkontakt (24-pin):	Ja
Högsta strömstyrka:	28 A
Total effekt:	550 W
Antalet SATA strömkontakter:	3
Strömförsörjningsenhet formfaktor:	ATX
PCI Express strömkontakter (6-polig):	Ja
Diskettenhet strömkontakt:	1
Utgångar (Notering):	+3.3V, +5V, +12V1, +12V2, +12V3, -12V, +5Vsb
