NINETEEN

HUNDRED

User

Manual

Nineteen Hundred User Manual

Congratulations on your purchase of the Antec Nineteen Hundred!!

Meet the Nineteen Hundred, a case engineered for performance and built to enclose the ultimate PC.

It is an unbeatable enclosure that delivers a combination of cooling, performance, and convenience and

stands head and shoulders above the competition.

With 9 expansion slots, the Nineteen Hundred features an advanced cooling system for graphics cards

up to 330 mm (13.0 inches) in length. Dual-layer mesh provides a stylish and new fashion into computer

hardware. Nineteen Hundred is using silicone grommets technology to limit vibrations.

In addition, Its comes with 4 advance silent Fluid Dynamic bearing chassis fan which can provide lowest

fan acoustic to under 18dB (A). Finally, the Nineteen Hundred is constructed of durable SECC steel that

lasts for builds to come. Along with pioneering design and solid construction the Nineteen Hundred is

the last word in ultimate PC builds

At Antec, we continually refine and improve our products to ensure the highest quality. As such, your

new chassis may differ slightly from the description in this manual due to improvements applied for the

optimal building experience. As of October 01, 2013, all features, descriptions, and illustrations in this

manual are correct.

Disclaimer

This manual is intended only as a guide for Antec’s computer

enclosures. For more comprehensive instructions on installing the

motherboard and peripherals, please refer to the manuals that

come with those components.

Table of Contents

Section 1: Introduction

1.1 Getting to Know Your Chassis ............................................................................ 5

1.2 Chassis Specifications......................................................................................... 6

1.3 Included Screws ................................................................................................. 6

1.4 Before You Begin ................................................................................................ 7

Section 2: Hardware Installation

2.1 Setting Up .......................................................................................................... 9

2.2 Motherboard Installation................................................................................... 9

2.3 Installing KUHLER H

O Liquid Coolers ................................................................ 11

2.4 Power Supply Installation .................................................................................. 12

2.5 External 5.25” Device Installation ...................................................................... 13

2.6 Internal 3.5” / 2.5” Device Installation .............................................................. 15

2.7 Cable Management ............................................................................................ 17

Section 3: Front I/O Ports

3.1 USB 2.0 ............................................................................................................... 19

3.2 USB 3.0 ............................................................................................................... 19

3.3 AC’97 / HD Audio Ports ...................................................................................... 20

3.4 Power Switch / Reset Switch / Hard Disk Drive LED Connectors ....................... 20

3.5 Rewiring Motherboard Header Connections ..................................................... 21

Section 4: Cooling System

4.1 Included Fans ..................................................................................................... 23

4.2 Optional Fans ..................................................................................................... 23

4.3 Fan Switch Controller ......................................................................................... 24

4.4 Air Filters ............................................................................................................ 25

Produktspecifikationer

Varumärke:	Antec
Kategori:	Inte kategoriserad
Modell:	Nineteen Hundred
Bredd:	223.6 mm
Djup:	555 mm
Höjd:	696 mm
Lämplig för:	Spela
Ljudutgång:	Ja
Material:	SECC, Steel
Modell:	PC
Strömförsörjning ingår:	Nej
Maximal CPU-kylarhöjd:	175 mm
Maximal grafikkortslängd:	330 mm
Produktens färg:	Black, Red
Formfaktor:	Full Tower
Antalet hårddiskar som stöds:	17
Antal USB 2.0 anslutningar:	2
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	4
Bakre fläktar installerade:	1x 120 mm
Harmonized System (HS)-kod:	84733080
Sidoruta:	Ja
Ljudanslutning:	Ja
Hårddiskstorlek som stöds:	2.5, 3.5 "
Som stöds moderkorts formfaktorer:	ATX, CEB, EATX
Strömförsörjning plats:	Botten
Antalet expansionsplatser:	9
Antal 2,5 "vikar:	2
Frontfläktar installerade:	3x 120 mm
Maximal främre fläktar:	3
Frontfläktdiametrar som stöds:	120 mm
Antal 3,5 "vikar:	12
Antalet 5,25 "fack:	3
Antal bakfläktar som stöds (max):	1
Bakre fläktdiametrar som stöds:	120 mm
Antal toppfläktar som stöds (max):	2
Toppfläktdiametrar som stöds:	120 mm
Flytande kylförmåga:	Ja
Installerade toppfläktar:	2x 120 mm
