Archos ARNOVA 9 G3 4GB Bruksanvisning

Archos Tablett ARNOVA 9 G3 4GB

Läs gratis den bruksanvisning för Archos ARNOVA 9 G3 4GB (58 sidor) i kategorin Tablett. Guiden har ansetts hjälpsam av 11 personer och har ett genomsnittsbetyg på 4.9 stjärnor baserat på 6 recensioner. Har du en fråga om Archos ARNOVA 9 G3 4GB eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/58

▲

ENGLISH

STARTING UP

Installation Wizard

The first time you start up your ARNOVA, the installation wizard will bring you through a few screens to

help you set up the principal settings: language, country, time, etc.

Before using your ARNOVA for the rst time, completely charge the battery!

1. Connect the supplied power cable to the ARNOVA Power connector and to a wall outlet.

2. The ARNOVA device will turn on and start charging.

- The Power indicator light is red while the battery is charging.

- It will turn yellow when the battery is fully charged.

Charging the Battery

???

ENGLISH

DESCRIPTION OF THE DEVICE

IMPORTANT:

Your device is frozen. You can turn it off. Press the ON/OFF button

for 10 seconds or press the reset

button. See Hardware Reset

1. USB Host port: to connect a keyboard, a mouse or a mass storage USB device.

2. Power connector

3. Micro-USB port: to connect your ARNOVA to your computer, using the

included USB cable (to transfer les)

4. Hardware Reset: in the event that your ARNOVA freezes operation, you

can press the “pinhole reset” button by using a sharp object such as a

toothpick.

5. Micro-SD card slot

6. Charging indicator

- red light: battery charging

- yellow: battery charged.

7. Headphone jack

8. Microphone

9. On/Off button: enables to turn on or turn off the device.

10. Volume buttons

11. Home button

12. Camera

www

ENGLISH

CONNECTING TO THE WIFI NETWORK

For this procedure to work, you need to be in a WiFi zone that will allow you to connect to it. Every time the

ARNOVA is in range of a network that you have already configured once, it will attempt to make a connection.

* For free access WiFi points, there is no need to enter any special

information. For secured networks, you will need either a key (a

series of numbers and/or letters) of the type WEP, WPA, or WPA2.

To obtain the exact connection parameters required, contact the

Internet service provider.

How to congure a WiFi network

From the status bar, at the bottom right hand of the screen, you can access the WiFi

settings quickly.

1. Touch the time in the status bar. The status dashboard is displayed.

2. Touch the time in the status dashboard. The setting dashboard is displayed below.

3. Touch WiFi to open the WiFi settings.

4. If the WiFi is off, slide the WiFi switch to the On position.

Once the WiFi is on, the ARNOVA will scan for available WiFi networks.

Secured networks are indicated with a Lock icon. If the device finds a network that

you connected to previously, it connects to it.

5. Touch the network you want to connect to.

6. Enter the required network information* and touch Connect.

We recommend that you select Show password in order to be able to see the

characters you are typing.

Your ARNOVA will attempt to establish a connection to that WiFi access point.

Produktspecifikationer

Varumärke:	Archos
Kategori:	Tablett
Modell:	ARNOVA 9 G3 4GB
Vikt:	630 g
Bredd:	239 mm
Djup:	184 mm
Höjd:	12.5 mm
Batterikapacitet:	2 mAh
Skärm diagonal:	9.7 "
Upplösning:	1024 x 768 pixlar
Processorfrekvens:	1 GHz
Intern lagringskapacitet:	4 GB
Wi-Fi:	Ja
Wi-Fi-standarder:	802.11b, 802.11g, Wi-Fi 4 (802.11n)
Ljudformat som stöds:	APE, FLAC, MP3, OGG, WAV
GPS:	Ja
Videoinspelning:	Ja
Plattform:	Android
Touch-teknik:	Flerpunktsberöring
LED-bakgrundsbelysning:	Ja
Antal färger:	16,78 miljoner färger
Inbyggda högtalare:	Ja
Antal inbyggda högtalare:	2
Full HD:	Ja
Maximal videoupplösning:	1024 x 768 pixlar
Inbyggd mikrofon:	Ja
Internminne:	1 GB
Processorarkitektur:	ARM Cortex-A8
Inbyggd kamera:	Ja
Mobil nätverksanslutning:	Ja
HD-klar:	Ja
Batteriteknik:	Litium Polymer (LiPo)
Batterikapacitet (wattimmar):	9 wh
Typ av minneskort:	SD, SDHC
Produktens färg:	Svart
bruksanvisning:	Ja
Hörlursutgång:	Ja
Inbyggd kortläsare:	Ja
Formfaktor:	Skiffer
Paneltyp:	TN+Film
Windows-operativsystem som stöds:	Ja
Mac-operativsystem som stöds:	Ja
Installerat operativsystem:	Android
Produktstorlek (BxDxH):	239 x 184 x 12.5 mm
Kabel inkluderad:	USB
Bildkomprimeringsformat:	BMP, GIF, JPG, PNG
AC-adapter inkluderad:	Ja
Antal USB 2.0 anslutningar:	1
Native bildförhållande:	4:3
Processorkärnor:	1
Mobilt nätverksgeneration:	3G
Bluetooth:	Nej
Linux operativsystem som stöds:	Ja
Wi-Fi-standard:	Wi-Fi 4 (802.11n)
Datanät:	3G
Högsta minneskortskapacitet:	32 GB
Automatisk fokus:	Ja
Drifttid för batteri:	- h
Lagringsmedia:	Flash
Uttag för mikrofon/linje in:	Nej
Operativsystemversion:	4.0
Andra kamera:	Ja
Mini-USB 2.0 anslutningar:	1
