COOKER AND OVEN

Contents

Warning, 2

Installation, 3-9

Positioning and levelling

Mounting a Power Supply Cable

Electrical connection

Gas connection

Adapting to different types of gas

Post Installation Checks

Technical specifications

Table of characteristics

Description of the appliance, 10

Overall view

Control panel

Start-up and use, 11-14

Using the hob

Using the oven

Using the cooking timer

Cooking modes

Oven cooking advice table

Precautions and tips, 15-16

General Appliance Warnings

Installation Warnings

Safety With The Cooktop

Maintenance Warnings

Gas And Electrical Safety

Respecting and conserving the environment

Care and maintenance, 17-18

Switching the appliance off

Cleaning the appliance

Replacing the oven light bulb

Cleaning The Cooktop

Gas tap maintenance

Assistance

Service information, 19

Operating Instructions

English,1

A6TMC2 C (X) AUS

WARNING: The appliance and its

accessible parts become hot

during use.

Care should be taken to avoid

touching heating elements.

Children less than 8 years of age

shall be kept away unless

continuously supervised.

This appliance can be used by

children aged from 8 years and

above and persons with reduced

physical, sensory or mental

capabilities or lack of experience

and knowledge if they have been

given supervision or instruction

concerning use of the appliance in

a safe way and understand the

hazards involved. Children shall not

play with the appliance. Cleaning

and user maintenance shall not be

made by children without

supervision.

WARNING: Unattended cooking on

a hob with fat or oil can be

dangerous and may result in fire.

NEVER try to extinguish a fire with

water, but switch off the appliance

and then cover flame e.g. with a lid

or a fire blanket.

Do not use harsh abrasive cleaners

or sharp metal scrapers to clean the

oven door glass since they can

scratch the surface, which may

result in shattering of the glass.

The internal surfaces of the

compartment (where present) may

become hot.

Never use steam cleaners or

pressure cleaners on the appliance.

Remove any liquid from the lid

before opening it.

WARNING

Do not close the glass cover (if

present) when the gas burners or

electric hotplates are still hot.

WARNING: Ensure that the

appliance is switched off before

replacing the lamp to avoid the

possibility of electric shock.

CAUTION: the use of inappropriate

hob guards can cause accidents.

! When you place the rack inside,

make sure that the stop is directed

upwards and in the back of the cavity.

! Before operating your new appliance please read

this instruction booklet carefully. It contains

important information concerning the safe installation

and operation of the appliance.

! Please keep these operating instructions for future

reference. Make sure that the instructions are kept

with the appliance if it is sold, given away or moved.

! The appliance must be installed by a qualified

professional according to the instructions provided.

! This cooktop must be installed in accordance with

the requirements of local gas and electrical authorities,

as well as the latest published versions of the following

standards:

•AS/NZS 5601 Gas Installation code

•SAA Wiring Rules.

! Any necessary adjustment or maintenance must be

performed after the cooker has been disconnected

from the electricity supply.

Ventilation opening Increase in the gap between

for comburent air the door and the flooring

Room ventilationRoom ventilationRoom ventilationRoom ventilationRoom ventilation

Where the total input of all appliances exceeds 3

MJ/h for each cubic metre of the room or enclosure

volume, the space shall be ventilated by one of the

methods detailed below. For the purpose of

assessing the adequacy of ventilation, the space

that cannot be isolated by doors is the ‘volume of a

room’.

Natural ventilation direct from outsideNatural ventilation direct from outside

Natural ventilation direct from outside

Two permanent openings shall be provided directly

to outside. The openings shall be located to ensure

the distance between the top of the upper opening

and the ceiling of the room or enclosure, and the

distance between the bottom of the lower opening

and the floor of the room or enclosure does not

exceed 5% of the height of the room or enclosure.

The minimum free ventilation area provided by each

opening shall be calculated using the following

formula:

Installation

Adjacent room Room requiring ventilation

A B

A = 3 × T, where

A = the minimum free ventilation area (cm2)

T = the total gas consumption of all appliances

(MJ/h)

The minimum vertical dimension of any free

ventilation opening shall be 6 mm.

NOTE 1 When used in this Clause, the term When used in this Clause, the term When used in this Clause, the term When used in this Clause, the term When used in this Clause, the term

‘directly to outside’ means any one of the‘directly to outside’ means any one of the

‘directly to outside’ means any one of the‘directly to outside’ means any one of the‘directly to outside’ means any one of the

following options, provided that thefollowing options, provided that the

following options, provided that thefollowing options, provided that thefollowing options, provided that the

ventilation path is unobstructed by buildingventilation path is unobstructed by building

ventilation path is unobstructed by building

material or insulation:material or insulation:

material or insulation:

(a) Directly through an outside wall (preferred

option).

(b) Through to an outside wall but offset.

(d) Into an underfloor space ventilated to outside.

(e) Into a roof space ventilated to outside.

NOTE 2 The two openings may be combined The two openings may be combined The two openings may be combined The two openings may be combined The two openings may be combined

provided that the top and bottom of theprovided that the top and bottom of theprovided that the top and bottom of theprovided that the top and bottom of theprovided that the top and bottom of the

opening reach the limits set by this Clause.opening reach the limits set by this Clause.opening reach the limits set by this Clause.opening reach the limits set by this Clause.opening reach the limits set by this Clause.

Natural ventilation via adjacent roomNatural ventilation via adjacent room

Natural ventilation via adjacent roomNatural ventilation via adjacent roomNatural ventilation via adjacent room

Two permanent openings shall be provided in the

room or enclosure. The openings shall be located to

ensure the distance between the top of the upper

opening and the ceiling of the room or enclosure,

and the distance between the bottom of the lower

opening and the floor of the room or enclosure does

not exceed 5% of the height of the room or

enclosure.

The minimum free ventilation area provided by each

opening shall be calculated using the following

formula:

A = 6 × T, where

A = the minimum free ventilation area (cm2)

T = the total gas consumption of all appliances

(MJ/h)

These requirements shall apply to all subsequent

rooms until a room is ventilated to outside, in

accordance with the previous section, or the total

input of the appliances does not exceed 3 MJ/h for

each cubic metre of the total volume of the

enclosure and rooms.

The minimum vertical dimension of any free

ventilation opening shall be 6 mm.

NOTE : The two openings may be combined: The two openings may be combined: The two openings may be combined: The two openings may be combined: The two openings may be combined

provided that the top and bottom of theprovided that the top and bottom of the

provided that the top and bottom of theprovided that the top and bottom of theprovided that the top and bottom of the

opening reach the limits set by this Clause.opening reach the limits set by this Clause.

opening reach the limits set by this Clause.opening reach the limits set by this Clause.opening reach the limits set by this Clause.

This appliance must be installed by an authorised person in accordance with this instruction manual AS/NZS 5601.1 – Gas installations

(installation and pipe sizing), local gas fitting regulations, local electrical regulations, Building Code of Australia and any other government authority.
