Sida 1/32
Contents
BUILT-IN MULTIFUNCTION
DOUBLE OVEN
DB62
Instruction booklet
Installation, 2-4
Where to put your oven
Electrical connections
Installation instructions
Installation diagrams
For your Safety, 5
Always
Never
Before using the oven for the first time
Description, 6-7
Features
Temperature conversion chart
The controls
Timer Operation, 8-12
Know your timer
Electronic clock and automatic oven timer operation
Using your Ovens, 13-27
Top oven
Main oven
Care and Cleaning, 28-29
Switching off the electricity
Cleaning the exterior
Cleaning the main oven
Cleaning the top oven
Oven Liners
Oven lamp replacement
Cleaning the doors
Troubleshooting, 30
Service, 31
Spare parts
GB
English
GB
1
Installation
2
GB !Keep this instruction booklet on hand in order to refer to
it when necessary. Take it with you when you move, and
should you sell this appliance or pass it on to another
party, make sure that this booklet is supplied along
with the appliance so that the new owner can become
familiar with the appliance and safety warnings.
!Read these instructions carefully; the following
pages contain important information on installation
and suggestions on how the appliance works.
!Ensure that the oven is installed by a qualified
registered installer, in accordance with the latest local
regulations using the following instructions.
!Before connecting or installing the oven the electricity
supply must be switched off.
Where to put your oven
●Your oven should not be located adjacent to a gas
hob/heater or eye level grill as flames from the
burners could cause damage to your oven.
●For your own safety and to get the best results from
your oven it is important to read through this
instruction booklet before using your oven for the
first time, including the Always and Never safety
warnings (see For Your Safety).
!Incorrect installation could affect the safety of the
oven.
!This appliance must be earthed.
●The installer must check that the voltage
shown on the rating plate corresponds with the
house electricity supply.
●The oven must be supplied via a suitable double
pole isolating switch, having a contact separation
of at least 3 mm in all poles placed in a readily
accessible position adjacent to the unit.
●The maximum loading for your oven is 5.3kW.
●After unpacking the oven stand it on the packing
base in order to avoid damage.
Electrical connections
!Ensure that the electricity supply is turned OFF before
installing your appliance.
●Remove the terminal cover at the rear base of the
oven. Pass the cable through the cable clamp and
connect to the appropriate terminals provided.
Allow sufficient cable so that the oven can be set
down on the floor whilst still connected up. Tighten
the screws on the cable clamp and replace the
terminal cover. Make mains connections.
This appliance conforms to EN55014 regarding
suppression of Radio and Television reception
interference.
Where a double oven is used a 32 amp double
pole control switch should be used to feed the unit
using a suitable rated cable. We recommend that a
minimum of 4mm2PVC insulated twin and earth cable
is used.
●Where a hob is fitted adjacent to an oven then a
45 amp Double Pole control switch should be used
to feed both units via separate suitably rated cables.
We recommend that a minimum of 4mm
2
PVC
insulated twin and earth cable is used.
!Children should not be allowed to play with the
appliance or tamper with the controls.
!IMPORTANT DO NOT LIFT OVEN BY THE DOOR
HANDLES.
This equipment is designed specifically for domestic
purposes and Ariston cannot accept responsibility if
used for any other type of application.
This appliance conforms to the following
EEC Directives:
- 73/23/EEC and 93/68/EEC (Low Voltage Equipment)
- 89/336/EEC, 92/31/EEC and 93/68/EEC
(Electromagnetic Compatibility)
3
1. General
The appliance is designed for mounting at a safe level
into an open housing which must be secured to the
backing wall.
2. Oven Housing Cabinets
●The oven unit housing cabinet dimensions must
comply with Fig. 4 (see Installation Diagrams).
●An air gap of 50 mm minimum must be provided at
the rear of any top or bottom cupboards or shelves
Fig. 1 (see Installation Diagrams).
●Ventilation must be unobstructed, ie. from adjacent
cabinetry. This can be done by either raising the
base of the cabinets using the adjusting feet (or
spacers) or alternatively by providing a slot in the
cabinet plinth to the dimensions shown overleaf.
●The air gap at the rear allows the warmed air to
pass out of the inner cabinet space, but where it is
intended to fit cupboards above the oven unit to
ceiling height it is essential that the warmed air is
exhausted through the front of the cabinet Fig. 1
(see Installation Diagrams).
●If an oven unit is installed adjacent to a tall cabinet,
steam escaping from the oven when the door is
opened could condense on, and perhaps stain, the
adjacent surface. To prevent permanent staining,
the adjacent surface should be made of a material
that is heat resistant and easy to clean.
Adjacent tall cabinets should not be deeper than
the oven housing cabinet.
!IMPORTANT, it is essential that the lower cupboard is
constructed in the manner illustrated (see Installation
Diagrams), ie. having side, back and roof panels so
joined as to provide no apertures which could permit
access to the oven unit when installed.
3. Final installation
●Using a spirit level, check that the housing cabinet
is level from side to side and from front to back in
its installed position.
●Correct any unevenness by placing wooden
packing under the bottom of the cabinet.
Make sure that the cabinet rests firmly on the
cabinet floor without rocking
●Before the oven is fitted, the cabinet must be firmly
secured to the backing wall for stability.
●The oven unit should now be lifted (by 2 adults)
into the cabinet and pushed fully home.
●Finally the oven unit must be secured to the cabinet
by means of the four pozi wash head screws, two
through each side trim.
●Remove all packing material from the grill and oven
interior.
List of Loose Items
4 x Pozi Wash Head No. 6 x 15mm screws.
GB
