Overview
Sometimes oor monitors are a problem. There isn’t enough room
for them onstage or someone sits in and can’t hear the monitors or
the drummer can’t hear them well enough. Or perhaps it’s a pick-up
gig or a rehearsal and you didn’t have enough time to set them up.
In any case, sometimes it would be preferable just to put on head-
phones and somehow connect them to the PA. That’s where the
HeadTAP comes in.
The HeadTAP is a passive device with an input to connect the PA
or monitor amplier and an output to connect the headphones. A
volume control regulates the headphone level and internal resistors
keep the unit’s impedance high enough to protect the headphones.
It also protects the amplier from encountering too low a load im-
pedance while powering tap units, the speaker system or several tap
units by themselves. A good tap will also work with a stereo head-
phone amplier for use in recording situations when you want to
add headphones for additional performers.
Features
l
Provides quick and convenient tapping facilities to permit
powering headphones directly from an amplier
l
Dual parallel 1/4-inch stereo/mono input jacks permit
daisy-chaining taps and/or speakers
l
Stereo/mono input selector button
l
Dual 1/4-inch stereo/mono headphone jacks
with Level Control
l
Passive device (requires no batteries or power adapter)
Specications
Input Impedance 100 Ω
Power Amp Loop Paralleled 1/4” stereo TRS jacks
Max Power Input 20 - 50W max
Output 2 x 1/4” stereo/mono headphone jacks
Controls Headphone Level
Mono/Stereo Switch
Active or Passive Passive
Dimensions 1.7″H x 3.7″W x 2.8″D
43mm x 93mm x 70mm
Weight 1.0 lb (4.6 kg)
ART maintains a policy of constant product improvement. ART reserves the right to
make changes in design, or make additions to, or improvements upon, this product
without any obligation to install same on products previously manufactured.
Therefore, specications are subject to change without notice.
a r t p r o a u d i o . c o m
Head
Head
Head
HeadHeadTAP
Headphone Tap
Usage
a.) If the power source is mono (i.e. one channel of a PA power
amp or mixer/amp), connect a speaker cable either from the amp
or a spare jack on a speaker to the input jack on the HeadTAP.
Now set the pushbutton to Mono (down).
b.) If the power source is a stereo headphone amplier or the
headphone output on a mixer, plug a stereo or balanced 1/4” to
1/4” patch cord directly into the headphone output. Connect the
other end of the cable to the HeadTAP’s Input jack and set the
pushbutton for Stereo (out).
c.) Connect headphones to either of the Headphone Output jacks
on the HeadTAP or both of them if you are connecting two
headphone sets.
d.) Adjust the Volume control as desired. Remember to also turn
up the volume of the amp, mixer, headphone amp, etc., so that
there will be sucient power to drive the HeadTAP(s).
e.) To add another HeadTAP to the circuit, simply run a stereo or
mono (depending on the usage) 1/4” to 1/4” patch cable from the
Parallel Output jack on the HeadTAP to the Input jack on the next
HeadTAP. Multiple HeadTAP’s and headphones can be intercon-
nected this way.
