Sida 1/8
MX622
SIX CHANNEL STEREO MIXER WITH EQ AND EFFECTS LOOP
SIX CHANNEL STEREO MIXER WITH EQ AND EFFECTS LOOP
SIX CHANNEL STEREO MIXER WITH EQ AND EFFECTS LOOP
SIX CHANNEL STEREO MIXER WITH EQ AND EFFECTS LOOP SIX CHANNEL STEREO MIXER WITH EQ AND EFFECTS LOOP
USER'S MANUAL
1
IMPORTANT SAFETY INSTRUCTIONS - READ FIRST
This symbol, wherever it appears, This symbol, wherever it appears, alerts you
alerts you to the presence of uninsulated to important operating and maintenance
dangerous voltages inside the enclosure that instructions in the accompanying literature.
may be sufficient to constitute a risk of shock. Please read the manual.
Read instructions
Retain these safety and operating instructions for future reference. Heed all warnings printed here and on the
equipment. Follow the operating instructions printed in this user guide.
Do not open
There are no user serviceable parts inside. Refer any service work to qualified technical personnel only.
Power sources
Only connect the unit to mains power of the type described in this user guide or marked on the rear panel. The
power source must provide a good ground connection.
Power cord
Use the power cord with sealed mains plug appropriate for your local main supply as provided with the equipment. If
the provided plug does not fit into you outlet consult your service agent. Route the power cord so that it is not likely to
be walked on, stretched or pinched by items placed upon or against.
Grounding
Do not defeat the grounding and polarization means of the power cord plug. Do not remove or tamper with the
ground connection on the power cord.
Moisture
To reduce the risk of fire or electrical shock, do not expose the unit to rain, moisture or use in damp or wet
conditions. Do not place container of liquid on it, which may spill into any openings
Heat
Do not locate the unit in a place close to excessive heat or direct sunlight, as this could be a fire hazard. Locate the
unit away from any equipment, which produces heat such as: power supplies, power amplifiers and heaters.
Environment
Protect from excessive dirt, dust, heat, and vibration when operating and storing. Avoid tobacco ash, drink spillage
and smoke especially that associated with smoke machines.
Handling
Protect the controls from damage during transit. Use adequate padding if you need to ship the unit. To avoid injury to
yourself or damage to the equipment take care when lifting, moving or carrying the unit.
Servicing
Switch off the equipment and unplug the power cord immediately if it is exposed to moisture, spilled liquid or the
power cord or plug becomes damaged during a lightning storm or if smoke odor or noise is noted. Refer servicing to
qualified technical personnel only.
Installation
Install the unit in accordance with the instruction printed in the user guide.
2
INTRODUCTION
The ART MX622 Six Channel Stereo Mixer with EQ and Effects Loop is a versatile mixer combining
three-balanced microphone or line level inputs with three stereo line inputs into a single stereo line level
mix. Each mono balanced XLR input includes fully variable Input gain, Mic/Line switch, Clip indicator, and
selectable 15 Volt Phantom power. An external effects loop section provides a mono Send from the three
Mic/Line channels to external equipment and stereo Returns with Eects Level and In/Out switch. Three
stereo line level inputs are also provided via RCA type jacks with separate Level controls for each stereo
pair. Stereo Record output RCA jacks provide full-level signal of the entire mix at all times. Main outputs
are stereo balanced ¼-inch TRS with Master Level and full range Bass/Treble equalization. The built in
power supply and single high 19” rack mount format allows for easy installation and reliable operation.
Features:
• Three balanced XLR inputs with separate Mic/Line switch, Level control and Clip Indicator
• Three pairs of RCA stereo inputs with separate Level controls
• Selectable 15 Volt Phantom power for each Mic channel
• Balanced ¼-inch TRS Main outputs with Master Level control
• Versatile Bass and Treble equalization on Main outputs
• Stereo Record Out RCA jacks
• Effects Loop with Effects Level control and In/Out switch
• ¼-inch Effects Send with stereo Returns
