SERVICE MANUAL
RM5
SMT Disclaimer
Due to the complex nature of the use of SMT installed components
in Yorkville equipment, we highly caution all service technicians in
attempting to repair or replace SMT factory installed components.
Many of these components may be glued prior to initial soldering.
Replacing SMT components requires expensive
specialized de-soldering equipment and training.
Yorkville Sound will repair and replace defective SMT components
to ensure proper quality assurance and installation is maintained.
Printed in Canada
www.artproaudio.com
E-mail: support@artproaudio.com
© 2016 Applied Research & Technology • Yorkville Sound
APPLIED RESEARCH AND TECHNOLOGY
0DQXDO6HUYLFH$5750YÜ
$XJXVW
AUX IN INPUTS
XLR /
Phone
Stereo
LeftRight
TO LEFT
SPEAKER
1/4
Space
Full
Space
1/2 Space
APPLIED RESEARCH AND TECHNOLOGY
R
DESIGNED & MANUFACTURED BY
YORKVILLE SOUND • TORONTO, CANADA
DISCONNECT POWER BEFORE SERVICING!
DEBRANCHER L’APPEREIL AVANT D’ENLEVER LES COUVERCLES!
AC
TO LEFT
SPEAKER
RM5
A-Z1396 / 2v0
230V
50Hz
0,6A
120VAC
60Hz 1.2A
Contains Transmitter Module FCC ID: A8TBM23SPKXYC2A
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2) this
device must accept any interference received, including
interference that may cause undesired operation.
Pairing: Hold four seconds
On/Off: Single Press
RM5
Hi Fi
Theatre
Ref.
APPLIED RESEARCH AND TECHNOLOGY
FROM RIGHT
SPEAKER
L
RM5
88
SPECIFICATIONS
System Type Active 2-Way Stereo
Program Power (Watts) 300 W
Max SPL (dB) 109
Frequency Response (Hz +/- 3dB) 45-22,000
Crossover Frequency (Hz) 2200
HF Driver(s)
High Resolution Ring Radiator
Center Plug to Improve Off Axis Response
HF Program Power (Watts) 25W (x 2)
refoow etisopmoC xaM-X hgiH hcni-5 )s(revirD FL
LF Program Power (Watts) 125W (x 2)
LF Protection Thermal / Peak (X-max)
Inputs
2 x XLR & ¼-inch TRS Balanced Combi-Jacks (Left/Right),
Stereo 1/8-inch TRS Jack / Bluetooth™ Wireless Streaming
Mode Controls
Reference, HiFi, and Theatre Room Compensation
1/4 Space, 1/2 Space and Full Space
Level Controls Master Level
Cabinet Material Aluminum Unibody Design
Power Supply USA – 105 to 125 VAC /60HZ
noitanitsed fo yrtnuoc rof derugifnoc era stinu tropxE
Bass Principal Dual Opposing Passive Radiator
Dimensions (H, W, D) 12.4-inch x 7.6-inch x 3.6-inch each speaker
rekaeps hcae mm9 x mm91 x mm13
)riaP( gk9 /
sbl02 thgieW
ART maintains a policy of constant product improvement. ART reserves the right to make changes in design,
or make additions to, or improvements upon, this product without any obligation to install same on products
previously manufactured. Therefore, specifications are subject to change without notice.
