1. Product Description
2. Safety Instructions
Important
Read and follow the instructions in this user manual
before installing, operating or servicing this product.
14,2 %
User Manual
The Havana and Cartago Dropper Series are 24 V DC, IP62 LED
strips for indoor and outdoor installation. They are suitable for
mounting in an open aluminum prole. The Dropper Series are
available in various color temperatures and as RGB, and RGBW
options.
For complete product specications visit the respective product
page on our website .www.highlite.com
Havana/Cartago
Dropper Series
This product must be installed in accordance with the applicable
national and international standards for electrical installations.
Improper installation may lead to hazardous situations and
material damage.
DANGER
Installation, service and maintenance of this product
shall be carried out only by qualied persons.
18,1 %
Do not fold or break the LED
strips.
Do not cover the LED strips with
any material during operation.
3. Installation Site Requirements
Attention
The LED strips are not suitable for underwater installation.
They are suitable for installation in damp locations.
©2024 Artecta. All rights reserved.
No part of this document may be copied, published or oth-
erwise reproduced without the prior written consent of
Highlite International.
Design and product specications are subject to change
without prior notice.
For the latest version of this document and other language
versions, please visit our website or www.highlite.com
contact us at .[email protected]
Highlite International B.V. • Vestastraat 2 • 6468 EX • Kerkrade • the Netherlands
Do not bend the LED strip on the
horizontal plane.
Do not twist the LED strip.
3. Handling
Do not connect the LED strip to
electrical power supply when
the LED strip is on the reel or
when it is tightly coiled. This will
damage the LEDs.
Do not put excessive pressure
on the LED chips.
You can bend the LED strip only
along the vertical axis. The mini-
mum bending radius is 20 mm.
Do not bend the LED strip with
the LEDs on the inside.
Do not fold or break the LED
strips.
Do not cover the LED strips with
any material during operation.
20 mm
Do not bend the LED strip on the horizontal plane.
Do not twist the LED strip.
3. Handling
Do not connect the LED strip to electrical power supply when the
LED strip is on the reel or when it is tightly coiled. This will damage
the LEDs.
You can bend the LED strip only along the vertical axis. The mini-
mum bending radius is 20 mm.
Do not bend the LED strip with the LEDs on the inside.
20 mm
Do not put excessive pressure on the LED chips.
4. Handling
Do not connect the LED strip to
electrical power supply when
the LED strip is on the reel or
when it is tightly coiled. This will
damage the LEDs.
Do not put excessive pressure
on the LED chips.
Do not fold or break the LED
strips.
Do not cover the LED strips with
any material during operation.
You can bend the LED strip only
along the vertical axis. The
maximum bending radius is
30mm.
Do not bend the LED strip with
the LEDs on the inside.
30 mm
Do not bend the LED strip on the
horizontal plane.
Do not twist the LED strip.
V1
Do not install the LED strips:
under water
at a place where the LED strips are exposed to direct sunlight
near heat-generating devices
Do not install the LED strips in environments with highly volatile
substances, such as sulfur, chlorine, bromine and VOC. This will
reduce the life of the LED chips.
Make sure that the LED strips are installed at a place with:
ambient temperature between -20 °C and 50 °C
sufcient airow.
Make sure that the mounting surface is clean and smooth, and
free of grease or silicone oil.
Make sure that the mounting surface is thermally conductive and
provides good heat dissipation.
If the LED strips are installed outdoors, make sure that they are not
exposed to the effects of the weather. The LED strips are not UV
resistant.
The LED strips can be installed in an open aluminum prole.
in closed aluminum proles.
