INSTRUCTIONS FOR USE

TD85.13XX

Carefully read the instructions for use before using the dryer.

Tumble Dryer

T411HS.W.U

Important safety instructions 3

Dryer description 6

Before using the appliance for the ﬁ rst time 7

Installation and connection 9

Tips before drying 18

Drying process 21

System settings 29

The following symbols are used throughout the manual and they have the following meanings:

Information, advice, tip, or recommendation Warning – danger of hot surface

Warning – general danger Warning – danger of fire

Warning – danger of electric shock

See Quick guide on the last page.

Dear Customer,

We thank you for purchasing this quality ASKO product.

We hope it meets all your expectations. Scandinavian design combines pure lines, everyday functionality,

and high quality. These are the key characteristics of all our products, and the reason why they are highly

appreciated across the globe.

We kindly recommend that you read these instructions before using the appliance for the ﬁ rst time. The

instruction manual also includes information on how you can help protect the environment.

TABLE OF CONTENTS

Original instructions

Cleaning and maintenance 32

Errors and Troubleshooting 40

Service and warranty 44

Technical information 47

Program table 48

Disposal 49

Quick guide 51

GENERAL

SAVE THESE INSTRUCTIONS FOR FUTURE REFERENCE!

WARNING - To reduce the risk of ﬁ re, electric shock, or injury to persons

when using your appliance, follow basic precautions, including the following:

1. Read all instructions before using the appliance.

2. WARNING - Only use the dryer to dry laundry that was washed with

water. Do not dry any laundry that was washed or cleaned with ﬂ ammable

cleaners or substances (such as gasoline, trichloroethylene, etc.) as this

may result in an explosion.

3. Do not wash or dry articles that have been previously cleaned in, washed

in, soaked in, or spotted with gasoline, dry-cleaning solvents, cooking oils,

other ﬂ ammable or explosive substances as they give oﬀ vapors that could

ignite or explode.

4. Instructions for use are available on our website at www.askona.com.

5. Your dryer is intended solely for household use.

6. Do not allow children to play on or in the appliance. Children should be

closely supervised when near the appliance.

7. Before the appliance is removed from service or discarded, remove the

door to the drying compartment.

8. Do not reach into the appliance if the drum is moving.

9. Do not install or store this appliance where it will be exposed to the weather.

10. Do not tamper with controls.

11. Do not attempt to repair or replace any part of the appliance or perform any

servicing unless speciﬁ cally recommended in this guide.

12. Do not use fabric softeners or dryer sheets unless the manufacturer gives

written assurance that the product will not damage a tumble dryer.

13. WARNING - Do not heat dry items containing vinyl, plastic, foam rubber

or similarly textured rubberlike materials, ﬁ berglass, or wool unless the

label speciﬁ es “washable”.

14. Clean the lint ﬁ lter before or after each load.

15. Keep the area around the exhaust opening and adjacent surrounding areas

free from the accumulation of lint, dust and dirt.

16. The interior of the machine should be cleaned periodically by an authorized

ASKO service agent.

17. Do not place items exposed to cooking oils in your dryer. Items

contaminated with cooking oils may contribute to a chemical reaction

that could cause a load to catch ﬁ re. To reduce the risk of ﬁ re due to

contaminated loads, the ﬁ nal part of a tumble dryer cycle occurs without

heat (cool down period). Avoid stopping a tumble dryer before the end of

IMPORTANT SAFETY INSTRUCTIONS
