Asrock H270M Pro4 Bruksanvisning

Asrock moderkort H270M Pro4

Läs gratis den bruksanvisning för Asrock H270M Pro4 (80 sidor) i kategorin moderkort. Guiden har ansetts hjälpsam av 12 personer och har ett genomsnittsbetyg på 4.4 stjärnor baserat på 6.5 recensioner. Har du en fråga om Asrock H270M Pro4 eller vill du ställa frågor till andra användare av produkten? Ställ en fråga

Ladda ner PDF

Sida 1/80

Version 1.0

Published October 2016

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

AUSTRALIA ONLY

Our goods come with guarantees that cannot be excluded under the Australian Consumer

Law. You are entitled to a replacement or refund for a major failure and compensation for

any other reasonably foreseeable loss or damage caused by our goods. You are also entitled

to have the goods repaired or replaced if the goods fail to be of acceptable quality and the

failure does not amount to a major failure. If you require assistance please call ASRock Tel

: +886-2-28965588 ext.123 (Standard International call charges apply)

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Produktspecifikationer

Varumärke:	Asrock
Kategori:	moderkort
Modell:	H270M Pro4
Bredd:	244 mm
Djup:	244 mm
Maximal upplösning:	4096 x 2160 pixlar
Antal HDMI-portar:	1
Hörlursutgångar:	1
Certifiering:	FCC, CE, WHQL, ErP/EuP ready
HDCP:	Ja
Maximalt internminne:	64 GB
Intel® Smart Response Technology:	Ja
Ljudutgångskanaler:	7.1 kanaler
Snabbinstallationsguide:	Ja
Intel® Optane™ Memory Ready:	Ja
Komponent för:	PC
Kompatibla processorer:	Intel® Celeron®
Minnestyper som stöds:	DDR4-SDRAM
Antal minnesplatser:	4
BIOS-typ:	UEFI AMI
ACPI-version:	6.0
bruksanvisning:	Ja
processortillverkare:	Intel
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	LGA 1151 (uttag H4)
Kabel inkluderad:	SATA
Antal PS/2-portar:	2
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	2
RAID-nivåer:	0, 1,5, 10
Minnesplatser, typ:	DIMM
Minneskanaler:	Dubbla kanaler
Minnets hastigheter:	2133,2400 MHz
Max antal processorer:	1
USB 2.0 anslutning:	2
ATX strömkontakt (24-pin):	Ja
EPS strömkontakt (8-polig):	Ja
TPM-anslutning:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	3
BIOS minnesstorlek:	128 mbit
LAN-styrenhet:	Intel® I219-V
Wake-on-LAN förberedd:	Ja
Moderkort, chipsetfamilj:	Intel
Moderkortets chipset:	Intel® H270
Moderkort formfaktor:	micro ATX
PCI Express x16 (Gen 3.x)-kortplatser:	2
Antal M.2 (M)-platser:	2
Harmonized System (HS)-kod:	84733020
Medföljande programvara:	ASRock A-Tuning, ASRock APP Charger, ASRock XFast LAN,
Kvalitet på VGA (D-Sub) porten:	1
Antal DVI-D anslutningar:	1
Uttag för mikrofon/linje in:	Ja
Intel® Turbo Boost Technology:	2.0
Drivrutiner medföljer:	Ja
Antal displayer som stöds:	3
Lagringsenhetsgränssnitt som stöds:	M.2, SATA III
Antal USB 3.2 Gen 1 (3.1 Gen 1)typ C-portar:	3
USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar:	2
Antal SATA III kontakter:	6
CPU-fläktsanslutning:	Ja
Antal anslutningar för fläktar:	1
Ljudanslutning på framsidan:	Ja
Stöd för parallellprocessteknik:	Quad-GPU CrossFireX
Antalet COM-anslutningar:	1
PCI Express x1 (Gen 3.x)-kortplatser:	2
Intel Extreme Memory Profile (XMP):	Ja
PC hälsoövervakning:	CPU, FAN, Temperature, Voltage
Chassits genomgångsanslutning:	Ja
Trial-programvara:	AntiVirus
Maximalt minne på grafikkort:	1024 MB
Intel® Core i3/i5/i7/i9 serien:	i3-6xxx, i5-6xxx, i7-6xxx
Intel® Rapid Storage Technology för företag:	Ja
