P4i45PE+
User Manual
Version 1.0
Published November 2003
Copyright©2003 ASRock INC. All rights reserved.
2
Copyright Notice:
No part of this manual may be reproduced, transcribed, transmitted, or translated in
any language, in any form or by any means, except duplication of documentation by
the purchaser for backup purpose, without written consent of ASRock Inc.
Products and corporate names appearing in this manual may or may not be regis-
tered trademarks or copyrights of their respective companies, and are used only for
identification or explanation and to the owners’ benefit, without intent to infringe.
Disclaimer:
Specifications and information contained in this manual are furnished for informa-
tional use only and subject to change without notice, and should not be constructed
as a commitment by ASRock. ASRock assumes no responsibility for any errors or
omissions that may appear in this manual.
With respect to the contents of this manual, ASRock does not provide warranty of
any kind, either expressed or implied, including but not limited to the implied warran-
ties or conditions of merchantability or fitness for a particular purpose.
In no event shall ASRock, its directors, officers, employees, or agents be liable for
any indirect, special, incidental, or consequential damages (including damages for
loss of profits, loss of business, loss of data, interruption of business and the like),
even if ASRock has been advised of the possibility of such damages arising from
any defect or error in the manual or product.
ASRock Website: http://www.asrock.com
3
Contents
1 Introduction ................................................... 4
1.1 Package Contents .......................................................... 4
1.2 Specifications ................................................................ 5
1.3 Motherboard Layout ...................................................... 8
1.4 ASRock I/O
TM
................................................................. 9
2 Installation...................................................... 10
2.1 Screw Holes ................................................................. 10
2.2 Pre-installation Precautions ........................................... 10
2.3 CPU Installation .............................................................. 11
2.4 Installation of CPU Fan and Heatsink ............................ 11
2.5 Installation of Memory Modules (DIMM)......................... 12
2.6 Expansion Slots (PCI and AGP Slots) ........................... 13
2.7 USB 2.0 Notice ............................................................... 13
2.8 Jumpers Setup .............................................................. 14
2.9 Connectors .................................................................... 15
2.10 Serial ATA (SATA) Hard Disks Installation ................... 17
2.11 Making An SATA Driver Diskette .................................. 18
3 BIOS Setup ...................................................... 19
3.1 BIOS Setup Utility ........................................................... 19
3.1.1 BIOS Menu Bar ....................................................... 19
3.1.2 Legend Bar ............................................................. 19
3.2 Main Menu...................................................................... 20
3.3 Advanced, Security, Power, Boot, and Exit Menus ..... 22
4 Software Support ........................................... 23
4.1 Install Operating System ............................................... 23
4.2 Support CD Information ................................................. 23
4.2.1 Running Support CD ............................................... 23
4.2.2 Drivers Menu .......................................................... 23
4.2.3 Utilities Menu ........................................................... 23
4.2.4 ASRock “PC-DIY Live Demo” Program ................... 23
4.2.5 Contact Information ................................................ 23
Appendix ............................................................ 24
1. Advanced BIOS Setup Menu ........................................... 24
2. Security Setup Menu ....................................................... 29
3. Power Setup Menu .......................................................... 30
4. Boot Setup Menu ............................................................. 31
5. Exit Menu ......................................................................... 32
