WARNING
This unit has no user-serviceable parts inside. Opening the casing presents a risk of
electrocution and only use indoors. ASRock will not be responsible for any result of
improper use, including but not limited to, any use of the product outside of its intended
purpose or use inconsistent with the warranty terms available online.
Only use the included cables specically labeled for your PSU. Using incorrect cables
may run the risk of catastrophic failure.
Installation Procedures
1
Quick Installation Guide
Power Supply Series
Remove the power supply from its packaging.
NOTE
Use the screws provided with your case to
install the power supply into your computer.
Connect the 24-Pin ATX cable to the PSU and
the motherboard.
2
It is recommended to install the power supply
with the fan facing down.
However, if your case places the power supply
at the bottom of the case and there are no
ventilation holes available, it may be best to
install the power supply with the fan facing up
for greater efciency and reliability.
3
Connect the 4+4-Pin EPS12V cable to the
motherboard. (Optional)
If you plan on extreme overclocking and
your motherboard supports additional 8-Pin
or 4-Pin CPU power connectors, connect the
second 4+4-Pin EPS12V cable.
This is only needed for heavy overclocking or
for Dual CPU motherboards.
4
5
Connect the 12V-2X6 / PCIe cables to your
graphics card(s).
NOTE
Take extra care to fully plug-in the 12V-2X6
cable to PSU and your graphics card.
Avoid bending the 12V-2X6 cable within 35mm
of the 12V-2X6 connector.
Do not attempt to plug an 8-Pin PCIe cable into
a 6-Pin connector without rst detaching the
two extra pins.
We recommend to use one PCIe cable per
PCIe connector on your graphics card if the
card requires 2 or more PCIe connections.
6
Connect SATA power cables to all data drives
or optical drives (hard drives, solid state drives,
optical drives).
7
Connect the peripheral "PATA" 4-Pin connectors
for fans, pumps, legacy components and other
devices/adapters.
8
Connect the AC power cord to your power
supply and to the wall. Check all connections to
assure a solid connection and turn the power
switch on the power supply to the ON position
(If the iCOOL mode is set to ON, the fan will not
spin during low to medium loads) .
