Z97 AnniversaryZ97 Anniversary

Version 1.1

Published October 2014

No part of this documentation may be reproduced, transcribed, transmitted, or

translated in any language, in any form or by any means, except duplication of

documentation by the purchaser for backup purpose, without written consent of

ASRock Inc.

Products and corporate names appearing in this documentation may or may not

be registered trademarks or copyrights of their respective companies, and are used

only for identication or explanation and to the owners’ benet, without intent to

infringe.

Disclaimer:

Specications and information contained in this documentation are furnished for

informational use only and subject to change without notice, and should not be

constructed as a commitment by ASRock. ASRock assumes no responsibility for

any errors or omissions that may appear in this documentation.

With respect to the contents of this documentation, ASRock does not provide

warranty of any kind, either expressed or implied, including but not limited to

the implied warranties or conditions of merchantability or tness for a particular

purpose.

In no event shall ASRock, its directors, ocers, employees, or agents be liable for

any indirect, special, incidental, or consequential damages (including damages for

loss of prots, loss of business, loss of data, interruption of business and the like),

even if ASRock has been advised of the possibility of such damages arising from any

defect or error in the documentation or product.

is device complies with Part 15 of the FCC Rules. Operation is subject to the following

two conditions:

(1) this device may not cause harmful interference, and

(2) this device must accept any interference received, including interference that

may cause undesired operation.

CALIFORNIA, USA ONLY

e Lithium battery adopted on this motherboard contains Perchlorate, a toxic substance

controlled in Perchlorate Best Management Practices (BMP) regulations passed by the

California Legislature. When you discard the Lithium battery in California, USA, please

follow the related regulations in advance.

“Perchlorate Material-special handling may apply, see www.dtsc.ca.gov/hazardouswaste/

perchlorate”

ASRock Website: http://www.asrock.com

e terms HDMI™ and HDMI High-Denition Multimedia Interface, and the HDMI

logo are trademarks or registered trademarks of HDMI Licensing LLC in the United

States and other countries.

Produktspecifikationer

Varumärke:	Asrock
Kategori:	moderkort
Modell:	Z97 Anniversary
Bredd:	- mm
Djup:	- mm
Wi-Fi:	Nej
Maximal upplösning:	4096 x 2304 pixlar
Antal HDMI-portar:	1
Certifiering:	FCC, CE, WHQL, ErP/EuP
Maximalt internminne:	32 GB
Ljudutgångskanaler:	7.1 kanaler
Snabbinstallationsguide:	Ja
Komponent för:	PC
Kompatibla processorer:	Intel Celeron, Intel Pentium
Minnestyper som stöds:	DDR3-SDRAM
Antal minnesplatser:	4
BIOS-typ:	EFI AMI
ACPI-version:	1.1
Obuffrat minne:	Ja
processortillverkare:	Intel
Windows-operativsystem som stöds:	Ja
DirectX-version:	11.1
Typ av ethernet-gränssnitt:	Gigabit Ethernet
Antal LAN (RJ-45) anslutningar:	1
processorsockel:	LGA 1150 (uttag H3)
Kabel inkluderad:	SATA
Antal PS/2-portar:	1
Nätverksansluten (Ethernet):	Ja
Strömkälla av typen:	ATX
Antal USB 2.0 anslutningar:	2
RAID-nivåer:	0, 1,5, 10
Minnesplatser, typ:	DIMM
Minneskanaler:	Dubbla kanaler
Minnets hastigheter:	1066,1333,1600,1866,2133,2400,2800,2933,3100 MHz
Max antal processorer:	1
USB 2.0 anslutning:	2
ATX strömkontakt (24-pin):	Ja
EPS strömkontakt (8-polig):	Ja
Fläktanslutning:	Ja
TPM-anslutning:	Ja
Antal USB 3.2 Gen 1 (3.1 Gen 1) typ A-portar:	4
BIOS minnesstorlek:	64 mbit
LAN-styrenhet:	Intel® I218-V
Wake-on-LAN förberedd:	Ja
Moderkort, chipsetfamilj:	Intel
Moderkortets chipset:	Intel® Z97
Moderkort formfaktor:	ATX
PCI Express x16 (Gen 3.x)-kortplatser:	1
Video adapter:	HD Graphics 4000
Bluetooth:	Nej
Grafikadapterfamilj:	Intel
Ombord grafikkort:	Nej
Drivrutiner medföljer:	Ja
Kylning typ:	Passiv
Lagringsenhetsgränssnitt som stöds:	SATA III
Ljudchipp:	Realtek ALC887
USB 3.2 Gen 1 (3.1 Gen 1)-anslutningar:	1
Antal SATA III kontakter:	6
CPU-fläktsanslutning:	Ja
Antal anslutningar för fläktar:	3
Ljudanslutning på framsidan:	Ja
PCI Express x1 (Gen 2.x)-kortplatser:	3
Stöd för parallellprocessteknik:	Stöds inte
Antalet COM-anslutningar:	1
Clear CMOS knapp:	Ja
PC hälsoövervakning:	CPU, FAN, Power supply, Temperature
Chassits genomgångsanslutning:	Ja
Maximalt minne på grafikkort:	1792 MB
Intel® Core i3/i5/i7/i9 serien:	i3-4xxx, i5-4xxx, i7-4xxx
PCI-kortplatser:	2
Diskret grafik stöd:	Ja
BIOS-omkopplarknappen:	Ja
