INSTRUCTION BOOK
ACRO CA1000
User Guide
CONTENTS
Package Contents
Product Overview
Power Management
Charging
Connections
Firmware Updates
02
03
06
07
08
15
Getting Started _01
Basic Operations
Home Screen
Notification Bar
Using Open APP Service
AK CONNECT
AK File Drop
Listening to Music
Playlist Management
ReplayGain
USB DAC Installation
How to Use USB Audio
CD Ripping
AK CD-Player
Bookmark Function
Favorites Function
Settings
Connecting to Wi-Fi
Using Bluetooth
Equalizer Setup
Using the Device _02
Safety Pre-Cautions
Troubleshooting
Copyright
Certifications
Registered Trademarks
Disclaimers
Specifications
16
20
22
25
26
31
33
36
39
40
41
42
44
45
46
47
55
56
59
62
64
65
66
68
69
70
Miscellaneous _03
User Guide
Contents may be changed without prior notice to improve the
performance or quality of the product.
Package
Contents
Getting Started 02
Protective Film: Protect the device and its screen.
USB Type-C Cable: For charging and data transfer.
Quick Start Guide: Basic overview of device functionality.
Warranty Card: Provides warranty details for your device.
Maintain a copy of this card as it may be required for future
technical support requests.
User Guide: The User Guide can be downloaded from the
Astell&Kern website.
[http://www.astellnkern.com > Support > Download]
Quick Start Guide
& Warranty Card
USB Type-C Cable
ACRO CA1000 Protective Film
Getting Started
03
User Guide
The appearance of the product, as well as the printed and
engraved information, may vary depending on the model.
Product
Overview
Next/Fast-
Forward
Power Button
Play/Pause
Previous/Rewind
2.5mm balanced
ports
6.35mm
unbalanced ports
4.4mm balanced
ports
3.5mm Unbalanced
/ Optical Out port
Data/Audio port
(USB Type-C)
Optical Input Port
Coaxial Input Port
microSD Card Slot
Charging port (USB Type-C)
RCA Input Port
RCA Output Port
Volume
Home Button
LCD
Touchscreen
Getting Started
08
User Guide
Connec-
tions
Earphones/Headphones
1. Connect earphones and headphones to the [UNBAL.1, 2]/
[BAL.1, 2] ports on the front of the product.
2. You can use a variety of earphones/headphones that fit
2.5mm, 3.5mm, 4.4mm, and 6.35mm ports.
Digital Input
1. Connect an external device to the [OPT IN]/[COAX IN] port
on the back of the product using the Optical/Coaxial cable.
Coaxial
Cable
Optical
Cable
CD Player
Digital input supports PCM sound sources of 24bit/176.4kHz or less.
The product may not receive input normally if it is from an
unsupported format.
Maintain moderate volume levels when connecting earphones or
headphones.
Exposure to high volume levels for extended periods may damage
your hearing.
Getting Started
13
User Guide
Delete Files (or Folders) from the Device
1. Select the file/folder to delete, right-click the mouse, and
then select [Delete].
2. Select [Yes] in the [Confirm File/Folder Deletion] window
to delete the selected files/folders.
Disconnecting from the Computer
1. Disconnect the USB Type-C cable after the transfer between
the device and computer is complete.
Disconnecting the device from the computer during a file transfer
may corrupt data on the device.
Getting Started
14
Maximum Capacity: 1TB
Notes on Inserting a microSD Card
Do not force the microSD card into the slot. Doing so may cause
malfunction of the product and damage to the card.
Do not repeatedly insert/remove the microSD card.
If not inserted properly, the microSD card may cause product
malfunctions and may become lodged in the product.
Notes on Removing a microSD Card
Be sure to safely remove the microSD card from the device.
Not following the proper procedure may corrupt data and cause
serious damage to the both the card and device.
Do not remove the microSD card during use. Doing so may cause
malfunction, delete data and damage the microSD card.
Recommended microSD Cards
SAMSUNG, SANDISK
Insert/Remove a microSD Card
1. Refer to the diagram and gently
insert a microSD card into the
microSD card slot.
2. To safely remove a microSD card,
on the Home Screen, select
[Safely remove SD card] from the
Notification Bar or select
[Unmount SD card] from
[Menu - Settings - System
Information].
3. Gently press the microSD card in
to unlock and release it from the
slot.
User Guide
Getting Started
15
Notes on Using a microSD Card
If the microSD card is not recognized or functions improperly,
format the card, preferably in the FAT32 system.
Using cards other than the recommended microSD card types
may cause malfunctions.
A microSD card is not included in the product package. Please
purchase separately.
For Wi-Fi connections, see Page 55.
The firmware update may not start if the battery level is too low.
(A minimum battery level of 20% is required.)
Do not disconnect from the wireless network while downloading the
update file. Doing so may cause data corruption and/or damage to
the system.
If an error occurs or the notice in the Notification Bar disappears
during an update, download the firmware update again through
[Menu - Settings - Update - System].
Moving to another screen during a file download will cancel the
download.
Wi-Fi Update / OTA (Over-the-Air)
1. Connect to a wireless network.
2. If a new firmware update is available, the screen will
display a Firmware Update Guide window.
3. Select [Update].
4. Follow the on-screen instructions to proceed with the
firmware update.
Firmware
Updates
User Guide
Using the Device
17
User Guide
Main Menu
1. From the left edge of the touchscreen, swipe your finger
right to display the Main Menu, or tap the “A” icon in the
upper left corner of the screen.
From the Home Screen, swipe your finger to the left, right,
up or down from any edge of the touchscreen to access display
menus. Each side of the Home Screen will activate a different
display menu.
Music files extracted using the AK CD-Ripper accessory that are
stored in the Ripping folder of the internal memory will be displayed
in the CD library menu.
Using the Device
22
User Guide
Notifi-
cation
Bar
15
16
17
1 2 3 4 5 6 7 98 10 11 12 13 14
Using the Device
28
User Guide
Streaming Music from Your Library
1. Select a category from the library
menu to see your list of music.
2. Select a song to begin streaming.
Downloading Music from Your Library
1. Select a category from the library
menu to see your list of music.
2. Press [ ] button at the upper-
right corner of the music list.
3. Select the desired music and
press [ ] to initiate the
download.
A message on the Notification
Bar will indicate when the
download is complete.
Depending on network conditions, song loading may be slow and
streaming may stutter.
Using a library for other processes can slow down the response
time of the library.
If you stream and download at the same time, it may slow the
device’s response time depending on the speed of the Wi-Fi network
or server.
To stop a download in progress, tap the notification in the Notification
Bar to go to the download screen. Then, select the items to pause or
delete.
Using the Device
33
User Guide
To search, press [ ] on the menu list and enter the title.
The search result will be displayed.
At the top of the Play History menu, press [ / ] to
sort the music list in order of most recently played/most
played.
After selecting the [MQS] category, from the Main Menu
press [ / ] at the top to sort the music list in order
of high quality / alphabetical order.
In the [MQS] category, the MQS tab shows MQA files and PCM
files of 24 bits or more, and the DSD tab shows DSD files.
MQS: MQA [44.1-384kHz(24bit)]
MQS: PCM [8-384kHz(24/32bit)]
DSD: DSD [2.8/5.6/11.2/22.4MHz]
Select the [Folder] category to check the internal / external
memory capacity and number of files / folders, and copy /
move music.
Press [ ] on the music list to add all music to the
current playlist.
Listening
to Music
Selecting Music
1. Select a category from the Main Menu to display the
corresponding music list.
2. Select a song from the list to begin playback.
Listening to Music
Select [Folder] to search music by folder.
Continuous Playing Time: Approx. 10.5 hours (Music: FLAC,16bit,
44.1kHz, Unbalanced, Volume 40, EQ Off, LCD Off, Low Gain)
Supported Formats: PCM [8~384kHz(8/16/24/32bit)]
DSD [2.8/5.6/11.2/22.4MHz]
Using the Device
34
User Guide
Press [ ] on top of the music list to view the options:
: Select / deselect entire list
: Add the selected list at the top / bottom / after the
current song of Now Playing
: Add selected list to a playlist
: Delete selected list
: Exit
Turn the [Volume] wheel to adjust the volume.
Press [ ] during playback to pause and [ ] to resume
playback.
Press [ / ] during playback for the previous/next track.
Press and hold [ / ] to rewind/fast-forward the track.
Drag the indicator on the Playback Progress Bar to a desired
location of a track during playback.
Press the album art on the Home Screen to display the
song lyrics.
Press [ ] at the top of the menu list to hide the menu list.
After selecting [ALBUM] or [CD LIBRARY] category, press
[ / / ] at the top to sort by different viewing options.
Using the Device
35
User Guide
Playlist Screen
Return to the previous screen.
Display the current playlist.
Display the editing options for the music list.
Play all songs in the current list.
Enter a search term to display a list
containing the search term.
Previous
Playlist
Edit mode
Play All
Search
1
2
3
4
5
13
2
4
5
Using the Device
36
Playlist
Manage-
ment
Creating a Playlist
1. Press [Playlists] on the menu to
view the playlists.
2. Select [ + ] in the upper right corner
of the screen.
3. Enter a name for the playlist and
then press [Add] to create a new
playlist.
Adding a Song to a Playlist
1. Press [Playlists] to display the
list of playlists.
2. Select a playlist and press
[+ Add Song] to display a list of
songs by album.
3. Select a song and press [Add]
to add the song to the selected
playlist.
User Guide
Using the Device
38
User Guide
Renaming a Playlist
Deleting a Playlist
1. Press [Playlists] to view the
playlists, then press [ ].
2. Select the playlist to be deleted.
3. Press [ ] at the top of the screen.
4. Press [DELETE] to delete the
selected playlist.
1. Press [Playlists] to view the
playlists, then press [ ].
2. Select a playlist to be renamed.
3. Press [ ] at the top of the
screen to display the RENAME
window.
4. Enter a name for the playlist and
then press [RENAME] to confirm
the change.
Using the Device
42
User Guide
The portable USB DAC must be able to receive digital input through
the micro-USB's OTG.
Audio output may vary widely depending on the digital input specs
of the portable USB DAC used. This is not a defect in the device
output and not a reason for exchange or refund.
When using DoP as a DSD output type, no sound may be outputted
except noise depending on the portable USB DAC.
CD
Ripping
CDs can be ripped directly to the device using the AK CD-
RIPPER (sold separately).
Connecting the AK CD-RIPPER
1. Connect the AK CD-RIPPER to USB Type-C port of the
device using the proper cable.
2. In the Notification Bar press [ ] to link the devices and
activate the CD Ripping Menu.
3. When ripping is complete, before disconnecting, press [ ]
on the Notification Bar to unlink/disconnect the devices.
Automatically select the CD ripper function.
1. Select the function to automatically execute in [Menu-
Settings-CD Ripper-Default run].
2. Select the [CD Player] / [CD Ripping] function.
3. When [Ask every time] is selected, the function selection
popup will be displayed each time a CD is inserted.
The USB Type-C cable provided with the device is to be used to
connect to the computer or to charge the product.
Depending on the CD-Ripper model the dedicated USB Type-C OTG
cable may not be provided in the product package.
Depending on the OTG cable used, the connection may be unstable.
When a USB connection is established while playing a DSD or DXD
file, a mode selection pop-up box will appear with the following options:
External device connection: Connect the player to the computer to
transfer files, USB DAC for audio playback or CD Ripper connection.
Charge device: Charge the device.
Using the Device
44
User Guide
AK CD-
Player
Using the AK CD-Player Function
1. Connect the AK CD-Ripper to the device and select CD
Player if not set as the default run function.
2. Insert a CD and metadata (ID3 tags) for the inserted CD
will be retrieved via Gracenote if Wi-Fi is turned on.
3. Once the metadata has downloaded, press play.
The USB Type-C cable provided with the device is to be used to
connect to the computer or to charge the product.
Depending on the CD-Ripper model the dedicated USB Type-C OTG
cable may not be provided in the product package.
Depending on the OTG cable used, the connection may be unstable.
To search the Gracenote database, the device must be connected to
Wi-Fi. Database access time may vary depending on the network
environment.
Please note that metadata for certain CDs may not be available on
the Gracenote database.
General audio CD and MQA-CD playback is supported, but MP3-CD
won't play.
Using the Device
46
User Guide
1. Press [ ] on the home screen
to add / remove the song being
played to the favorites list.
2. From the Home Screen, swipe
[Left Right] direction to display
the Main Menu.
Press [Favorites] to display the
list of favorite songs.
Favorites
Function
Favorites function allows users to mark a currently playing
song as a favorite and add it to the Favorites folder.
Setting favorites
Using the Device
50
User Guide
Playback Settings
Set how to add a song to Now Playing when a song is
selected from a music list.
ReplayGain
Set consistent volume playback levels between tracks.
Notification Panel
Add, delete, or reorganize Quick Settings buttons on the
notification bar. Drag and drop icons to add quick settings
buttons or change the preferred order.
USB Mode
Media Device (USB Drive): When connected to a computer,
device appears as a removable drive.
DAC Input: Output sound from a connected computer to the device.
CD Ripper
Set the automatic CD ripping function as well as the file
format and ripping speed.
AMP
The AMP output can be set to Low, Mid, High, or Super.
The operating time varies depending on the AMP mode.
The AMP supports 3.5mm/6.35mm unbalanced and 2.5mm/4.4mm
balanced ports.

Produktspecifikationer

Varumärke: Astell&Kern
Kategori: mottagare
Modell: ACRO CA1000

Behöver du hjälp?

Om du behöver hjälp med Astell&Kern ACRO CA1000 ställ en fråga nedan och andra användare kommer att svara dig


mottagare Astell&Kern Manualer

Astell&Kern

Astell&Kern PA10 Bruksanvisning

7 September 2024
Astell&Kern

Astell&Kern ACRO CA1000 Bruksanvisning

2 September 2024

mottagare Manualer

Nyaste mottagare Manualer

Yamaha

Yamaha Aventage RX-A4A Bruksanvisning

9 April 2025
Yamaha

Yamaha Aventage RX-A8A Bruksanvisning

9 April 2025
Phonocar

Phonocar PH544 Bruksanvisning

5 April 2025
DJI

DJI D-RTK 3 Bruksanvisning

4 April 2025
Alpine

Alpine MRX-F65 Bruksanvisning

2 April 2025
QSC

QSC SPA-Qf 60x2 Bruksanvisning

2 April 2025
Harper

Harper HDT2-5010 Bruksanvisning

2 April 2025
Harper

Harper HDT2-2010 Bruksanvisning

2 April 2025
Pro-Ject

Pro-Ject Stereo Box DS Bruksanvisning

30 Mars 2025
Streacom

Streacom TL1 Bruksanvisning

30 Mars 2025
