User Manual

AtlonA

www.atlona.com | toll free: 1-877-536-3976

For International: 1-408-962-0515 2

TABLE OF CONTENTS

1. Introduction .................................................. 3

2. Package Contents .................................................. 3

3. Features .................................................. 3

4. Specication .................................................. 3

5. Description .................................................. 4

6. Remote Control .................................................. 5

7. Display Mode List .................................................. 5

8. Special Notes on LCD Monitors .................................................. 6

9. Atlona Product Registration .................................................. 6

10. Safety Information .................................................. 7

11. Warranty .................................................. 8

www.atlona.com | toll free: 1-877-536-3976

For International: 1-408-962-0515 3

INTRODUCTION

PACKAGE CONTENTS:

FEATURES:

SPECIFICATIONS:

Atlona Technologies’ AT-DIS7-HD is a 7 inch Testing monitor designed for those looking to test cabling and

installation of different components, where displays are remote or not yet present. This portable display will

recognize any HDMI or DVI source at resolutions up to 1080P, and allow integrators and installers to observe

both audio and video signal in real time. An added function allows users the ability to view signal information

such as HDCP compliance, Resolution and Frequency, Digital format, and Audio information. With multiple

control options including manual as well as IR Remote, the AT-DIS7-HD is perfect for installers and integrators

looking for a simple solution to monitor or verify audio and video settings on remote displays. The DIS7-HD can

also be placed in the Rack Unit for constant monitoring.

1. AT-DIS7-HD Unit

2. Operating instructions

3. Power supply (12VDC 1A)

4. Remote

5. IR extension cable

• 7’’ TFT testing panel

• Accepts resolution up to 1080p• HDMI input support HDMI1.3b

• Monitor supports the latest HDMI standard 1.3b

• DIS7-HD is featured with a built speaker

• Manual Panel button control or IR control

Screen size 7.0”W

Max input resolution 1920x1200/60Hz

Max brightness 220cd/m2

View angle (CR=10) >=110°(V),

>=140°(H)

Colors 262.1K

Embedded speaker 0.8W

Dimensions (W×H×D) 7’’ ×4.5’’ ×1.2’’

Mass (main unit) 5.8

Power supply DC:+12V

Power consumption 8W
