Sida 1/16
User Manual
CV/SV/PC/HD/HDMI 1080p
Scaler Box
AT-LINE-PRO2
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
1. Introduction .................................................. 2
2. Features .................................................. 2
3. Package Contents .................................................. 2
4. Operation Controls and Functions .................................................. 3
4.1 Front Panel .................................................. 3
4.2 Rear Panel .................................................. 4
4.3 OSD Operation .................................................. 5
4.4 Remote Control .................................................. 6
5. RS-232 Remote Control Protocol .................................................. 7
6. Specifications .................................................. 11
6.1 General Specification .................................................. 11
6.2 Support Resolution .................................................. 11
7. Safety Information .................................................. 13
8. Warranty .................................................. 14
9. Atlona Product Registration .................................................. 15
TABLE OF CONTENTS
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
Atlona Scaler Box is designed to upscale digital/analog video signal from Composite, S-Video, PC, Component
(HD) and HDMI input sources, to digital HDMI output of wide-range HDTV and PC resolutions, up to 1080p
and WUXGA (1920 x 1200.) Besides video upscaling, the scaler box also converts digital/analog audio signal
to digital format, then output either through HDMI combining with the video, or Coaxial S/PDIF separately.
AT-LINE-PRO2 has a comprehensive OSD menu that allows user to select a variety of output resolutions and
adjust for best picture quality.
• HDMI 1.2, HDCP 1.1 and DVI 1.0 compliant.
• Scales any PC (VGA ~ WUXGA) /HD (480i ~ 1080p) resolutions to/from another PC/HD resolutions.
• Automatically detect the factory setting of the connected display and output the corresponding resolution
and refresh rate, when the NATIVE output is selected.
• Supports 50/60Hz frame rate conversion.
• Supports 3-D motion video adaptive, 3-D de-interlacing, and 3:2 / 2:2 pull-down detection and recovery.
• Provides output picture adjustment on contrast, brightness, hue, saturation, sharpness, RGB (color tone)
level, and aspect ratio size.
• Supports high resolution input/output:
PC: VGA, SVGA, XGA, SXGA, UXGA, WXGA, WSXGA, WUXGA
HDTV: 480i, 576i, 480p, 576p, 720p, 1080i, and 1080p
• Supports digital and analog audio input and output.
• Atlona AT-LINE-PRO2 Scaler Box
• D-Sub (15pin) Cable
• 3XRCA Cable (Composite Video + L/R Audio)
• Remote Controller
• 5VDC Power Supply Adaptor
• Operation Manual
INTRODUCTION
FEATURES
PACKAGE CONTENTS
atlona.com
Toll free: 1-877-536-3976
Local: 1-408-962-0515
