Sida 1/8
Installation Guide
AT-VGW-HW-T2
1
Velocity Hardware Gateway for AV Control, Room
Scheduling, and Device Management
AT-VGW-HW-T2
The Atlona AT-VGW-HW-T2 is a hardware gateway that serves as a centralized processor for
Velocity™ AV control, room scheduling, and device management systems. The gateway serves
up to 20 rooms for AV control and 40 rooms for scheduling. With a simple network connection
and web browser to access the VGW-HW-T2, an integrator, tech manager, or technician can
congure, deploy, and modify Velocity systems quickly, with no programming necessary. In
addition to AV control, the VGW-HW-T2 gateway supports integration with popular calendar
services such as Google Workspace™, Oce 365™, Microsoft Exchange®, and Astra Schedule,
allowing room status and schedules to be displayed on Velocity touch panels. The hardware
gateway includes Velocity Device Manager, a powerful system integration resource for centralized
conguration and management of Atlona devices over a network. The optional Velocity Premier
Services – Remote Gateway (AT-VPS-RG) allows remote management of the gateway over
the internet. The VGW-HW-T2 supports industry-standard, secure data communications, and
features dual Gigabit Ethernet ports for isolating an AV device LAN from a facility or corporate
network.
1 x AT-VGW-T2
2 x Mounting plate
4 x Mounting screw
4 x Rubber feet
1 x Long rack ear
1 x Short rack ear
1 x Installation Guide
Package Contents
Installation Guide
AT-VGW-HW-T2
2
USB USB-C PWR
TM
VELOCITY
AT-VGW-HW-T
AUDIO OUT
OUTPUT ETHERNET
1 2
19V 4.74A
1 AUDIO OUT
Future feature port, not usable at this time.
2 USB
Connect USB devices to these ports for
use with a keyboard and mouse, or use a
USB ash drive to obtain the IP addresses
of the LAN ports.
3 USB-C
This port can be connected to a display or
monitor to view device information, such
as an IP address.
4 PWR
Recessed button for turning the device o
or back on, if needed.
5 OUTPUT
Connect one of these ports to a monitor
or display to view device information,
such as IP address.
6 ETHERNET
Connect an Ethernet cable from one of
these ports to the same network as the
controlled devices.
7 19V 4.74A
Connect the included 19V power supply
to this port for power.
Panel Descriptions
231 4
65 7
NOTE: Connect only one output port at a time. If multiple ports have been
connected, the rst HDMI port connected will take precedence.
Installation Guide
AT-VGW-HW-T2
3
Mounting Instructions
The AT-VGW-HW-T can be mounted in dierent ways, based on the number of units that are
being installed. The AT-VGW-HW-T may also be mounted in a rack or on/under any at surface.
Single-unit rack installation
1 Attach the included small rack ear to one side of the AT-VGW-HW-T, using the included
screws.
2 Attach the included longer rack ear to the opposite side of the AT-VGW-HW-T using the
included screws.
USB USB-C AUDIO OUT
TM
V
ELOCITY
Dual-unit rack installation
1 Turn both units upside-down on a at surface, next to each other, as shown.
2 Position the included mounting plate over the pre-drilled holes on the bottom of the
enclosure. When attaching the mounting plate, the countersink bevels on the mounting
plate should face upward.
USB-C AUDIO OUT USB USB-C AUDIO OUT
TM
V
ELOCITY
Countersink bevel
