Sida 1/1
Email: sales@autel.com
Web: www.autel.com
1
1. Removable Imager Head Cable – connects to the tool when performing
digital inspections for image and video viewing
2. Handgrip – ergonomically designed handle for comfortable grips and
agile operation
3. USB Cable – connects the Digital Inspection Camera to MaxiSys tablet
NOTE: The power of MaxiVideo inspection camera is directly
supplied by the USB port, and no external power source is needed.
The MaxiVideo Inspection Camera kit is supplied with useful accessories,
such as magnet, hook and mirror, which enable the video scope to perform
special tasks
For MV108 (with 8.5mm imager head)
For MV105 (with 5.5mm imager head)
1
23
Description
MV105 3/8’’ to 12’’ (0.95cm to 30cm)：
MV108 1’’ to 14’’ (2.54cm to 35.56cm)：
MV108 (640x480); MV105 (320 x 240)
Main Unit: 0°C to 50°C; Cable: -10°C to 70°C
-20°C to 75°C
Imager head and cable to 1m
0.3kg with 8.5mm diameter imager head
0.2kg with 5.5mm diameter imager head
FCC (EMC), CE (EMC and LVD)
Connect the Removable Imager
Head Cable to the Handgrip. Make
sure the key and slot are properly
aligned. Once they are aligned,
finger-tighten the knurled knob to
hold the connection firmly in place.
2
Power up the MaxiSys Tablet, and
select the “Digital Inspection”
application on the Job Menu.
3
Connect the MaxiVideo inspection
camera to the MaxiSys Tablet with
the USB connection, and that’s it!
1. Magnet – picks up small metal objects, such as dropped rings or screws
2. Hook – unclogs obstacles and picks up wires in the pipes or confined areas
3. Mirror – helps to look around corners and see the unreachable areas
The three accessories, including the Magnet, Hook, and Mirror, can be attached
to the Imager Head as described. Hold the accessory and the imager head.
Slip the end of the accessory over the imager head and then fix it as shown.
Reorient or relocate the receiving antenna.
Increase the separation between the equipment and receiver.
Consult the dealer or an experienced radio/TV technician for help.
This device complies with part 15 of the FCC Rules. Operation is
subject to the following two conditions:
This device may not cause harmful interference, and
This device must accept any interference received, including
interference that may cause undesired operation.
Changes or modifications not expressly approved by the
party responsible for compliance could void the user’s authority
to operate the equipment.
FCC Compliance
This equipment has been tested and found to comply with the
limits for a Class B digital device, pursuant to Part 15 of the FCC
Rules. These limits are designed to provide reasonable protection
against harmful interference in a residential installation.
This equipment generates uses and can radiate radio frequency
energy and, if not installed and used in accordance with the
instructions, may cause harmful interference to radio communications.
However, there is no guarantee that interference will not occur
in a particular installation.If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one or more of
the following measures:
The two accessories, both the Magnet and Mirror, can be attached to the
Imager Head as described. Hold the accessory and the imager head as shown.
Screw the thread part of the accessory over the imager head and then fix it.
1. Mirror – helps to look around corners and see the unreachable areas
2. Magnet - picks up small metal objects, such as dropped rings or screws
8.5mm Imager Head Accessories
5.5mm Imager Head Accessories
8.5mm
5.5mm
Item
Optimal Viewing Distance
Image Capture
Operating Temperature
Storage Temperature
Waterproof
Weight
Compliance
The MV105/108 digital inspection camera is designed to work with
MaxiSys series products or PC. It turns your MaxiSys tablet into a
video inspection scope, allowing you to examine difficult-to-reach
areas normally hidden from sight. It is capable of recording digital
still images and videos, which offers you an economical solution
to inspect machinery, facilities, and infrastructure in a safe and
quick way.
