www.avsl.com 100.540 UK

Metallic Magnetic Bluetooth® Earphones

EMBT1

Item ref: 100.540UK Black, 100.541UK Rose Gold, 100.542UK Grey, 100.543UK Gold

User Manual

These stylish metallic Bluetooth earphones provide both great sound performance and practicality with their magnetic

earbuds and tangle free ribbon cable. Connect to your smart device via Bluetooth and enjoy up to 5 hours of listening

from a single charge. An in-line hands-free microphone and volume/track control gives you the ability to listen to and

take control of your favourite tunes or make and receive calls on the move. There are 4 modern colour schemes to

choose from, which match the latest smartphone designs. To keep your headphones looking like new a hard-shell carry

case is also provided.

Features

• Bluetooth v4.1 Airhoa chipset with multi-point support allowing you to connect 2 devices at the same time.

• Operating distance of up to 10m providing freedom of movement.

• Magnetic earbuds and flat ribbon-style cable for tangle free storage.

• In-line hands-free microphone and volume/track controls.

• 85mAh Lithium rechargeable battery providing up to 5 hours usage from a single charge.

• Supplied with hard-shell carry case, USB charging lead and 3 sizes of earbud

• Fully compatible with iOS and Android devices

Technical Specifications

Speaker Driver

10mmØ

Sensitivity

98db±3db

Impedance

32 Ohms±15%

Frequency Response

20hz-20khz

Bluetooth Version

4.1

Bluetooth Range

Up to 10m (clear line of sight)

Power Supply

Internal rechargeable mAh Lithium Ion battery 85

Charge Time

2 Hours

Battery Life: Bluetooth Playback

Up to 5 hours

Weight:

7.6g

Overview

Powering on/off:

Press and hold the MF button until the blue light blinks and

the voice is heard. To power off, press message “power on”

and hold the MF button until a red light blinks and the voice

message “power off” is heard.

Pairing with your device:

Press and hold the MF button until alternating blue and red

lights blink and the pairing is heard. Select voice message “ ”

the Bluetooth pairing name AV:Link EMBT1 in your device “ ”

list and when connected a voice message saying pairing “

successful, connected can be heard. if your device asks for a ”

pairing code the default setting for these earphones is 0000.

www.avsl.com 100.540 UK

Volume up/next track:

Short press the (+) button to move the unit volume up and press and hold the (+) button to move onto the next track.

Volume down/previous track:

Short press the (-) button to move the unit volume down, press and hold the (-) button to go back to the previous track.

Play/pause:

Short press the MF button to play and pause your current track.

Hands-free operation:

When you receive an incoming call the voice me the voice will then tell you the number of who ssage “incoming call” will be heard and

is calling. To accept the call, press the MF button once or to reject it press the MF button twice. Once you have completed your call,

press the MF button once to hang up. To dial the last number stored on your phone, press the MF button twice either when listening

to music or in standby mode.

Charging the device:

To charge the device only use the USB cable supplied and make sure that the headphones are switched off. Whilst charging a red light

will be on, which will turn blue when they are fully charged. Charging time is normally around 2 hours from flat and the device will give

up to 5 hours of playback time from a single charge.

In the Box

• Bluetooth magnetic earphones 1pc

• USB charging cable 1pc

• Hard-shell carry case 1pc

• Spare silicone buds 2 pairs (small and large)

• User guide 1pc

FAQ

Q) Bluetooth headphon cannot pair with device. Check that the headphones are in pairing mode and that the Bluetooth mode is es A)

enabled on your device and in scan mode.

Q) A) Bluetooth headphones disconnect with my device well within the stated 10m transmission distance. e maximum transmission Th

distance stated is dependent on clear line of sight between the headphones and your device. If there are large metallic objects or a

other devices transmitting radio or wireless signals in the vicinity, they can impact on the reception of the headphones.

Q) Bluetooth headphones won t switch on. ’A) Check that the headphones are fully charged before operation.

Q) Bluetooth headphones won t connect to my PC. Please check that your PC supports the A2DP Bluetooth profile. ’A)

Safety Disclaimer

Do not attempt to service this product yourself as opening or removing covers may result in fire, electric shock or equipment damage

and will also invalidate the warranty. This product is only designed for indoor use and must be kept away from water and high humidity

along with high temperatures and direct sunlight.

This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial waste at the end of its

useful life. The goods must be disposed of according to your local council guidelines.

Hereby, AVSL Group Ltd. declares that the radio equipment type 100.5 /100.5 /100.5 /100.543UK complies with Directive 2014/53/EU : 40UK 41UK 42UK

The full text of the EU declaration of conformity for .5 is available at the following internet address: www.avsl.com/assets/doc/1/0/1005 UK.pdf 100 40UK 40

The full text of the EU declaration of conformity for 100.5 is available at the following internet address: www.avsl.com/assets/doc/1/0/1005 UK.pdf 41UK 41

The full text of the EU declaration of conformity for 100.5 is available at the following internet address: www.avsl.com/assets/doc/1/0/1005 UK.pdf 42UK 42

The full text of the EU declaration of conformity for 100.543 is available at the following internet address: www.avsl.com/assets/doc/1/0/100543UK.pdf UK

Errors and omissions excepted.
