Sida 1/2
www.avsl.com 4. User Manual 12 160UK
IO-ADPT
IO LINK RF ADAPTOR –
Item ref: 124.160 UK
User Manual
Thank-you for choosing this IO Link RF adaptor. Designed for use with satellite boxes that do not
have an RF2 output. This device converts the I/O port to an RF2 output allowing the use of a TV link
or magic eye remote extender. The adaptor also has a RF loop through input to allow reception of
DTV signal for additional TV sets.
Specification:
I/O Input 10 pin din plug on 240mm lead
RF Input RF socket
RF Output RF plug (channel 21 69) –
Dimension 58 x 56 x 21mm
Weight g 60
Installation:
Before installation please ensure that both TV and Sky box are disconnected from mains power.
• Connect adaptor to satellite box through the 10-pin DIN connector ensuring it is correctly in-
line.
• Connect RF output to a magic eye device and then connect to the TV.
• Connect UHF aerial to RF input (if required).
www.avsl.com 4.160 User Manual 12 UK
For set-ups with more than one TV, a distribution amplifier with DC pass facility can be used, such as
Mercury’s AMD & AMS ranges. See diagram below:
Set- up
For the adaptor to work correctly, RF output power must be switched on via the satellite box.
To activate your IO Link adaptor on a Sky+HD box:
• Using your Sky remote control press “SERVICES”.
• Press “0” then “0”then “1” then “SELECT” to enter the installer set-up menu.
• Press the down arrow button to navigate to “RF Outlet Power Supply” and change the setting
on “On”.
• Press the GREEN button to save the change.
• Retune your TV in analogue mode (not DTV mode).
This product is classed as Electrical or Electronic equipment and should not be disposed with other household or commercial
waste at the end of its useful life. The goods must be disposed of according to your local council guidelines.
Errors and omissions excepted
Copyright© 2021 AVSL Group Ltd, Unit 2 Bridgewater Park, AVSL (Europe) Ltd, Unit 3D North Point House,
Taylor Road, Trafford Park, Manchester. M41 7JQ. North Point Bus. Park, New Mallow Road, Cork, Ireland.
