AXVI-9006
INSTALLATION INSTRUCTIONS
AxxessInterfaces.com © COPYRIGHT 2020 METRA ELECTRONICS CORPORATION REV. 5/10/23 INSTAXVI-9006
ATTENTION: With the key out of the
ignition, disconnect the negative battery
terminal before installing this product. Ensure
that all installation connections, especially the
air bag indicator lights, are plugged in before
reconnecting the battery or cycling the ignition
to test this product.
NOTE: Refer also to the instructions included
with the aftermarket radio.
INTERFACE FEATURES
INTERFACE COMPONENTS
TOOLS REQUIRED
• Crimping tool and connectors, or solder gun,
solder, and heat shrink • Tape • Wire cutter
• Zip ties • Small flat-blade screwdriver
TABLE OF CONTENTS
Connections2 ............................................................
Installation3 .............................................................
Programming3 .........................................................
Volkswagen Data Interface 2015-Up
APPLICATIONS
• Provides accessory power
(12-volt 10-amp)
• Retains R.A.P. (retained
accessory power)
• Provides NAV outputs (parking
brake, reverse, speed sense)
• For use in non-amplified
systems, or when replacing an
amplified system
• 48-inch leads for remote tuner
location
• Pre-wired AXSWC harness
(AXSWC sold separately)
• Retains the factory backup
camera
• Retains balance and fade
• Micro-B USB updatable
Volkswagen
Beetle2016-2019 ................................................
Golf Series 2015-Up ...........................................
Jetta2016-2019 ..................................................
Jetta GLI2016-2018 ............................................
Passat...................................................2016-Up
Tiguan2016-2017 ...............................................
• AXVI-9006 interface
• AXVI-9006 harness
Visit for more detailed information about the product and up-to-date AxxessInterfaces.com
vehicle specific applications
