Läs gratis den bruksanvisning för Axis AX-S14 Ultra (2 sidor) i kategorin skärmaskin. Guiden har ansetts hjälpsam av 22 personer och har ett genomsnittsbetyg på 4.6 stjärnor baserat på 11.5 recensioner. Har du en fråga om Axis AX-S14 Ultra eller vill du ställa frågor till andra användare av produkten? Ställ en fråga
Sida 1/2
LUBRICATION
The rod on which the product holder slides, which is underneath the slicer, should be
lubricated weekly with several drops of oil. Machine without oiler. Lift up the machine and
oil the rod directly. After the lubrication have the carriage sliding 4 or 5 times.
Use oil SHELL ONDINA 15 or ESSO MARCOL 82.
Occasionally, the slice thickness plate slide rod should be coated lightly with lubricant.
Turn the slice thickness control fully counterclockwise when lubricating this slide rod
and then turn it ful
ly clockwise when finished.
DO NOT lubricate the rod on which the last slice device slides.
It must be kept clean but not lubricated. The motor has sealed bearings and requires no
lubrication maintenance.
WEAR ADJUSTMENT
After several years of operation and many sharpenings of the blade it may become
necessary to have the slice thickness plate adjusted closer to the blade.
INSTALLAT ION
MAINTENANCE
SLICER
INSTALLATION
UNPACKING
Immediately after unpacking the slicer, check it for possib
le shipping damage. If this
machine is found to be damaged after unpacking, save the packing material and contact
the carrier within 15 days of delivery.
Prior to installation, test the elettrical service to assure that it agrees with the
specifications on the machine data plate 1 .
ELECTRICAL
WARNING: THIS MACHINE IS PROVIDED WITH THIS PLUG MUST BE
CONNECTED TO PROPERLY GROUNDING PLUG, GROUNDED OUTLET. IF THE
RECEPTACLE IS NOT THE PROP
ER GROUNDING TYPE, CONTACT AN
ELECTRICIAN.
CLEANING
This machine must be thoroughly cleaned and sanitiz
ed afte
r installation and before
being put into service.
SAFETY
SAFETY DEVICES INCORPORATED IN THIS SLICER MUST BE IN THEIR CORRECT
OPERATING POSITIONS ANYTIME THE SLICER IS IN USE.
The blade cover 5 must be in position over the knife and secured by tightening
the hand knob.
The Iast slice device 4 must be used when slicing it keep your ha
nds away from
the blade.
When the slicer is not runni
ng, the slicer thickness control 2
must be set on zero
(fuIly clockwise) to prevent the blade edge from being exposed. Always UNPLUG the
power cord before cleaning or moving the slicer.
GB
AX-S9 Ultra
AX-S10 Ultra
AX-S12 Ultra
AX-SD12 Ultra
AX-S14 Ultra
Filename: Man_AX_S_Serie_Ultra_GB.PMD 03/02/15
Dimension mm
Slicing capacity mm
B
A
C
Motor
Data
Volts
Hz
Ph
Amp
N/min
AX-S9Ultra AX-S10Ultra AX-S12Ultra AX-SD12Ultra
E 330 360 470
F 280 280 365
G 410 410 500
H 360 360 455
L 590 590 630
A
AX-S14Ultra
AX-S14Ultra
AX-S14Ultra
X- S14Ultra
AX-S9Ultra AX-S10Ultra AX-S12Ultra AX-SD12Ultra
540
410
600
560
750
390
320
AX-S9Ultra AX-S10Ultra AX-S12Ultra AX-SD12Ultra
12 13 24
15 16 29
35
42
18
22
450
420
600
115
60
1
1,5 1,5 2,5
1750
115
60
1
1750
115
60
1
1750
115
60
1
1750
2,5
115
60
1
1750
2,5
A
B
C
Weight
Net kg
Brut kg
AX-S9Ultra AX-S10Ultra AX-S12Ultra AX-SD12Ultra
140 140 200
190 190 220
170 170 210
225
290
260
150
220
210
5659 Royalmount Avenue
Montreal, Qc, Canada H4P 2P9
Tel.: 514.737.9701 / Toll Free: 888.275.4538
Fax.: 514.342.3854 / Toll Free: 877.453.8832
3560 NW 56th Street
Fort Lauderdale, FL 33309
Tel.: 786.600.4687 / Toll Free: 844.218.8477
Fax.: 786.661.4100
