INSTALLATION GUIDE

ENGLISH

AXIS Q8721-E Dual PTZ Network Camera

Legal Considerations

Video and audio surveillance can be prohibited by laws that vary

from country to country. Check the laws in your local region

before using this product for surveillance purposes. This product

includes two (1) H.264 decoder licenses. To purchase further

licenses, contact your reseller.

Trademark Acknowledgments

Apple, Boa, Bonjour, Ethernet, Internet Explorer, Linux, Microsoft,

Mozilla, Real, SMPTE, QuickTime, UNIX, Windows, Windows Vista

and WWW are registered trademarks of the respective holders.

Java and all Java-based trademarks and logos are trademarks or

registered trademarks of Oracle and/or its affiliates. UPnP

is a

certification mark of the UPnP

Implementers Corporation.

Electromagnetic Compatibility (EMC)

This equipment, configured with designated power supply and IR

illuminators (sold separately), has been designed and tested to

fulfill applicable standards for:

• Radio frequency emission when installed according to the

instructions and used in its intended environment.

• Immunity to electrical and electromagnetic phenomena when

installed according to the instructions and used in its intended

environment.

USA - This equipment has been tested using a shielded network

cable and found to comply with the limits for a Class A digital

device, pursuant to part 15 of the FCC Rules. These limits are

designed to provide reasonable protection against harmful

interference when the equipment is operated in a commercial

environment. This equipment generates, uses, and can radiate

radio frequency energy and, if not installed and used in

accordance with the instruction manual, may cause harmful

interference to radio communications. Operation of this

equipment in a residential area is likely to cause harmful

interference in which case the user will be required to correct the

interference at his own expense.

Canada - This Class A digital apparatus complies with Canadian

ICES-003.

Europe - This digital equipment fulfills the requirements

for RF emission according to the Class A limit of EN 55022.

Caution! This is a Class A product. In a domestic environment this

product may cause RF interference, in which case the user may be

required to take adequate measures.

This product fulfills the requirements for immunity according to

EN 61000-6-1 residential, commercial and light-industry

environments. This product fulfills the requirements for immunity

according to EN 61000-6-2 industrial environments. This product

fulfills the requirements for immunity according to EN 55024

office and commercial environments.

Australia - This digital equipment fulfills the requirements for

RF emission according to the Class A limit of AS/NZS CISPR 22.

NOTICE! This is a class A product. In a domestic environment this

product may cause RF interference, in which case the user may be

required to take adequate measures.

Safety

This product complies with EN/IEC 60950-1 and

EN/IEC 60950-22, Safety of Information Technology Equipment.

Photobiological Safety

This product, configured with IR illuminators (sold separately),

fulfills the requirements for photobiological safety according to

EN 62471 (risk group 1).

Equipment Modifications

This equipment must be installed and used in strict accordance

with the instructions given in the user documentation. This

equipment contains no user-serviceable components.

Unauthorized equipment changes or modifications will invalidate

all applicable regulatory certifications and approvals.

Liability

Every care has been taken in the preparation of this document.

Please inform your local Axis office of any inaccuracies or

omissions. Axis Communications AB cannot be held responsible

for any technical or typographical errors and reserves the right to

make changes to the product and documentation without prior

notice. Axis Communications AB makes no warranty of any kind

with regard to the material contained within this document,

including, but not limited to, the implied warranties of

merchantability and fitness for a particular purpose. Axis

Communications AB shall not be liable nor responsible for

incidental or consequential damages in connection with the

furnishing, performance or use of this material. This product is

only to be used for its intended purpose.

RoHS

This product complies with both the European RoHS

directive, 2002/95/EC, and the Chinese RoHS regulations,

ACPEIP.

WEEE Directive

The European Union has enacted a Directive 2002/96/EC

on Waste Electrical and Electronic Equipment (WEEE

Directive). This directive is applicable in the European

Union member states.

The WEEE marking on this product (see right) or its

documentation indicates that the product must not be disposed of

together with household waste. To prevent possible harm to

human health and/or the environment, the product must be

disposed of in an approved and environmentally safe recycling

process. For further information on how to dispose of this product

correctly, contact the product supplier, or the local authority

responsible for waste disposal in your area.

Business users should contact the product supplier for information

on how to dispose of this product correctly. This product should

not be mixed with other commercial waste.

Support

Should you require any technical assistance, please contact your

Axis reseller. If your questions cannot be answered immediately,

your reseller will forward your queries through the appropriate

channels to ensure a rapid response. If you are connected to the

Internet, you can:

• download user documentation and firmware updates

• find answers to resolved problems in the FAQ database. Search

by product, category, or phrases

• report problems to Axis support by logging in to your private

support area

ENGLISH

Safeguards

Please read through this Installation Guide carefully before installing the product. Keep the Installation Guide for

further reference.

• Risk of pinching. Do not touch the product while it is moving.

• Store the Axis product in a dry and ventilated environment.

• Avoid exposing the Axis product to vibration, shocks or heavy pressure and do not install the product on

unstable brackets, unstable or vibrating surfaces or walls, since this could cause damage to the product.

• Only use applicable tools when installing the Axis product; excessive force could cause damage to the

product.

• Do not aim the thermal camera lens toward the sun or other high-intensity radiation sources since this

could cause damage to the sensor.

• Do not use chemicals, caustic agents, or aerosol cleaners. Use a damp cloth for cleaning.

• Only use accessories that comply with the technical specification of the product. These can be provided by

Axis or a third party.

• Use only spare parts provided by or recommended by Axis.

• Do not attempt to repair the product by yourself, contact Axis or your Axis reseller for service matters.

• This Axis product shall be used in compliance with local laws and regulations.

• Do not install the camera near heat sources since fluctuating temperatures may affect thermal image qual-

ity.

• The Axis product should be installed by a trained professional. Please observe relevant national and local

regulations for the installation.

Transportation

• When transporting the Axis product, use the original packaging or equivalent to prevent damage to the

product.

Battery Replacement

This Axis product uses a 3.0 V CR2032 Lithium battery as the power supply for its internal real-time clock (RTC).

Under normal conditions this battery will last for a minimum of 5 years. Low battery power affects the operation

of the RTC, causing it to reset at every power-up. A log message will appear when the battery needs replacing. The

battery should not be replaced unless required!

If the battery does need replacing, please contact www.axis.com/techsup for assistance.

• Dispose of used batteries according to the manufacturer's instructions.

• Risk of explosion if battery is incorrectly replaced.

• Replace only with the same or equivalent battery, as recommended by the manufacturer.

Produktspecifikationer

Varumärke:	Axis
Kategori:	övervakningskamera
Modell:	Q8721-E
Vikt:	1400 g
Bredd:	180 mm
Djup:	135 mm
Höjd:	67 mm
Ljudformat som stöds:	AAC
Videoformat som stöds:	H.264
Maximal upplösning:	1920 x 1080 pixlar
Infraröd våglängd:	850 nm
Fast brännvidd:	60 mm
HTTPS-kryptering:	Ja
Ljudsystem:	2-vägs
Optisk sensorstorlek:	1/3 "
Bildsensortyp:	CMOS
Digital zoom:	12 x
Optisk zoom:	10 x
Internminne:	256 MB
vitbalans:	Automatisk
Modell:	IP-säkerhetskamera
Flashminne:	128 MB
Rotationsvinkel:	360 °
Lutningsvinkel:	-20 - 45 °
Typ av minneskort:	SD, SDHC
Kabellängd:	2.5 m
Produktens färg:	Vit
bruksanvisning:	Ja
Slutartid:	1/10000 s
LED typ:	IR
mörkerseende avstånd:	100 m
Strömförbrukning (vanlig):	30 W
Temperatur vid drift:	-50 - 50 ° C
Intervall för relativ operativ luftfuktighet:	10 - 100 %
AC-inspänning:	120-230 V
Internationellt skydd (IP) kod:	IP66
Video rörelsedetektor:	Ja
Kryptering/säkerhet:	HTTPS
Placeringar som kan användas:	Inomhus & utomhus
Anslutningsteknologi:	Kabel
Dag / nattläge:	Ja
Monteringssätt:	Innertak/vägg
Minimibelysning:	0.2 lx
Kameraslutningstyp:	Elektronisk
Brännviddsintervall:	5.1 - 51 mm
Mörkerseende:	Ja
Bildfrekvens:	30 fps
Nätverksansluten (Ethernet):	Nej
Stöd för nätverksprotokoll:	IPv4/v6, HTTP, HTTPS, QoS Layer 3 DiffServ, FTP, CIFS/SMB, SMTP, Bonjour, UPnP™, SNMPv1/v2c/v3(MIB-II), DNS, DynDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, RTCP, ICMP, DHCP, ARP, SOCKS
Filtrering för IP-adress:	Ja
DC-utgång volt:	+12V
Växelström Frekvens:	50 - 60 hz
Panoreringshastighet:	20 °/sek
PTZ-styrning:	Ja
Synfältsvinkel (FOV):	48.1 °
Antal belysning lysdioder:	30
Uttag för mikrofon/linje in:	Ja
Larm ingång / utgång:	Ja
Objektivets betraktningsvinkel, horisontell:	16 °
Panoreringsvinkel:	0 - 360 °
Objektivets betraktningsvinkel, vertikal:	9 °
Lutningshastighet:	20 °/sek
F-tal (relativ öppning):	1.8
