B-TECH AUDIO VIDEO MOUNTS
www.btechavmounts.com
CONTENTS
INSTALLATION TOOLS REQUIRED
FEATURES
BT7523
FLAT SCREEN WALL MOUNT WITH TILT
INSTALLATION GUIDE & PARTS LIST
This Pack Contains 1 Mount
Crosshead
screwdriver
Drill
10mm (7/16") masonry bit
or 6mm (1/4") wood bit
Pencil
Stud finder
(optional)
Installation Safety Notes.....................................................................................................................2
Parts List.............................................................................................................................................4
Disassembly Instructions....................................................................................................................6
Installation Instructions.......................................................................................................................7
Additional Mounting Options.............................................................................................................13
Product Dimensions..........................................................................................................................14
B-Tech Contact Details.....................................................................................................................16
PLEASE KEEP THIS FOR FUTURE REFERENCE
13mm (1/2") spanner
or socket
●Designed for flat screens up to 42” (107cm) / 25kg (55lbs)
●Fits 75 x 75mm, 100 x 100mm, 200 x 100mm
and 200 x 200mm VESA mounting patterns
●Mounts screen only 52mm (2”) from wall
●Tilts +/-15°
●Simple hook-on installation with all mounting
hardware included
●Supplied with pin hex security screws for
added security
●Compatible with B-Tech accessory collars
Community Design Nos.
001713280-0012
001713280-0017
COMPATIBLE
Produktspecifikationer
| Varumärke: | B-tech |
| Kategori: | Platt panelstöd |
| Modell: | BT7523 |
| Maximal skärmstorlek: | 42 " |
| Lutningsvinkel: | -15 - 15 ° |
| Maxvikt: | 25 kg |
| Produktens färg: | Silver |
| Monteringssätt: | Vägg |
| Gränsssnitt för panelmontering: | 75 x 75,100 x 100,200 x 100,200 x 200 mm |
| Monteringsgränssnitt kompatibilitet (min): | 75 x 75 mm |
| Monteringsgränssnitt kompatibilitet (max): | 200 x 200 mm |
| Avstånd till väggen (max): | 52 mm |
