BT883

PROJECTOR CEILING MOUNT

WITH ADJUSTABLE DROP

INSTALLATION GUIDE & PARTS LIST

This Pack Contains 1 Mount

Installation Safety Notes.....................................................................................................................2

Parts List.............................................................................................................................................4

Installation Instructions.......................................................................................................................6

Product Dimensions..........................................................................................................................15

B-Tech Contact Details.....................................................................................................................16

B-TECH AUDIO VIDEO MOUNTS

www.btechavmounts.com

CONTENTS

INSTALLATION TOOLS REQUIRED

FEATURES

12mm (1/2") masonry bit

or 8mm (11/32") wood bit

Level

(optional)

PLEASE KEEP THIS FOR FUTURE REFERENCE

Crosshead

screwdriver

Drill

Pencil

13mm (1/2") spanner

or socket

REG. DESIGN NO: 3016251

● Suitable for projectors up to 10kg (22lbs)

● Hand lever for easy adjustment of ceiling drop:

Min 750mm (29.5”) – Max 1222mm (48”)

● +/-90° tilt adjustment, +/-90° roll adjustment & 360° swivel

● Unique ‘carousel’ mounting plate for universal compatibility

● Suitable for angled / cathedral ceilings

● Integrated cable management

● Maximum distance between any two fixing points on

projector: 340mm (13.5”)

● Suitable for projectors with M2.5, M3, M4, M5 and M6 fixings

● Simple installation with all mounting hardware and fixings included

REG. DESIGN NO: 3016251

Produktspecifikationer

Varumärke:	B-tech
Kategori:	Platt panelstöd
Modell:	BT883
Teleskopisk:	Ja
Avstånd till väggen (min):	830 mm
Maxvikt:	10 kg
Produktens färg:	Silver
Monteringssätt:	Vägg
Avstånd till väggen (max):	1330 mm
