Dear Customer,

Congratulations on choosing , one of the finest vehicle in the country “Bajaj Pulsar 135 LS”

brought to you by Bajaj Auto Limited.

Before you prepare for riding, please read this User's Guide carefully to familiarize yourself with

the mechanism and the controls of the vehicle.

To maintain your bike in perfect running condition to deliver consistent performance, we

earnestly advise you to avail periodic services.

You can entrust our Bajaj Dealers, who are well equipped with all necessary facilities, skill sets

and trained manpower for servicing and repairs of your . In the rare event “Bajaj Pulsar 135 LS”

of going to a local garage, always insist on Genuine Bajaj Spares to ensure safety, performance

and longer life of your vehicle.

Should you require any additional information, please approach our Bajaj Dealers. If necessary,

you may also write to selling dealers, with relevant details like Registration no. Chassis no.,

Engine no., Date of purchase, Kms. run, name of selling dealer and your contact numbers.

Finally, may we request you to give your vehicle a proper care and regular maintenance, as

described in this manual. We are sure this will offer you a long trouble-free ownership

experience.

Wishing you unlimited miles of happiness!

International Marketing

BAJAJ AUTO LIMITED

Akurdi Pune 411 035 India

Table of Contents

Description

Identification Data....................................................................................................................................1

Technical Specifications......................................................................................................................... 2

Location of Parts.....................................................................................................................................3

How to Ride your Bike.........................................................................................................................13

• Running In.................................................................................................................................13

• Riding the Bike..........................................................................................................................13

• Fuel Saving Tips.......................................................................................................................15

Safe Riding Tips....................................................................................................................................16

General Maintenance Information.........................................................................................................17

• Engine Oil..................................................................................................................................17

• Battery........................................................................................................................................19

• Rainy Season Care...................................................................................................................20

Daily Safety Checks...............................................................................................................................21

Non-use Maintenance............................................................................................................................22

Periodic Maintenance / Lubrication Chart...........................................................................................23

Pre-Delivery Inspection..........................................................................................................................26

Applicable to All Periodic Services......................................................................................................27

Use Only Bajaj Genuine Parts..............................................................................................................28

DOC. NO.: 71111376 REV. 02, JULY. 11

Warning

This indicates that a potential hazard or injury to you or other persons and

to the vehicle can happen, if the advise provided is not followed.

Safety and Warning Information

Caution

This indicates that a potential hazard that could result in vehicle damage.

Follow the advise provided with the caution.

The description and illustration in this booklet are not to be taken as binding on

the manufacturers.

The essential features of the type described and illustrated herein remaining

unaltered.

Bajaj Auto Limited reserves the right to carry out at any moment without being

obliged to bring this booklet upto-date.

Modifications on the vehicle, parts or accessories as may be convenient and

necessary.

Notice

Identification Data

The Frame and Engine serial numbers are used to register the motorcycle. They are the unique

alpha-numeric codes to identify your particular vehicle from others of the same model and type.

Engine Number Location

On LH Side Crankcase

Near Gear Change Lever

(Alpha-Numeric - 11 Digits)

Frame Number Location

On LH Side of Steering Tube

(Alpha-Numeric - 17 Digits)

Technical Specifications

Engine 4 stroke DTS-Si, Single cylinder, Natural :

air cooled

Bore x Stroke 54 mm x 58.8 mm:

Eng. Displacement 134.66 cc:

Compression Ratio 9.8 : 1:

Idling Speed 1400 rpm:

Max. Net Power 13.5 Ps @ 9000 rpm:

Max. Net Torque 11.4 Nm @ 7500 rpm:

Ignition System DC, Micro controller based digital CDI :

with Trics

Spark Plug - 2 Nos. Champion PRZ9HC BOSCH UR4AC: ,

Spark Plug Gap 0.6 to 0.7 mm:

Lubrication Wet sump, Forced.:

Transmission 5 speed constant mesh:

Front Brake Hydraulic operated 240 mm disc brake:

Rear Brake Mech. expanding shoe 130 mm :

Fuel Tank Capacity :

Full 8.0 liters:

Reserve 2.5 liters:

Usable Reserve 1.6 liters:

Dimensions :

Length 1995 mm:

Width 765 mm:

Height 1045 mm:

Wheel base 1325 mm:

Ground clearance 170 mm :

Tyre Size Front 2.75 X 17”, 41 P:

Rear 100/90 X 17”, 55 P:

Tyre Pressure Front 1.75 kg/cm2 (25 psi):

Rear (Solo) 2.00 kg/cm2 (28 psi):

Rear (Pillion) 2.25 kg/cm2 (32 psi):

Electrical System 12 Volts DC:

Head Lamp 35/35W:

Pilot lamp 5W (2 nos.):

Neutral LED:

Reserve Indicator LED:

Tail / Stop Lamp LED:

Turn Signal Indicator LED:

Side indicator Lamp LED:

Hi Beam Indi. Lamp LED:

Speedometer Lamp LED:

Fuel Gauge LED bar display:

Horn 12 V DC 2A:

Battery 12 V 5 Ah MF:

Rear No. Plate Lamp 5W:

Vehicle Kerb Weight 122 kg.:

Gross Vehicle Weight 252 kg.:

Max. Speed 115 km/hr. (With single rider 68 kg):

Climbing Ability 26% max.:

Note : All dimensions are under UNLADEN condition. Above

information is subject to change without any notice.

(inside cluster)
